Side 1/44
Innity Kappa 6, Kappa 8, and Kappa 10 marine speaker - Owner’s Manual
Haut-parleur marine Innity Kappa 6, Kappa 8 et Kappa 10 - Mode D’emploi
Altavoz para entornos marinoss Innity Kappa 6, Kappa 8 y Kappa 10 - Manual de Propietario
Innity Kappa 6、Kappa 8 和 Kappa 10 船用扬声器 - 用户手册
Innity Kappa 6、Kappa 8 和 Kappa 10 船載喇叭 - 擁有者手冊
Marine speaker laut Innity Kappa 6, Kappa 8, dan Kappa 10 - Panduan Pengguna
Innity(インフィニティ ) Kappa 6、Kappa 8、Kappa 10マ リ ー ン・ス ピ ー カ ー -
取扱説明書
Innity Kappa 6, Kappa 8 및 Kappa 10 Marine 마린 스피커 - 사용자 설명서
INFINITY KAPPA 6, KAPPA 8, AND
KAPPA 10 MARINE SPEAKER
CHS
ES
FR
EN
CHT
JP
KR
ID
THANK YOU FOR YOUR PURCHASE . . .
Your Infinity product has been designed to provide you with the performance and ease of operation you would expect from
Infinity.
ABOUT THE MANUAL
This manual describes general installation guidelines. However, please note that proper installation of marine audio
components requires qualified experience. If you do not have the knowledge and tools to successfully perform this
installation, we strongly recommend consulting an authorized Infinity dealer about your installation options. Keep all
instructions and sales receipts for reference.
WHAT’S IN THE BOX
Kappa 6
DIMENSIONS
Kappa 6
Kappa 8
Kappa 10
Kappa 8
EN
INFINITY KAPPA 6, KAPPA 8, AND
KAPPA 10 MARINE SPEAKER
12X
12X
1X
2X
1X
1X
2X
2X
2X
12X
12X
1X
1X
1X
2X
2X
2X
1X
2X
6X
6X
1X
1X
1X
1X
1X
1X
7-15/32” (189.4mm)
5-23/32” (144.8mm)
2-9/16” (65mm)
3-21/32” (92.5mm)
3-3/16” (80.5mm)
4-9/32” (108.1mm)
9-1/2” (241mm)
7” (177.4mm)
SPEAKER SIGNAL WIRING
To send signal to the Infinity marine speaker, connect the positive (+) and negative (-) speaker wires to the appropriate
speaker outputs of your source unit or amplifier. Be sure to observe proper polarity.
SPEAKER LED WIRING
To provide power for the LEDs, plug the 24-gauge black (+), blue, green, and red LED wires from the speaker into the
included female connector, then run the wires from the female connector to your compatible 12-volt power source or light
controller (sold separately). If using a separate controller, be sure to connect each wire to the proper output.
If hardwiring the LEDs directly to your power source, you can choose the color of the LEDs by connecting the black wire to
the positive (+) terminal, and the appropriate R, G, and/or B single wire or combination of wires to the negative (-) terminal.
There are 7 possible colors, depending on the wiring configuration you choose:
EN
Kappa 10
9-9/16” (235.6mm)
11-5/8” (295mm)
6-13/32” 162.4mm
4-7/8” (123mm)
R BG
To power source To speaker
Blue
Green
Red
Black
