Operating instructions
Contents
Installation, 2-3-4
Positioning and levelling
Connecting the water and electricity supplies
Advice regarding the first wash cycle
Technical data
Ecodesign Regulation
Electrical Connection
Description of the appliance, 5
Overall view
Control panel
Loading the racks, 6
Lower rack
Cutlery basket
Upper rack
Start-up and use, 7-8
Starting the dishwasher
Measuring out the detergent
Wash options
Wash cycles, 9
Table of wash cycles
Rinse aid and refined salt, 10
Measuring out the rinse aid
Measuring out the refined salt
Care and maintenance, 11
Shutting off the water and electricity supplies
Cleaning the dishwasher
Preventing unpleasant odours
Cleaning the sprayer arms
Cleaning the water inlet filter
Cleaning the filters
Leaving the machine unused for extended periods
Precautions and advice, 12
General safety
Disposal
Saving energy and respecting the environment
Troubleshooting, 13
Guarantee, 14
After Sales Service, 15
IDP 127B D
DISHWASHER
English, 1
EN
EN
2
Installation
Keep this instruction manual in a safe place for future
reference. If the appliance is sold, given away or moved,
please ensure the manual is kept with the machine, so that
the new owner may benefit from the advice contained within
it.
Please read this instruction manual carefully: it
contains important information regarding the safe
installation, use and maintenance of the appliance.
If the appliance must be moved at any time, keep it in
an upright position; if absolutely necessary, it may be tilted
onto its back.
This appliance is intended to be used in household and
similar applications such as:
- staff kitchen areas in shops, offices and other working
environments;
- farm houses;
- by clients in hotels, motels and other residential type
environments;
- bed and breakfast type environments.
Positioning and levelling
1. Remove the appliance from all packaging and check
that it has not been damaged during transportation.
If it has been damaged, contact the retailer and do not
proceed any further with the installation process.
2. Check the dishwasher by placing it so that its sides or
back panel are in contact with the adjacent cabinets or
even with the wall. This appliance can also be recessed
under a single worktop
* (
see the Assembly instruction
sheet
).
3. Position the dishwasher on a level and sturdy floor. If the
floor is uneven, the front feet of the appliance may be
adjusted until it reaches a horizontal position. If the
appliance is levelled correctly, it will be more stable and
much less likely to move or cause vibrations and noise
while it is operating.
4. Adjust the height of the rear foot from the front of the appliance*
on the central lower part of the dishwasher, turning a hexagonal
spanner (red color) with an opening of 8 mm in a clockwise
direction to increase the height or in an anticlockwise direction to
decrease the height.
Connecting the water and electricity
supplies
Connection to the water and electricity supplies should
only be performed by a qualified technician.
The dishwasher should not stand on top of the water
hoses or the electricity supply cable.
The appliance must be connected to the water supply
network using new hoses.
Do not use old hoses.
The water inlet and outlet hoses and the electricity supply
cable may be positioned towards the right or the left in
order to achieve the best possible installation.
Connecting the water inlet hose
•To a suitable cold water connection point: before
attaching the hose, run the water until it is perfectly clear
so that any impurities that may be present in the water
do not clog the appliance; after performing this
operation, screw the inlet hose tightly onto a tap with a
¾ gas threaded connection.
•To a suitable hot water connection point: your
dishwasher may be supplied with hot water from the
mains supply (if you have a central heating system with
radiators) provided that it does not exceed a temperature
of 60°C.
Screw the hose to the tap as described for connection
to a cold water supply.
If the inlet hose is not long enough, contact a specialist
store or an authorised technician (
see Assistance
).
The water pressure must be within the values indicated
in the Technical data table (
see adjacent information
).
The hose should not be bent or compressed.
Connecting the water outlet hose
Connect the outlet hose (without bending it) to a drain
duct with a minimum diameter of 4 cm.
The outlet hose must be at a height ranging from 40 to 80
cm from the floor / surface where the dishwasher rests (A).
Before connecting the water outlet hose to the sink drain,
remove the plastic plug (B).
Anti-flooding protection
To ensure floods do not occur, the dishwasher:
- is provided with a special system which blocks the water
supply in the event of anomalies or leaks from inside the
appliance.
Some models are also equipped with the supplementary
safety device
New Acqua Stop
*, which guarantees anti-
flooding protection even in the event of a supply hose
rupture.
WARNING: HAZARDOUS VOLTAGE!
Under no circumstance should the water inlet hose be cut
as it contains live electrical parts.
* Only available in selected models.
EN
3
Electrical connection
Before inserting the plug into the electrical socket, make
sure that:
•The socket is earthed and complies with current
regulations.
•The socket can withstand the maximum load of the
appliance, which is indicated on the data plate located
on the inside of the door (
see chapter entitled
Description of the appliance
).
•The power supply voltage falls within the values
indicated on the data plate on the inside of the door.
•The socket is compatible with the plug of the appliance.
If this is not the case, ask an authorised technician to
replace the plug (
see Assistance
); do not use extension
cables or multiple sockets.
Once the appliance has been installed, the power
supply cable and the electrical socket should be easily
accessible.
The cable should not be bent or compressed.
If the power supply cable is damaged, it must be re-
placed by the manufacturer or its Technical Assistance
Service in order to prevent all potential hazards. (See As-
sistance)
The Company shall not be held responsible for any
incidents that occur if these regulations are not observed.
Technical data
Dimensions
width 60 cm
height 85 cm
depth 60 cm
Capacity 12 standard place-settings
Water supply
pressure
0,05 ÷ 1MPa (0.5 ÷ 10 bar)
7,25 – 145 psi
Power supply voltage See appliance data plate
Total absorbed power See appliance data plate
Fuse See appliance data plate
This dishwasher conforms to the
following European Community
Directives:
-2006/95/EC (Low Voltage)
-2004/108/EC (Electromagnetic
Compatibility)
-2005/32/EC (Comm. Reg.
1275/2008) (Ecodesign)
-97/17/EC (Labelling)
-2002/96/EC (Waste Electrical
and Electronic Equipment)
(WEEE)
Anti-condensation strip*
After installing the dishwasher, open the door and stick the
adhesive transparent strip under the wooden shelf in order
to protect it from any condensation which may form.
Advice regarding the first wash cycle
After the appliance has been installed, immediately before
running the first wash cycle, completely fill the salt
dispenser with water and add only then approximately 1 kg
of salt (
see chapter entitled Rinse aid and refined salt
). The
water may overflow: this is normal and is not a cause for
concern. Select the water hardness value (
see chapter
entitled Rinse aid and refined salt
). - After the salt has been
poured into the machine, the LOW SALT indicator light*
switches off.
If the salt container is not filled, the water softener and
the heating element may be damaged as a result.
ECODESIGN REGULATION
ECO wash cycle is the standard cycle to which the energy label data refers; this cycle can be used to wash crockery with a normal
soil level and is the most efficient in terms of energy and water consumption for this type of crockery. To reduce consumption even
further, only run the dishwasher when it is full.
Standby consumption: Left-on mode consumption: 3 W – Off mode consumption: 1,3 W
Consumption data table for the main cycles
* Cycle data refers to the values recorded in a laboratory, in accordance with European standard EN 50242.
** Data is obtained by recording values when the appliance is operational and loaded with user crockery.
Standard conditions* User conditions**
Energy consumption
(kWh/cycle)
Water consumption
(l/cycle)
Duration
(min/cycle)
Energy consumption
(kWh/cycle)
Water consumption
(l/cycle)
Duration
(min/cycle)
INTENSIVE
1,60 16 150 1,40 15 135
NORMAL
1,30 16 120 1,10 15 110
