Side 1/2
LG STUDIO
HOM IE APPL ANCES
KEY FEATURES
FlushFit™ Design
1-Hour wash & Dry
Quadwash Pro
Dynamic Heat Dry with AutoVent™ Dry
BlastZone Bottle Wash™
PRODUCT FEAT URES
SDNTHS72S
Top Control Wi-Fi Enabled Dishwasher
© 2024 LG Electronics USA, Inc. All rights reserved. "LG Life’s Good" is a registered trademark of LG Corp. All other product and brand names are trademarks or registered trademarks of their respective owners. Design, features and specifications are subject to
change without notice. Non-metric weights and measurements are approximate. Some features may require Internet access. Content and services may vary by product and are subject to change without notice. 6/18/25
CAPACITY
Total Place Setting 16 Place Setting
Maximum Height of Upper Rack 7.1 inch (180mm)
Maximun Height of Lower Rack 12.5 inch (320mm)
RACKS AND BASKETS
Easy Rack Plus Yes
Fold Down Tines
Upper: All Foldable
Lower: Half Smart FD & Half Normal FD
Rack Handle / Deco Yes
Rack Color (Handle / Tine) Dark Grey
Cup Rack Yes
Cup Rack Color Cup Rack (Dark Grey), Rubber (Noble Gray)
Height Adjustable Easy One Touch (3 Level)
Cutlery Baskets Yes
3rd Rack Yes, Normal Rail
Gliding Type
Upper: Gliding Rail
Lower: Gliding Wheel
STYLE AND DESIGN
Colors PrintProof™ Stainless Steel
Remaining Time Indicator Cycle Track™ Floor Display
Tub Material Stainless Steel
Tub Light Top Light
Touch Yes
Control Panel (Location) Top Control (Hidden Display)
Handle Bar Handle
FEATURES
No. Wash Cycles 5 (Auto, Heavy, Normal, 1-Hour, Download Cycle)
No. of Options
6 (Steam, High Temp, Dry Boost, Delay Start,
Contol Lock, Remote, Wi-Fi AP Mode)
TrueSteam
TM
Yes
Quadwash Yes
Bottle Wash Yes
SenseClean Wash System Yes
Vario Wash Yes
No. of Spray Arms 4 (Top, Upper, Lower, Bottle)
Detergent and Rinse-Aid Dispenser Yes
Drying System Dynamic Heat Dry with AutoVent™ Dry
End of Cycle Indicator Beeper + END Indication on Display
Hidden Water Heater Yes
Safety Float Switch (Leaks) Yes
Soil (Turbidity) Sensor Yes
Direct Drive Motor
TM
Yes
LoDecibel Quiet Operation 39dB
Tub Insulation Damping Sheet, Sound Absorbing Material
BPA-Free Nylon Coated Racks and Tines Yes
Anti-Bacterial Treatment (Drain Hose) Yes
Balance Door Yes
QUAD ARM
STS Deco Yes
Body Color Pearl Dark Grey
Nozzle Color Orange
SMART FEATURES
Wi-Fi Enabled Yes
POWER RATINGS
ENERGY STAR® Qualied Yes
Most Efcience Yes
CEE Tier 1
Energy Use (kWh/Year) 220
Water Use (Gallons/Cycle) 2.9
DIMENSIONS /CLEAR ANCES/WEIGHT
Product (W x H x D) 23 3/4” x 33 5/8” x 23 3/4”
Depth with Door Closed (Handle) 23 3/4” (603mm) / 26 1/8” (664mm)
Depth with Door Open 48 1/2”
Carton Dimensions (W x H x D) 28 1/32” x 29 5/8” x 34 7/8”
Clearance (W x H x D) 24” x 24” x 33 5/8”
Weight (Unit / Carton) 93lbs / 104lbs
Container Stufng Quantity 140
LIMITED WARRANTY
Parts and Labor 2 Year
Main Control Board and Rack Parts 5 Year Limited
Stainless Steel Door Liner and Tub 5 Years
Direct Drive Motor 10 Years
UPC CODES
SDNTHS72S 048231348119
LG STUDIO
HOM IE APPL ANCES
SDNTHS72S
© 2024 LG Electronics USA, Inc. All rights reserved. "LG Life’s Good" is a registered trademark of LG Corp. All other product and brand names are trademarks or registered trademarks of their respective owners. Design, features and specifications are subject to
change without notice. Non-metric weights and measurements are approximate. Some features may require Internet access. Content and services may vary by product and are subject to change without notice. 5/13/2
DIMENSIONS
Product (W x H x D) 23 3/4” x 33 5/8” x 23 3/4”
Depth with Door Closed (Handle) 23 3/4” (603mm) / 26 1/8” (664mm)
Depth with Door Open 48 1/2”
Carton Dimensions (W x H x D) 28 1/32” x 29 5/8” x 34 7/8”
Clearance (W x H x D) 24” x 24” x 33 5/8”
Weight (Unit / Carton) 93lbs / 104lbs
Container Stufng Quantity 140
Depth when lower door is fully opened 42 3/16” (1072.2mm)
23 / " (603 mm) 4
3
9 / " 8
(238 mm)
3
4 / " 16
(119 mm)
5
/
4
"
(134 mm)
11
1
4 / " 2
(115 mm)
1
33 / " 16
(846 mm)
5
4 / " 2
(115 mm)
1
33 / " 8
(854 mm)
5
2
3
/ " (
mm)
20
3
/
16
" ( mm)
23
3
/ " (6 mm)4
4
1
/ " (114 mm)2
(654 -6 mm)
25
3
/4
" - 25
15/16"
• This dishwasher is designed to fit a standard dishwasher opening. An opening
may be needed on both sides to route plumbing and electrical connections.
• Select a location as close to the sink as possible for easy connections to
water supply line, drain hose and electrical connection.
• To ensure proper drainage, install the dishwasher no
more than 12 ft. (3.65 m) from the sink.
• The location must have sufficient space for the dishwasher door to open
easily and provide at least 0.1" (2 mm) between the dishwasher and the cabinet
sides.
• If installing the dishwasher in a corner, leave a minimum of 2" (50 mm)
between the dishwasher and the adjacent wall.
The adjacent wall must be free of obstructions.
• To allow for proper clearance of plumbing and electrical, use the template
included with the literature to determine the clearance on the side of the
cabinet where the cabinet
meets the back wall. Using a 2 1/2" diameter hole saw, drill a hole in the target
area as shown on the template.
• If an extension drain hose is required, use a 5/8" or 7/8" inside diameter, 2–3
ft. length hose and a coupler for connecting the two hose ends.
• For flush installations only, you may remove the cabinet brace inside the
cabinet.
Water Supply Line
1
2
3
4
3
4
2
1
Elctrical Cable
1
