Ilve UMI30NE3WHP Bruksanvisning
Les nedenfor 📖 manual på norsk for Ilve UMI30NE3WHP (60 sider) i kategorien Komfyr. Denne guiden var nyttig for 3 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere
Side 1/60
COOKERS
Majestic
User Instructions, Installation, Maintenance
Cookers characteristics
These warnings refer to different models of cookers.
Be sure that you have correctly identied the model that you possess (see the rating
plate).
cod.EI33960100000EN
48/2022
ZONA PER
TARGHETTA
EN
MODEL
UM30
UM09
UMD10
UM12
UM15
UMI30
UMI09
UMDI10
DIMENSIONS
29 7/8” (W) x 27 9/16” (D) x 35 55/04” (H)
35 7/8” (W) x 27 9/16” (D) x [34 1/4”- 36 1/8”] (H)
39 3/8” (W) x 27 9/16” (D) x [34 1/4”- 36 1/8”] (H)
47 7/8” (W) x 27 9/16” (D) x [34 1/4”- 36 1/8”] (H)
59 1/2” (W) x 27 9/16” (D) x [34 1/4”- 36 1/8”] (H)
29 7/8” (W) x 27 9/16” (D) x 35 55/04” (H)
35 7/8” (W) x 27 9/16” (D) x [34 1/4”- 36 1/8”] (H)
39 3/8” (W) x 27 9/16” (D) x [34 1/4”- 36 1/8”] (H)
2
• Before beginning, please read these instructions completely and carefully.
• Do not remove permanently afxed labels, warnings, or plates from the product. This may void the warranty.
• Please observe all local and national codes and ordinances.
• Please ensure that this product is properly grounded.
• The installer should leave these instructions with the consumer who should retain them for local inspector’s use
and for future reference.
WARNING
IMPORTANT - PLEASE READ AND FOLLOW
TIPPING HAZARD
To reduce the risk of the appliance tipping, it must be
secured by a properly installed anti-tip bracket(s). Ve-
rify that the anti-tip bracket has been properly atta-
ched to the oor or wall as directed in the installation
instructions. After removing the drawer, or the panel
under the door, using a ashlight, verify that the an-
ti-tip bracket has been installed properly
• THIS RANGE CAN TIP
• INJURIES TO PERSONS CAN RESULT
• INSTALL ANTI-TIP DEVICE PACKED
• WITH RANGE
• SEE INSTALLATION INSTRUCTIONS
Anti-tip bracket
WARNING If the informations in this instructions is not followed exactly, a
re or explosion may result causing property damage, personal injury
or death.
— Do not store or use gasoline or other ammable vapors and liquids
in the vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use any phone in your building.
• Immediately call your gas supplier from a neighbor’s phone.
Follow the gas supplier’s instructions.
• If you cannot reach your gas supplier, call the re department.
— Installation and service must be performed by a qualied installer,
service agency or the gas supplier.
3
All Appliances:
CAUTION: Do Not Leave Children Alone - Children should not be left alone or unattended in area where appliance
is in use. They should never be allowed to sit or stand on any part of the appliance. Do not store items of interest to
children above or at the back of this appliance, as they could climb on the appliance to reach items and be
injured.
Wear Proper Apparel - Loose-tting or hanging garments should never be worn while using the appliance.
User Servicing - Do not repair or replace any part of the appliance unless specically recommended in the ma-
nual.
All other servicing should be referred to a qualied technician.
Storage in or on Appliance – Flammable materials should not be stored in an oven or near surface units.
Do Not Use Water on Grease Fires - Smother re or ame or use dry chemical or foam type extinguisher .
Use Only Dry Potholders - Moist or damp potholders on hot surfaces may result in burns from steam. Do not
let potholder touch hot heating elements. Do not use a towel or other bulky cloth.
IMPORTANT INSTRUCTION
WARNING
• NEVER use this appliance as a space heater to heat or warm the room. Doing so may result in carbon monoxide
poisoning (only for GAS cooking).
• IF YOU OR SOMEONE IN YOUR FAMILY HAS A PACEMAKER, PLEASE CONSULT WITH A PHYSICIAN BEFORE USING. Due to
high operating frequencies, a pacemaker may not function properly due to electromagnetic transmissions.
• Keep appliance area clear and free from combustible materials, gasoline and other ammable vapors and
liquids.
• A child or adult can tip the range and be killed.
• Install the anti-tip device to the structure and/or the range. Verify the anti-tip device has been properly installed
and engaged [2 options are available: please refer to the pictures at page 7].
• Engage the range to the anti-tip device by [2 options are available: please refer to the pictures at page 7]. Ensure
the anti-tip device is re-engaged when the range is moved.
• Re-engage the anti-tip device if the range is moved. Do not operate the range without the anti-tip device in place
and engaged.
• See installation instructions for details.
• If the enclosed hardware cannot be utilized, please refer to a qualied installer to properly fasten the appliance
so that it does not tip over.
• Failure to do so can result in death or serious burns to children or adults.
• Installation must conform with local codes or in absence of codes, the National Fuel Gas Code ANSIZ223.1/NFPA 54
latest edition. Electrical installation must be in accordance with the National Electrical Code, ANSI/NFPA70 latest edi-
tion and/or local codes. IN CANADA: Installation must be in accordance with the current CAN/CGA-B149.1 National
Gas.
• Installation Code or CAN/CGA-B 149.2, Propane. Installation Code and/or local codes. Electrical installation must be
in accordance with the current CSA C22.1 Canadian Electrical Codes Part 1 and/or local codes.
• Installation of any gas –red equipment should be made by a licensed plumber . A manual gas shut-off valve must
be installed in the gas supply line ahead of the oven in the gas stream for safety and ease of service.
• In Massachusetts: All gas products must be installed by a “Massachusetts” licensed plumber or gastter . A “T” handle
type manual gas valve must be installed in the gas supply line to this appliance. The manufacturer will not be respon-
sible for any damage to property or to persons caused by incorrect installation or improper use of the appliance.
• The manufacture reserves the right to make changes to its products when considered necessary and useful, without
affecting the essential safety and operating characteristics.
• This appliance has been designed for non-professional, domestic use only.
• This appliance must be used only for the purposes for which it was intended. Any other use is incorrect and therefore
dangerous.
• Possible hazards may result from using this appliance for storage space.
• Appliances are not intended for manufactured (mobile) home installation .
• Misuse of appliance doors or drawers such as stepping, leaning or sitting on them can result in damage or personal
hazards or injuries.
• DO NOT TOUCH SURFACE UNITS OR AREAS NEAR UNITS – Surface units may be hot even though they are dark in color.
Areas near surface units may become hot enough to cause burns. During and after use, do not touch, or let clothing
or other ammable materials contact surface units or areas near units until they have had sufcient time to cool. Do
not touch the burner assembly, grates or surroundings urfaces (including the backguard) or the interior surfaces of
the oven during use.
• Care must be taken to prevent aluminum foil and meat probes from contacting the heater elements.
Produkspesifikasjoner
| Merke: | Ilve |
| Kategori: | Komfyr |
| Modell: | UMI30NE3WHP |
