Side 1/36

OWNER'S MANUAL

INDUCTION HOB

Before beginning installation, read these instructions

carefully. This will simplify installation and ensure that the

product is installed correctly and safely. Leave these

instructions near the product after installation for future

reference.

ENGLISH

CBIZ2435B CBIZ2437B

MFL71949901

Rev.07_092524

www.lg.com

TABLE OF CONTENTS

This manual may contain images or

content that may be different from the

model you purchased.

This manual is subject to revision by the

manufacturer.

SAFETY INSTRUCTIONS

READ ALL INSTRUCTIONS BEFORE USE...........................................................3

WARNING............................................................................................................3

CAUTION .............................................................................................................7

CARING FOR THE ENVIRONMENT ....................................................................8

INSTALLATION

Product Overview...............................................................................................9

Installation ........................................................................................................10

OPERATION

Introduction to Induction Cooking ................................................................14

Cookware ..........................................................................................................14

Using the Hob Elements..................................................................................16

SMART FUNCTIONS

LG ThinQ Application.......................................................................................23

MAINTENANCE

Care and Cleaning............................................................................................26

TROUBLESHOOTING

Before Calling for Service................................................................................28

APPENDIX

Product Fiche....................................................................................................32

SAFETY INSTRUCTIONS

ENGLISH

SAFETY INSTRUCTIONS

READ ALL INSTRUCTIONS BEFORE USE

The following safety guidelines are intended to prevent unforeseen

risks or damage from unsafe or incorrect operation of the appliance.

The guidelines are separated into ‘

WARNING

’ and ‘

CAUTION

’ as

described below.

Safety Messages

WARNING

• To reduce the risk of explosion, fire, death, electric shock, injury or

scalding to persons when using this product, follow basic

precautions, including the following:

Installation

• Disconnect the appliance from the mains electricity supply before

carrying out any work or maintenance on it.

• Connection to a good earth wiring system is essential and

mandatory.

This symbol is displayed to indicate matters and operations

that can cause risk. Read the part with this symbol carefully

and follow the instructions in order to avoid risk.

WARNING

This indicates that the failure to follow the instructions can

cause serious injury or death.

CAUTION

This indicates that the failure to follow the instructions can

cause the minor injury or damage to the product.

SAFETY INSTRUCTIONS

• Alterations to the domestic wiring system must only be made by a

qualified electrician.

• In order to avoid a hazard, this appliance must be installed according

to these instructions for installation.

• This appliance is to be properly installed and earthed only by a

suitably qualified person.

• This appliance should be connected to a circuit which incorporates an

isolating switch providing full disconnection from the power supply.

• Failure to install the appliance correctly could invalidate any warranty

or liability claims.

• If the supply cord is damaged, it must be replaced by the

manufacturer, its service agent or similarly qualified persons in order

to avoid a hazard.

• The appliance must not be installed behind a decorative door or

cover in order to avoid overheating.

• Do not repair or replace any part of the appliance. All servicing should

be done only by a qualified technician to avoid the risk of personal

injury and damage to the appliance.

• Never modify or alter the construction of an appliance such as

removal of panels, wire covers or any other permanent part of the

product.

Operation

• Do not cook on a broken or cracked hob. If the hob surface should

break or crack, switch the appliance off immediately at the mains

power supply (wall switch) and contact a qualified technician.

• Switch the hob off at the wall before cleaning or maintenance.

• This appliance complies with electromagnetic safety standards.

However, persons with cardiac pacemakers or other electrical

implants (such as insulin pumps) must consult with their doctor or

implant manufacturer before using this appliance to make sure that

their implants will not be affected by the electromagnetic field.

• During use, accessible parts of this appliance will become hot enough

to cause burns.

SAFETY INSTRUCTIONS

ENGLISH

• Do not let your body, clothing or any item other than suitable

cookware contact the glass until the surface is cool.

• Metallic objects such as knives, forks, spoons and lids should not be

placed on the hob surface since they can get hot.

• Keep children away.

• Handles of saucepans may be hot to touch. Check saucepan handles

do not overhang other cooking zones that are on. Keep handles out

of reach of children.

• Never leave the appliance unattended when in use. Boilover causes

smoking and greasy spillovers that may ignite.

• Never leave any objects or utensils on the appliance.

• Care should be taken to avoid touching heating elements.

• Never use your appliance for warming or heating the room.

• After use, always turn off the cooking zones and the hob as described

in this manual (i.e. by using the control panel). Do not rely on the pan

detection feature to turn off the cooking zones when you remove the

pans.

• Children should be supervised to ensure that they do not play with

the appliance.

• Children or persons with a disability which limits their ability to use

the appliance should have a responsible and competent person to

instruct them in its use. The instructor should be satisfied that they

can use the appliance without danger to themselves or their

surroundings.

• Do not store items of interest to children in cabinets above the

appliance. Children climbing on the hob could be seriously injured.

• Do not leave children alone or unattended in the area where the

appliance is in use.

• This appliance is not intended for use by persons (including children)

with reduced physical, sensory or mental capabilities, or lack of

experience and knowledge, unless they have been given supervision

or instruction concerning use of the appliance by a person

responsible for their safety.

SAFETY INSTRUCTIONS

• Children less than 8 years of age shall be kept away unless

continuously supervised.

• Keep the appliance and its cord out of reach of children less than 8

years.

• Keep pets away from the product to avoid risk of fire or burns. Do not

allow pets to climb on the product even when it is not in operation.

• No combustible material or products should be placed on this

appliance at any time.

• If the surface is cracked, switch off the appliance to avoid the

possibility of electric shock. Do not reuse your hob until the glass

surface has been changed by technical specialist.

• The appliance and its accessible parts become hot during use.

• Danger of fire: Do not store items on the cooking surfaces.

• Never keep any combustible items or aerosol cans in a drawer

located under the hob.

• Unattended cooking on a hob with fat or oil can be dangerous and

may result in fire. NEVER try to extinguish a fire with water, but switch

off the appliance and then cover flame e.g. with a lid or a fire blanket.

• Use only hob guards designed by the manufacturer of the cooking

appliance or indicated by the manufacturer of the appliance in the

instructions for use as suitable or hob guards incorporated in the

appliance. The use of inappropriate guards can cause accidents.

Maintenance

• Cleaning and user maintenance shall not be made by children

without supervision.

• Do not repair or replace any part of the appliance unless specifically

recommended in the manual. All other servicing should be done by a

qualified technician.

• If the supply cord is damaged, it must be replaced by the

manufacturer, its service agent or similarly qualified persons in order

to avoid a hazard.

SAFETY INSTRUCTIONS

ENGLISH

CAUTION

• To reduce the risk of injury to persons, malfunction, or damage to the

product or property when using the appliance, follow basic safety

precautions, including the following:

Installation

• Take care - panel edges are sharp.

• Make this information available to the person responsible for

installing the appliance as it could reduce your installation costs.

• Failure to install the appliance correctly could invalidate any warranty

or liability claims.

Operation

• The razor-sharp blade of a hob scraper is exposed when the safety

cover is retracted. Use with extreme care and always store safely and

out of reach of children.

• Never use your appliance as a work or storage surface.

• Do not place or leave any magnetisable objects (e.g. credit cards,

memory cards) or electronic devices (e.g. computers, MP3 players)

near the appliance, as they may be affected by its electromagnetic

field.

• Do not place or drop heavy objects on your hob. Doing so can cause

the hob surface to crack.

• Do not stand on your hob.

• Do not use pans with jagged edges or drag pans across the glass

surface as this can scratch the glass.

• This appliance is intended to be used in household and similar

domestic applications such as:

- staff kitchen areas in shops, offices and other working

environments

- farm houses

SAFETY INSTRUCTIONS

- by clients in hotels, motels and other residential type environments

- bed and breakfast type environments.

• The appliance is not intended to be operated by means of an external

timer or separate remote-control system. This does not apply if

operation with appliances included in EN 50615 is switched off.

• The cooking process has to be supervised. A short term cooking

process has to be supervised continuously.

Maintenance

• Do not use scourers or any other harsh abrasive cleaning agents to

clean your hob, as these can scratch the glass.

• A steam cleaner is not to be used.

• Do not use a steam cleaner to clean your hob.

CARING FOR THE ENVIRONMENT

Disposal of Your Old Appliance

• This crossed-out wheeled bin symbol indicates that waste

electrical and electronic products (WEEE) should be

disposed of separately from the municipal waste stream.

• Old electrical products can contain hazardous substances

so correct disposal of your old appliance will help prevent

potential negative consequences for the environment and

human health. Your old appliance may contain reusable

parts that could be used to repair other products, and

other valuable materials that can be recycled to conserve

limited resources.

• You can take your appliance either to the shop where you

purchased the product, or contact your local government

waste office for details of your nearest authorised WEEE

collection point. For the most up to date information for

your country, please see www.lg.com/global/recycling.

INSTALLATION

ENGLISH

INSTALLATION

Product Overview

Parts and Features

Accessories

Retainer Brackets (8 ea)

Specifications

CBIZ2437B CBIZ2435B

Max. 2200/3300 W Zone

Max. 2200/3300 W Zone Max. 1400/2000 W Zone

Max. 2200/3300 W Zone

Max. 3300/3700 W Zone

Glass Plate

Control Panel

Model

CBIZ2435B

CBIZ2437B

Cooking Zones 4 zones

INSTALLATION

Dimensions are approximate.

Installation

Dimensions and Clearances

Cut out the work surface according to the sizes

shown in the drawing.

For the purpose of installation and use, a minimum

of 5 cm distance shall be preserved around the

cutout.

Be sure the thickness of the work surface is at least

10 mm. Select heat-resistant and insulated work

surface material to avoid electrical shock and

larger deformation caused by heat radiation from

the hob. Wood and similar fibrous or hygroscopic

material shall not be used as work surface material

unless impregnated. As shown below:

NOTE

• The safety distance between the sides of the hob

and the inner surfaces of the worktop

should

be at least 3 mm.

590 mm

520 mm

50 mm

46 mm

560 mm - 562 mm

480 mm - 482 mm

Min. 50 mm

Min. 3 mm

Seal

Under any circumstances, make sure the hob is

well ventilated and the air inlet and outlet are not

blocked. Ensure the hob is in a good working

situation, as shown below.

NOTE

• The safety distance between the hob and the

cupboard above the hob

should be a

minimum of 500 mm when there is no range

hood fitted. If there is a range hood fitted, then

the safety distance specified by the

manufacturer of the range hood must be

Supply Voltage 220-240 V~ 50/60 Hz

380-415 V 3N~ 50/60

Maximum Connected

Load Power

7400 W

Appliance Dimensions

Width X Depth X

Height (mm)

590 X 520 X 50

Countertop Cutout

Dimensions

Width X Depth (mm)

560 X 480

Model

CBIZ2435B

CBIZ2437B

INSTALLATION

ENGLISH

maintained between the cooktop hob and the

range hood above it.

Oven

Drawer

Min. 500 mm

Min. 15 mm

Min. 20 mm

Air intake

Air exit 5 mm

Min. 10 mm

WARNING

•

Ensuring Adequate Ventilation

Make sure the hob is well ventilated and that air

inlet and outlet are not blocked. In order to avoid

accidentally touching the hot bottom of the hob,

or unexpected electric shock during operation, it

is necessary to fit a wooden insert, fixed by

screws, at a minimum distance of 15 mm from

the bottom of the hob. Follow the requirements

below.

• There are ventilation holes around outside of the

hob. YOU MUST ensure these holes are not

blocked by the worktop when you put the hob

into position.

• The glue, which join the plastic or wooden

material to the furniture has to resist to 150 ℃ to

avoid the unstuck of the paneling.

Min. 15 mm

Max. 5 mmMax. 5 mm

INSTALLATION

WARNING

• The rear wall, adjacent and surrounding surfaces

must therefore be able to withstand a

temperature of 90 ℃.

Installing the Appliance

Before Installing the Hob

• Make sure that the work surface is square and

level, and no structural members interfere with

space requirements. An uneven surface can

cause the hob glass to crack unexpectedly due to

unequal surface pressures.

• Make sure that the work surface is made of a

heat-resistant and insulated material.

• If the hob is installed above an oven, the oven

must have a built-in cooling fan.

• The installation must comply with all clearance

requirements and applicable standards and

regulations.

• Make sure that a suitable isolating switch

providing full disconnection from the mains

power supply is incorporated in the permanent

wiring, mounted and positioned to comply with

local wiring rules and regulations.

• A device must be provided in the electrical

installation that allows the appliance to be

disconnected from the mains at all poles with a

contact opening width of at least 3 mm. Suitable

isolation devices include line protecting cut -

outs, fuses (screw type fuses are to be removed

from the holder), earth leakage trips and

contactors.

• The isolating switch must be easily accessible to

the customer with the hob installed.

• Consult local building authorities and by-laws if

in doubt regarding installation.

• Use heat-resistant and easy-to-clean finishes

(such as ceramic tiles) for the wall surfaces

surrounding the hob.

• The kitchen unit in which the appliance is fitted

must satisfy the stability requirements of DIN

68930.

After Installing the Hob

• Maker sure that the power cord is not accessible

through cupboard doors or drawers.

• Make sure that there is adequate flow of fresh air

from outside the cabinetry to the base of the

hob.

• If the hob is installed above a drawer or

cupboard space, a thermal protection barrier

must be installed below the base of the hob.

• The isolating switch must be easily accessible by

the customer.

Before Locating the Fixing Brackets

• The appliance should be placed on a stable,

smooth surface. Do not apply force onto the

buttons protruding from the hob.

Adjusting the Bracket Position

Fix the hob on the work surface by screwing 2

brackets on the bottom of hob(see picture) after

installation. Adjust the bracket position to suit the

particular work top thickness.

WARNING

• Under any circumstances, make sure that the

brackets cannot come into contact with the inner

surfaces of the worktop after installation.

CAUTION

• The hob must be installed by qualified

technicians. We have technicians available for

such service. Never carry out the installation by

yourself.

• The hob must not be installed directly above a

dishwasher, fridge, freezer, washing machine or

clothes dryer, as the humidity may damage the

hob.

• The hob shall be installed so that better heat

radiation can be ensured to enhance its

reliability.

INSTALLATION

ENGLISH

• The wall and induced heating zone above the

installation surface shall withstand heat.

Connecting the hob to the mains

power supply

This hob must be connected to the mains power

supply only by a qualified electrician.

Before connecting the hob to the mains power

supply, it is the Electricians responsibility to check

that:

• The domestic wiring system is suitable for the

power drawn by the hob.

• The voltage corresponds to the value given in

the rating plate.

• The power supply cable sections can withstand

the load specified on the rating plate.

Connect the hob to the mains power supply. Do not

use adapters, reducers, or branching devices, as

they can cause overheating and fire.

The power supply cable must not touch any hot

parts and must be positioned so that its

temperature will not exceed 75 ℃ at any point.

Check with an electrician whether the domestic

wiring system is suitable without alterations.

Any alterations must only be made by a qualified

electrician.

Yellow / Green

Blue

Brown

Black

If the total number of heating units of the

appliance you choose is not less than 4, the

appliance can be connected directly to the mains

by single-phase electric connection, as shown

below.

Yellow / Green

Blue

Brown

Black

• If the power cord is damaged or needs to be

replaced, contact an LG Electronics Customer

Information Centre.

• The installer must ensure that the correct

electrical connection has been made and that it

is compliant with safety regulations.

• If the appliance is being connected directly to the

mains an omnipolar circuit-breaker must be

installed with a minimum opening of 3 mm

between contacts.

• The power cord must not be bent or

compressed.

• The power cord must be checked regularly and

replaced by authorised technicians only.

• Once the hob is connected to the mains supply,

check that all cooking zones are ready for use by

briefly switching each on in turn at the maximum

setting with suitable cookware.

WARNING

• Make sure that the bottom surface and the

power cord of the hob do not come into contact.

OPERATION

Introduction to Induction

Cooking

CAUTION

• People with a heart pace maker should consult

with their doctor before using this unit.

How Induction Cooking Works

Induction cooking is a safe, advanced, efficient and

economical cooking technology. It works by

electromagnetic vibrations generating heat

directly in the cookware, rather than indirectly

through heating the glass surface. The glass

becomes hot only because the pan eventually

warms it up.

Iron Pot

Magnetic Circuit

Ceramic Glass Plate

Induction Coil

Induced Currents

Before Using your Induction Hob

• Read this guide, taking special note of the

SAFETY INSTRUCTIONS chapter.

• Remove any protective film that may still be on

your induction hob.

Cookware

Choosing the Right Cookware

NOTE

• When purchasing cookware for use on the

induction hob, look for cookware identified by

the manufacturer as "induction ready" or

"induction capable", or that is marked by the

manufacturer as specifically designed for

induction cooking.

• The base material of the cookware must be

magnetic for the cooking elements to activate.

Use a magnet to check if the cookware base

material is suitable. If the magnet sticks to the

bottom of the cookware, the cookware can be

used for induction cooking.

• Cookware made from the following materials is

not suitable: pure stainless steel, aluminium or

copper without a magnetic base, glass, wood,

porcelain, ceramic, and earthenware.

• Do not use cookware with jagged edges or a

curved base.

• Make sure that the base of your cookware is

smooth, sits flat against the glass, and is the

same size as the cooking zone. Use cookware

whose diameter is as large as the graphic of the

zone selected. Using a pot slightly wider will

ensure that energy will be used with maximum

efficiency. If you use a pot smaller than the

cooking zone, efficiency could be less than

expected. Pot smaller than 120 mm could be

OPERATION

ENGLISH

undetected by the hob. Always centre your

cookware on the cooking zone.

Cookware placement in flexible zones

• Always lift cookware directly off the Induction

hob.

Detection of Small Articles

When an unsuitable size or non-magnetic

cookware (e.g. aluminium), or some other small

item (e.g. knife, fork, key) has been left on the hob,

the hob automatically goes to standby after 1

minute.

OPERATION

Using the Hob Elements

Using the Control Panel

Control Panel

CBIZ2437B

CBIZ2435B

ON/OFF

Button

Flexible Zone

Button

Power Control

Timer

Button

Pause

Button

Keylock

Button

Hood Connection Button

Wi-Fi Connection Button

Power Setting Display

+/-

Buttons

Timer

Indicator

Timer

display

• To operate the buttons, press the desired button

with the ball of your finger.

• You will hear a beep each time when you press.

• Make sure the buttons are always clean, dry, and

that there is no object (e.g. a utensil or a cloth)

covering them. Even a thin film of water may

make the buttons difficult to operate.

Using the Cooking Zones

Press the

ON/OFF

button for one second. After

power on, the buzzer beeps once, all displays

show “0” or “00”, indicating that the induction

hob has entered the state of standby mode.

OPERATION

ENGLISH

Place suitable cookware on the cooking zone

that you wish to use.

• Make sure the bottom of the cookware and

the surface of the cooking zone are clean

and dry.

Press and slide the power control, the power

setting display corresponding to the button

will flash.

Select a power setting by pressing the power

control.

• If you don’t choose a power setting within 1

minute, the induction hob will automatically

switch off. You will need to start again at step

• You can modify the power setting at any

time during cooking by repeating of this

step.

NOTE

• If the display flashes "u" with the power setting,

this means that:

- you have not placed cookware on the correct

cooking zone or,

- the cookware you’re using is not suitable for

induction cooking or,

- the cookware is too small or not properly

centered on the cooking zone.

• No heating takes place unless there is suitable

cookware on the cooking zone.

• The display will automatically turn off after 1

minute if no suitable cookware is placed on it.

• It is normal for the hob to make a gentle buzzing

or whirring sound when in the cooking mode.

• A fan noise is also normal to be heard when the

Hob's electronics become hot during and

cooking.

Power Settings

The settings below are guidelines only. The exact

setting will depend on several factors, including

your cookware and the amount you are cooking.

Experiment with the induction hob to find the

settings that best suit you.

Finish Cooking

Press the power control that you wish to switch

off. Turn the cooking zone off by pressing or

Power

setting

Suitability

1 - 2 • Delicate warming for small

amounts of food

• Melting chocolate, butter, and

foods that burn quickly

• Gentle simmering

• Slow warming

3 - 5 • Reheating

• Rapid simmering

• Cooking rice

6 - 11 • Pancakes

12 - 14 • Sautéing

• Cooking pasta

15 • Stir-frying

• Searing

• Bringing soup to the boil

• Boiling water

B • Bringing soup to the boil quickly

• Boiling water quickly

OPERATION

sliding the slider to ”0”. Make sure the display

shows “0”.

Turn the whole hob off by pressing the

ON/

OFF

button.

CAUTION

•

Beware of hot surfaces

“H” and “h” will show which cooking zone is too

hot to touch in 2 steps. It will disappear when the

surface has cooled down to a safe temperature.

It can also be used as an energy saving function

if you want to heat further cookware, use the

hob that is still hot.

- "H": Very hot residual heat (heat retention)

- "h": residual heat

Using the Boost Function

Activate the boost function

With the boost function, large quantities of water

can be heated more quickly than with the

corresponding power setting 15.

WARNING

• Never use the boost function to preheat empty

cookware or to heat oil, butter or lard. The

cookware may be damaged and the fat or grease

may catch fire if overheated.

NOTE

• The function can work in any cooking zone.

• If the previous selected setting was level 0, after

automatically switch off of the boost function

power setting 15 will set.

• Under certain conditions, the boost function

may automatically switch off to protect the

electronic components inside the hob. The

power setting returns to its the previous

selected.

• The cooking zones have a maximum power

available to them. If this power range is

exceeded by switching on the boost function, the

power setting of cooking zone is automatically

reduced.

Press the power control.

Press or slide the "B" button. Make sure the

display shows “b”.

Cancel the boost function

Press the power control that you wish to cancel

the boost function and set the desired power

setting.

• The function can work in any cooking zone.

• If the previous selected setting was level 0,

after automatically switch off of the boost

function power setting 15 will set.

OPERATION

ENGLISH

Using the Flexible Zone

NOTE

• If one of the two cooking zones in the flexible

zone is on, cancel the cooking zone operation

and use the flexible function.

• This zone can be used as a single big zone or as

two independent zones.

• The flexible zone is made up of two independent

inductors that can be controlled separately.

When working as a single big zone, the cooking

zone that is not covered by cookware is

automatically switched off after one minute.

• To ensure correct cookware detection and a

even heat distribution, the cookware should be

correctly placed:

- In the front or rear area of the flexible zone

when the cookware is smaller than 22 cm

- Anywhere with bigger cookware

Single big zone

To activate the flexible zone as a single big zone,

simply press the Flexible Zone button.

The power setting works as any other normal zone.

If the cookware is moved from the front to the rear

area of the zone (or vice versa), the flexible zone

automatically detects the new position, keeping

the same power.

To add further cookware, press the dedicated

buttons again, in order to detect the cookware.

Two independent zones

To use the flexible zone as two separate zones with

different power settings, press the Flexible Zone

button to deactivate.

Using the Timer

• You can set it to turn one or more cooking zones

off after the set time is up. The maximum setting

time is 99 minutes.

Setting the timer to turn one or more cooking

zones off automatically

If the cooking zone is in use, press the

Timer

button repeatedly until the indicator of a

necessary cooking zone comes on. The timer

indicator will start flashing and "00" will show

in the timer display.

Set the time by pressing the

+/-

buttons.

• Hint: Press the

+/-

buttons once to decrease

or increase by 1 minute.

• Press and hold the

+/-

buttons to decrease or

increase by 10 minutes.

When the timer is set, it will begin to count

down immediately.

OPERATION

When cooking timer expires, the

corresponding cooking zone will be switched

off automatically.

NOTE

• Other cooking zones will keep operating if they

were turned on previously.

To see the remaining time

Press the

Timer

button repeatedly until the

indicator of the necessary cooking zone comes

on.

Modifying the Timer

Press the

Timer

button repeatedly until the

indicator of the necessary cooking zone comes

on.

Set the time by pressing the

+/-

buttons.

Canceling the Timer

Press the

Timer

button repeatedly until the

indicator of a necessary cooking zone comes

on.

Press and hold the “ - ” button on

Timer

, the

timer decreases to “00” and the timer is

cancelled.

Locking the Buttons

• You can lock the buttons to prevent unintended

use (for example children accidentally turning

the cooking zones on).

• When the buttons are locked, all buttons are

disabled.

To lock the buttons

Press the

Keylock

button for 3 seconds.

The timer display shows "Lo" and the timing

time flashes alternately

To unlock the buttons

Press the

Keylock

button for 3 seconds.

NOTE

• When the hob is in the lock mode, all the buttons

are disabled except the

ON/OFF

button. You can

always turn the induction hob off with the

ON/

OFF

button in an emergency, but you will need

to unlock the hob before the next operation.

Using the Pause Mode

• The pause function reduces the power setting of

a cooking zone to level 1 and maintains it at that

level until deactivated. This function can be used

to briefly interrupt and then continue the

cooking process.

• When entering the pause mode, all the buttons

except the

ON/OFF

button are disabled.

To enter pause mode

Press the

Pause

button.

OPERATION

ENGLISH

The timer display and the working power

setting display will display "||"

To exit pause mode

Press the

Pause

button to return the cooking

zone to the previous power setting.

NOTE

• When the hob is in the pause mode, all the

buttons are disabled, except the

ON/OFF

button. You can always turn the induction hob

off with the

ON/OFF

button.

Default Working Times

Auto shut down is a safety protection function for

your induction hob. It shuts down automatically if

ever you forget to turn off your cooking. The

default working times for various power settings

are shown in the below table:

When the cookware is removed, the induction hob

will stop heating immediately and the hob

automatically switches off after 1 minute.

Special Function

Wi-Fi connection

• Press the

Wi-Fi

connection button for 3 seconds,

the

Wi-Fi

LED turns ON.

Wi-Fi

function is ON.

Follow the instructions in the

LG ThinQ

application on your smartphone for using the

Wi-Fi

function.

Hood connection

• This product features a Wi-Fi device that you can

use to connect the hob to LG hoods. Through the

Wi-Fi

connection, you can use the hood

connection on the

LG ThinQ

application.

Activate

Wi-Fi

connection. Press the hood

connection button, the hood LED is ON. Hood

connection is ON.

NOTE

• Hood connection will not work if there are any

Wi-Fi connectivity issues or faults, connection

problems or any faults, malfunctions, or errors

caused by network connection.

Power Limit Mode

Enables the total power of the hob to be limited, if

necessary, based on the conditions of your

electrical installation.

Press the

Keylock

button for 3 seconds in

power off to enter the lock mode.

Press the

Timer

button for 3 seconds and hear

the buzzer ring.

Power setting

Default working

times (hour)

1-3 6

4-6 5

7-9 4

10-15 1.5

OPERATION

Press the lower left boost button to enter the

power limit mode.

Press the

keylock

button repeatedly to select

maximum connected load power.

Press the

ON/OFF

button to confirm the

current power of the hob and exit the power

limit mode.

Display Maximum power

25 2500 W

35 3500 W

45 4500 W

60 6000 W

74 7400 W

SMART FUNCTIONS

ENGLISH

SMART FUNCTIONS

LG ThinQ Application

This feature is only available on models with Wi-Fi.

The

LG ThinQ

application allows you to

communicate with the appliance using a

smartphone.

LG ThinQ Application Features

Communicate with the appliance from a

smartphone using the convenient smart features.

Hood pairing

Allows you to choose which hood to work with your

induction.

Monitoring

This function helps you check the operation status

of the product, lock status, heat strength for each

burner, and timer.

Usage time monitoring

This function helps you check the total amount of

time used by each burner today, weekly, and

monthly.

NOTE

• If you change your wireless router, Internet

service provider, or password, delete the

registered appliance from the

LG ThinQ

application and register it again.

• To disconnect the appliance from the

Wi-Fi

network, delete the appliance from the list of

connected products in the

LG ThinQ

application.

• The application is subject to change for

appliance improvement purposes without notice

to users.

• Functions may vary by model.

Installing LG ThinQ Application

and Connecting an LG

Appliance

Models with QR Code

Scan the QR code attached to the product using the

camera or a QR code reader application on your

smartphone.

Models without QR Code

Search for and install the

LG ThinQ

application

from the Google Play Store or Apple App Store

on a smartphone.

Run the

LG ThinQ

application and sign in with

your existing account or create an LG account

to sign in.

Touch the add (

) button on the

LG ThinQ

application to connect your LG appliance.

Follow the instructions in the application to

complete the process.

NOTE

• To verify the Wi-Fi connection, check that the Wi-

Fi indicator on the control panel is lit.

• The appliance supports 2.4 GHz Wi-Fi networks

only. To check your network frequency, contact

your Internet service provider or refer to your

wireless router manual.

SMART FUNCTIONS

NOTE

•

LG ThinQ

is not responsible for any network

connection problems or any faults,

malfunctions, or errors caused by network

connection.

• The surrounding wireless environment can

make the wireless network service run slowly.

• If the distance between the appliance and the

wireless router is too far, the signal strength

becomes weak. It may take a long time to

connect or installation may fail.

• If the appliance is having trouble connecting to

the Wi-Fi network, it may be too far from the

router. Purchase a Wi-Fi repeater (range

extender) to improve the Wi-Fi signal strength.

• The network connection may not work properly

depending on the Internet service provider.

• The Wi-Fi connection may not connect or may be

interrupted because of the home network

environment.

• The appliance cannot be connected due to

problems with the wireless signal transmission.

Unplug the appliance and wait about a minute

before trying again.

• If the firewall on your wireless router is enabled,

disable the firewall or add an exception to it.

• The wireless network name (SSID) should be a

combination of English letters and numbers. (Do

not use special characters.)

• Smartphone user interface (UI) may vary

depending on the mobile operating system (OS)

and the manufacturer.

• If the security protocol of the router is set to

WEP

, you may fail to set up the network. Please

change it to other security protocols (

WPA2

recommended) and connect the product again.

• To disable the Wi-Fi function, press and hold the

Wi-Fi

connection button for 3 seconds. The Wi-Fi

indicator will be turned off.

• To reconnect the appliance or add another user,

press and hold the

Wi-Fi

connection button for 3

seconds to temporarily turn it off. Run the

ThinQ

application and follow the instructions in

the application to connect the appliance.

Radio Equipment Specifications

Wireless function S/W version: V 1.0

For consideration of the user, this device should be

installed and operated with a minimum distance of

3 cm between the device and the body.

Declaration of Conformity

Hereby, LG Electronics declares that the radio

equipment type Hob is in compliance with Directive

2014/53/EU. The full text of the EU declaration of

conformity is available at the following internet

address:

http://www.lg.com/global/support/cedoc/cedoc#

Open Source Software Notice

Information

To obtain the source code that is contained in this

product, under GPL, LGPL, MPL, and other open

source licenses that have the obligation to disclose

source code, and to access all referred license

terms, copyright notices and other relevant

documents, please visit https://

opensource.lge.com.

LG Electronics will also provide open source code to

you on CD-ROM for a charge covering the cost of

performing such distribution (such as the cost of

media, shipping, and handling) upon email request

to opensource@lge.com.

Module Name LCWB-001

Wireless LAN

Frequency Range

2412 MHz - 2472 MHz

Wireless LAN Output

Power (Max)

18.14 dBm

Bluetooth Frequency

Range

2402 MHz - 2480 MHz

Bluetooth Output

Power (Max)

7.03 dBm

SMART FUNCTIONS

ENGLISH

This offer is valid to anyone in receipt of this

information for a period of three years after our

last shipment of this product.

MAINTENANCE

Care and Cleaning

Cleaning the Appliance

CAUTION

• A steam cleaner is not to be used.

Everyday Soiling on Glass

(Fingerprints, Marks, Stains Left by

Food or Non-sugary Spillovers on

the Glass)

Switch the power to the hob off.

Apply a hob cleaner while the glass is still warm

(but not hot!).

Rinse and wipe dry with a clean cloth or paper

towel.

NOTE

• When the power to the hob is switched off, there

will be no 'hot surface' indication but the cooking

zone may still be hot! Take extreme care.

• Heavy-duty scourers, some nylon scourers and

harsh/abrasive cleaning agents may scratch the

glass. Always read the label to check if your

cleaner or scourer is suitable.

• Never leave cleaning residue on the hob: the

glass may become stained.

Boilovers, Melts, and Hot Sugary

Spills on the Glass

Remove these immediately with a fish slice, palette

knife or razor blade scraper suitable for hobs, but

beware of hot cooking zone surfaces:

Switch the power to the hob off at the

mechanical isolation switch.

Hold the blade or utensil at a 30° angle and

slowly scrape the soiling or spill to a cool area

of the hob. Using the blade incorrectly or

improperly can scratch the hob's surface.

Clean the soiling or spill up with a dish cloth or

paper towel.

Follow steps 2 to 3 for ‘Everyday Soiling on

Glass’ above.

NOTE

• Remove stains left by melts and sugary food or

spillovers as soon as possible. If left to cool on

the glass, they may be difficult to remove or even

permanently damage the glass surface.

• Cut hazard: when the safety cover of a cleaning

blade is retracted, the blade in a scraper is razor-

sharp. Use with extreme care and always store

safely and out of reach of children.

Spillovers on the Control Panel

Switch the power to the hob off.

Soak up the spill.

Wipe the control panel area with a clean damp

sponge or cloth.

Wipe the area completely dry with a paper

towel.

NOTE

• The hob may beep and turn itself off, and the

control panel may not function while there is

liquid on them. Make sure that you wipe the

MAINTENANCE

ENGLISH

control panel area dry before turning the hob

back on.

TROUBLESHOOTING

Before Calling for Service

Repairs should be performed by a licensed technician only. Improper repair may result in considerable

danger to you and others. However, some minor problems can be resolved as in the table below:

If a problem is not solved, please contact an LG Electronics Customer Information Centre.

Parts and Features

Symptoms Possible Cause & Solution

The induction hob

cannot be turned on.

No power

• Make sure the induction hob is connected to the power supply and that it

is switched on. Check whether there is a power outage in your home or

area. If you’ve checked everything and the problem persists, call a qualified

technician.

The control panel is

unresponsive.

The buttons are locked.

• Unlock the buttons. See section 'Locking the Buttons' for instructions.

The control panel is

difficult to operate.

There may be a slight film of water over the buttons or you may be using

the tip of your finger when touching the buttons.

• Make sure the control panel area is dry and use the ball of your finger

when touching the buttons.

The glass is becoming

scratched and marked.

Rough-edged cookware

• Use cookware with flat and smooth bases. See ‘Choosing the Right

Cookware’.

Unsuitable, abrasive scourer or cleaning products being used.

• See ‘MAINTENANCE’.

Some cookware make

crackling or clicking

noises.

This may be caused by the construction of your cookware (layers of

different metals vibrating differently).

• This is normal for cookware and does not indicate a fault.

The induction hob

makes a low humming

noise when used on a

high power setting.

This is caused by the technology of induction cooking.

• This is normal, but the noise should quieten down or disappear completely

when you decrease the power setting.

Fan noise coming from

the induction hob.

A cooling fan built into your induction hob has come on to prevent the

electronics from overheating. It may continue to run even after you’ve

turned the induction hob off.

• This is normal and needs no action. Do not switch the power to the

induction hob off at the wall while the fan is running.

Cookware do not

become hot and error

codes appear in the

display.

The induction hob cannot detect the cookware because it is not suitable

for induction cooking.

• Use cookware suitable for induction cooking. See section ‘Choosing the

Right Cookware’.

TROUBLESHOOTING

ENGLISH

Error Codes (Auto-Recovery)

Cookware do not

become hot and "u"

appears in the display.

The induction hob cannot detect the cookware because it is too small for

the cooking zone or not properly centred on it.

• Centre the cookware and make sure that its base matches the size of the

cooking zone.

The induction hob or a

cooking zone has

turned itself off

unexpectedly, a tone

sounds and an error

code is displayed

(typically alternating

with one or two digits

in the cooking timer

display).

Technical fault

• Please note down the error letters and numbers, switch the power to the

induction hob off at the wall, and contact a qualified technician.

The LED does not come

on when unit is

plugged in.

No power supplied.

• Check to see if plug is secured tightly in outlet and that outlet is working.

The cooking mode

indicator comes on,

but heating does not

start.

High temperature of the hob.

• Ambient temperature may be too high. Air Intake or air vent may be

blocked.

There is something wrong with the fan.

• Check whether the fan runs smoothly.

Heating stops

suddenly during

operation and the

display flashes “u”.

Cookware type is wrong.

Cookware diameter is too small.

• Use a suitable cookware. (refer to the instruction manual.)

Cooker has overheated.

• Unit is overheated. Wait for temperature to return to normal. Press the

ON/OFF

button to restart unit.

The LED on the display

is blinking and not

working.

This is a temporary power failure.

• Cut off the power through the circuit breaker. After a while, reconnect the

power. If the problem persists, call for service.

Symptoms Possible Cause & Solution

C1 High temperature of ceramic plate sensor

• This is normal. Problems can be resolved as follows.

• Wait for the temperature of the ceramic plate return to normal. Press the

ON/OFF

button to restart unit. Check whether the fan runs smoothly; if

not, call for service.

Symptoms Possible Cause & Solution

TROUBLESHOOTING

Error Codes (No Auto-Recovery)

C2 High temperature of IGBT. (1#)

• This is normal. Problems can be resolved as follows.

• Wait for the temperature of the IGBT return to normal. Press the

ON/OFF

button to restart unit. Check whether the fan runs smoothly; if not, call for

service.

EL Supply voltage is below the rated voltage.

• This is normal. Problems can be resolved as follows.

• Wait for the temperature of the ceramic plate return to normal. Press the

ON/OFF

button to restart unit. Please inspect whether power supply is

normal. Power on after the power supply is normal.

EH Supply voltage is above the rated voltage.

• This is normal. Problems can be resolved as follows.

• Please inspect whether power supply is normal. Power on after the power

supply is normal. Press the

ON/OFF

button to restart unit.

EF All cooking zones will switch themselves off if liquid boils over or

something (pan or pot) is on the control panel.

• This is normal. Problems can be resolved as follows.

• The automatic shutoff will also be activated if you place a damp cloth on

the control panel. In both of these instances, the appliance will need to be

switched on again using the

ON/OFF

button after the liquid or the cloth

has been removed.

Symptoms Possible Cause & Solution

E1 Ceramic plate temperature sensor failure (open circuit)

• Call for service.

E2 Ceramic plate temperature sensor failure (short circuit)

• Call for service.

E7 Ceramic plate temperature sensor failure (invalid)

• Call for service.

E3 Temperature sensor of the IGBT failure (open circuit)

• Call for service.

E4 Temperature sensor of the IGBT failure (short circuit)

• Call for service.

F5 The DC Motor fails to operate because of problems with the PCB or

wiring, or electrical disturbance on the motor blade.

• Call for service.

Symptoms Possible Cause & Solution

TROUBLESHOOTING

ENGLISH

Wi-Fi

EU The connection between the display board and the main board is fail.

• Call for service.

Symptoms Possible Cause & Solution

Your home appliance

and smartphone are

not connected to the

Wi-Fi network.

The password for the Wi-Fi that you are trying to connect to is incorrect.

• Find the Wi-Fi network connected to your smartphone and remove it, then

LG ThinQ

Mobile data for your smartphone is turned on.

• Turn off the

Mobile data

of your smartphone and register the appliance

using the Wi-Fi network.

The wireless network name (SSID) is set incorrectly.

• The wireless network name (SSID) should be a combination of English

letters and numbers. (Do not use special characters.)

The router frequency is not 2.4 GHz.

• Only a 2.4 GHz router frequency is supported. Set the wireless router to 2.4

GHz and connect the appliance to the wireless router. To check the router

frequency, check with your Internet service provider or the router

manufacturer.

The distance between the appliance and the router is too far.

• If the distance between the appliance and the router is too far, the signal

may be weak and the connection may not be configured correctly. Move

the location of the router so that it is closer to the appliance.

Symptoms Possible Cause & Solution

APPENDIX

Product Fiche

Product Fiche_COMMISSION DELEGATED REGULATION (EU) No 66/2014, Applicable Standard EN

60350-2

COMMISSION REGULATION (EU) No 801/2013 and (EU) No 1275/2008 Applicable Standard EN 50564

Trademark LG

Model identifier CBIZ2437B CBIZ2435B

Type of hob Built-in hob

Heating technology induction cooking zones

Number of cooking zones and/

or areas

4 cooking zones

For circular cooking zones or

area: diameter of useful surface

area per electric heated cooking

zone, rounded to the nearest 5

For non-circular cooking zones

or areas: length and width of

useful surface area per electric

heated cooking zone or area,

rounded to the nearest 5 mm

Front Left 18.5 cm

Rear Left 18.5 cm

Front Right 18.5 cm

Rear Right 18.5 cm

Front Left 18.5 cm

Rear Left 18.5 cm

Front Right 20.5 cm

Rear Right 14.5 cm

Energy consumption per

cooking zone or area calculated

per kg (EC

electric cooking

)

Front Left 192.0 Wh/kg

Rear Left 192.0 Wh/kg

Front Right 192.0 Wh/kg

Rear Right 192.0 Wh/kg

Front Left 191.0 Wh/kg

Rear Left 191.0 Wh/kg

Front Right 188.0 Wh/kg

Rear Right 190.0 Wh/k

Energy consumption for the hob

calculated per kg (EC

electric hob

)

192.0 Wh/kg 190.0 Wh/kg

Standby power consumption 0.5 W

The period of time after which the power management function, or

a similar function, switches the equipment automatically into

standby and/or off mode and/or the condition providing networked

standby

10 min.

Memo

Produkspesifikasjoner

Merke:	LG
Kategori:	Stekeovn
Modell:	CBIZ2437B

Trenger du hjelp?

Hvis du trenger hjelp med LG CBIZ2437B still et spørsmål nedenfor, og andre brukere vil svare deg

Ditt navn*

Din e-post*

Skriv spørsmålet ditt her

Stekeovn LG Manualer

LG CBIS3018BE Bruksanvisning

11 Mars 2025

LG WCES6428 Bruksanvisning

6 Februar 2025

LG Studio LSCG307BD Bruksanvisning

2 Februar 2025

LG LSCE365STE Bruksanvisning

20 Januar 2025

LG LCE3010SBE Bruksanvisning

20 Januar 2025

LG MH6387TL Bruksanvisning

17 Januar 2025

LG MH6387PRL Bruksanvisning

17 Januar 2025

LG MH6387B Bruksanvisning

17 Januar 2025

LG MH6388P Bruksanvisning

17 Januar 2025

LG GC-W141FTH Bruksanvisning

17 Januar 2025

Stekeovn Manualer

Nyeste Stekeovn Manualer

Ignis AKH 2012 IX Bruksanvisning

10 April 2025

AEG T27PIQ4S0 Bruksanvisning

10 April 2025

Korona 57157 Bruksanvisning

9 April 2025

Constructa CB10453 Bruksanvisning

9 April 2025

Instant Omni Plus Toaster Bruksanvisning

9 April 2025

Miele CSAD 1400 Bruksanvisning

9 April 2025

Bora Classic 2.0 CKG Bruksanvisning

9 April 2025

Hotpoint HTX8017DCF2 Bruksanvisning

9 April 2025

Rangemaster RMB60HPNGF Bruksanvisning

9 April 2025

Breville the Quick Cook Dual Zone LIC700 Bruksanvisning

8 April 2025
