Side 1/15
Studiophile BX8
Users Manual
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
What’s in the Box? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Studiophile BX8 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Front and Rear Panel Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
XLR Balanced Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
TRS Balanced/Unbalanced Connection . . . . . . . . . . . . . . . . . . . . . . .7
Connecting to Preamp, Computer or Game Console Outputs . . .8
Setting the EQ Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Setting the Acoustic Space Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Placing the BX8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Appendix A - Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Appendix B - Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Technical Support & Contact Information . . . . . . . . . . . . . . . . . . . . . . .14
Your BX8 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Studiophile BX8
version: BX8-050103
Introduction
Thank you for choosing the BX8 Studiophile Series bi-amplified powered studio
reference monitor speakers. M-Audio is well known for digital audio interface
technology, digital converters, audio pre amps and mixers. Now, after long
research and development, the Studiophile BX8 is born to change the concept
of studio reference monitoring.
The BX8 was designed and tested by veteran audio engineers to meet your needs
in a studio monitoring environment. It is focused on the functional goal of
delivering pure original sound without any additional coloration.The BX8 monitor
is self-powered, directly accepting a line level signal from a variety of sources.
The Studiophile BX8 is designed to overcome all the limitations of conventional
studio reference monitors within the digital audio environment. This system
delivers a wide range of frequency response by employing two extraordinary
drivers and unique crossover technology licensed by M-Audio. It boasts a stable
and balanced low-mid frequency response along with a defined mid- and high-
frequency response as well. Both drivers are magnetically shielded for desktop
music production.
For pro engineers at commercial studios to home studio owners,the Studiophile
BX8 sets a new affordable standard in studio monitoring.
What’s in the Box?
Your Studiophile BX8 box contains:
•Two BX8 speakers
•Two detachable AC power cords
• This manual
• Actual test data of the BX8 you purchased
Studiophile BX8 Features
1. Woofer
The woofer unit is 8 inches in diameter with a magnetically shielded
mineral-filled polypropylene cone, high-temperature voice coil and damped
rubber surround. It is designed to deliver balanced mid- and low- frequency
response. Polypropylene is used to react against the input signal accurately and
to deliver even minimal input precisely while minimizing distortion.
2
