TSS-CENTER4000
Owner’s Guide
TOTAL SPEAKER SOLUTIONS
TSS-4000
INTRODUCTION
Infinity Total Solutions
™
Infinity Total Solutions TSS-CENTER4000 center channel
speakers. It uses identical drivers to provide exceptional
dialogue r
eproduction and a seamless transition between the
front channels.The horizontal design allows for maximum
placement flexibility.
About This Guide
Please read this guide completely before connecting and
operating the TSS-CENTER4000 center channel speaker.
Maximum perf
ormance is dependent upon following these
instructions, as well as those in the owner’s manuals of
associated components in your home theater system. Save
these instr
uctions for future reference.
Unpacking the Speaker
F
inish unpacking the speaker and check the contents. If you
suspect damage from transit, report it immediately to your
dealer. Keep the shipping carton and packing materials for
future use.
Contents
Please verify that the package contains the following items:
PLANNING YOUR SYSTEM
Before deciding where to best place your speakers, survey your
r
oom and study Figures 1 and 2.
Figure 1. In this overhead view of a typical installation, satellite
speaker
s are used to reproduce sound for the front and surround
channels.The center channel reproduces sound and dialogue.
The powered subwoofer provides bass for effects and music.
Placement
F
igur
e 2.
T
his example shows the TSS-CENTER4000 being placed
on top of a tele
v
ision.The speaker can also be placed below the
television and tilted up (see Figure 3).
Couch
Left
Front
Channel
Left
Surround
Channel
Right
Surround
Channel
Right
Front
Channel
Center
Channel
(above or below TV)
Subwoofer
(1) TSS-CENTER4000 center channel speaker
(1) Speaker base
(1)
Wall bracket with wall bracket cover
2
TSS-CENTER4000
P
ar
t
A
Part B
(2) Wall-mount end caps
(attached to satellite)
(1) Allen
wrench
3
TSS-CENTER4000
Tilting the Speaker
If needed,
the enclosed stand allows you to tilt the speaker
across a wide range (i.e., up a maximum of 18˚ or down a
maximum of 7˚),
as shown in Figure 3.
Important!
Do not e
xceed the tilt range. Doing so may cause the speaker to
fall out of its stand.
Figure 3.
Wall-Mounting the TSS-CENTER4000 Using the
Included Wall Bracket
The customer is responsible for proper selection and use of
mounting hardware, and for correctly and safely wall-mounting
the speakers.
Step One
Remove the wall bracket cover by removing the four wall bracket
screws on the ends as shown.
Step Two
Run the speaker wire behind the wall bracket and out the hole
in the center. After deciding where to place the center speaker,
attach the wall bracket (in a horizontal position) to the wall
using the appropriate screws and anchors.
Step Three
Run the speaker wires out through the hole in the center of
the wall bracket cover. Resecure in place with the four wall
bracket screws, as shown.
Mounting Screws and Anchors
Not Included
Wall Bracket
Center Hole
