Side 1/74
1
Microwave/Oven Combination Control Guide
Parts and Features
This manual covers several models. Your model may have some or all of the items listed. Refer to this manual or the Frequently Asked
Questions (FAQs) section of our website at www.jennair.com for more detailed instructions. In Canada, refer to the Customer Service
section at www.jennair.ca.
A. Electronic oven control
B. Convection element and fan
(hidden behind back panel)
C. Light
D. Broil element
E. Turntable
F. Metal shielded window
G. Lower oven (on combination models. See
separate Control Guide.)
H. Bottom vent
I. Bottom Vent Shield (on some models)
J. Dual microwave emission
K. Model and serial number plate (on center
vent under control panel.
NOTE: On single microwave oven models,
on the right side trim.)
L. Door switch
Parts and Features not shown
Convection grid
Grilling grid
Crisper pan and handle
2
Turntable
A. Turntable
B. Support and rollers
C. Hub
The turntable rotates in both directions to help cook food more
evenly. Do not operate the microwave oven without having the
turntable in place. Refer to the Quick Start Guide for ordering
information.
The raised, curved lines in the center of the turntable bottom fit
between the 3 spokes of the hub. The hub turns the turntable
during microwave oven use. The rollers on the support should fit
inside the turntable bottom ridge.
NOTE: The microwave-cooling fan may continue to run for several
minutes after the cooking cycle has been completed. The
microwave cooking does not continue beyond the end of cooking
cycle.
To Turn On/Off:
For best microwave performance, it is recommended to always
leave the turntable on. If necessary, the turntable can be turned
Off (except during an auto function).
This is helpful when cooking with a dish that is larger than the
turntable.
1. From the Microwave Cooking Mode menu, touch
TURNTABLE to turn the rotation On or Off.
A. Cooking mode
B. Time – minute selection
C. Time – second selection
D. Turntable On/Off menu
E. Start cooking cycle
F. Power level selection
Convection Grid
The convection grid provides optimal heat circulation for
convection cooking (on some models). It is recommended for
convection cooking and for grilling thick pieces of meat such as
bone-in chicken.
■ The grid will become hot. Always use oven mitts or pot holders
when handling.
■ To avoid damage to the microwave oven, do not allow the grid
to touch the inside cavity walls, ceiling, or floor.
■ Always use the turntable.
■ To avoid damage to the microwave oven, do not store the grid
in the oven.
■ Two-level cooking is not recommended.
■ For best results, do not place popcorn bags on the grid.
■ The grid is designed specifically for this oven. For best cooking
results, do not attempt to use any other grid in this oven.
Coated Crisper Pan and Handle
The crisper pan, with its nonstick surface and detachable handle,
has been specifically designed for microwave use and is ideal for
pan-frying (pan-browning) foods in the microwave oven.
■ The crisper pan will become hot. Always use the handle and
oven mitts or pot holders when handling. Place gripping end
on the edge of pan, squeeze handle, and lift pan.
■ Do not allow the crisper pan or handle to touch the inside
cavity walls, ceiling, or floor.
■ Use the turntable as a support for the crisper pan.
■ Do not place hot crisper pan on heat-sensitive surfaces.
Damage may occur.
■ To avoid damage to the microwave oven, do not use another
metal object with the crisper pan.
■ The crisper pan is designed specifically for this oven. Do not
use it in any other oven.
■ Use only wooden or plastic cooking utensils to help avoid
scratches.
3
Microwave Oven Control
This manual covers several models. Your model may have some or all of the items listed. Refer to this manual or the Frequently Asked
Questions (FAQs) section of our website at www.jennair.com for more detailed instructions. In Canada, refer to the Customer Service
section at www.jennair.ca.
The microwave oven’s controls are accessed through its control panel and interactive touch display.
NOTE: Due to the sensitivity of the control panel, we have provided special instructions for cleaning the panel as well as the touch panel.
See “General Cleaning” section in the Owner’s Manual for cleaning instructions.
Combination Oven Models
A. Power
B. Microwave cancel
C. Add 30 Sec.
D. Microwave
E. Display
F. Lower oven
G. Oven light
H. Oven cancel
I. Clean
Touch Panel
The touch panel houses the control menu and function controls.
The touch pads are very sensitive and require only a light touch to
activate.
For more information about the individual controls, see their
respective sections in this manual.
Welcome Guide
This appears on your display the first time the microwave is
powered up. The Welcome Guide allows you to set up your new
microwave oven.
After every selection, a tone will sound.
1. A new welcome screen will appear, please read it and touch
NEXT.
2. Select your language.
3. Select the clock by scrolling to the correct time in the hours
and minutes column. You can then select AM/PM or 24 hour
clock (military time). Touch NEXT.
4. Choose to have daylight savings time AUTO SYNC (turn on),
or DO NOT ADJUST (turn off). Touch NEXT.
5. Enter current date (MM/DD/YYYY) by scrolling to the column
to set the MONTH, DAY, and YEAR. Touch NEXT.
6. Select the units of temperature. You can choose Fahrenheit or
Celsius. Touch NEXT.
7. Select the Clock Theme by scrolling to the desired setting.
Touch NEXT.
NOTE: This is the background for the center touch display.
8. If you selected CLOCK ONLY, touch SAVE to complete the
setup.
or
If you selected a picture for the Clock Theme, select the
desired image and touch SAVE.
Display
When the oven(s) is in use (active mode), the display shows the
oven temperature, heat source(s) and timer if set.
After approximately 2 minutes of inactivity, the display will go into
standby (sleep) mode, and the backlight of the display will dim.
When the oven is in operation, the display will remain active.
During programming, the display shows menus and the
appropriate selections for the respective cooking function.
Display Screen
1. The touch display screen is used to make menu selections,
adjust settings and input commands.
A. Cooking mode
B. Time – minute selection
C. Time – second selection
D. Turntable on/off menu
E. Start cooking cycle
F. Power level selection
Menu selections and input adjustments are made in the center
portion of the screen, and the command inputs (Back, More, Start,
etc.) are made using the bottom buttons. Screen titles and
descriptions are displayed in the top portion of the screen. A light
to medium pressure touch of the fingertip will activate the menu
selection.
