Side 1/3
marvelrefrigeration.com | 800.223.3900
Performance
• Dynamic Cooling Technology
™
delivers the industry’s best
temperature stability and rapid cool down, tested and proven
to cool nearly 2x faster than competitors
• Thermal-efcient cabinet ensures optimum preservation
and energy efciency while maximizing capacity
• Argon-lled, UV-resistant tinted dual pane glass door protects
contents from damaging ultraviolet light, while conserving energy
• Now even quieter operation thanks to exclusive design
enhancements to buffer and minimize sound
Storage Capabilities
• 2.7 cu. ft. capacity, stores (72) 12-oz cans and 3 wine bottles
• Black steel-framed glass shelves are cantilevered
and fully adjustable
• Includes (1) 3-in-1 Convertible Shelf™ featuring removable glass pane
with wine rack option
• Store food, beverages, or wine
Touchpad Controls
• Multifunction Marvel Intuit
™
Integrated Controls allow you to select a
precise cabinet temperature from 34° F to 42° F
• Vacation mode conserves energy during times when unit
is not in use
Aesthetics
• Two-stage, arctic white theater-style LED lighting and
midnight black interior
• Easy-to-install panel overlay option features soft-close integrated
hinge for a truly ush t with cabinetry
• Finish options: stainless steel, black or overlay (panel ready)
Additional Convenience
• Close Door Assist System
™
gently and automatically draws door to a
close, ensuring door is never accidentally left ajar
• Black toe kick adjustable to 4” with leveling legs
• Filler kit available for 18” wide opening
• 1-year parts and labor warranty, 5-year sealed system parts warranty
15” Marvel Beverage Center
Model # ML15BC
Ordering Options
Stainless Frame, Glass Door, Right Hinge,
Stainless Designer Handle
ML15BCG2RS
Stainless Frame, Glass Door, Left Hinge,
Stainless Designer Handle
ML15BCG2LS
Smooth Black Frame, Glass Door,
Right Hinge, Black Designer Handle
ML15BCG2RB
Smooth Black Frame, Glass Door,
Left Hinge, Black Designer Handle
ML15BCG2LB
Panel-Ready Framed Glass Door,
Integrated Right Hinge (Handle Not Included)*
ML15BCF3RP
Panel-Ready Framed Glass Door,
Integrated Left Hinge (Handle Not Included)*
ML15BCF3LP
Panel-Ready Solid Overlay Door,
Integrated Right Hinge (Handle Not Included)*
ML15BCP3RP
Panel-Ready Solid Overlay Door,
Integrated Left Hinge (Handle Not Included)*
ML15BCP3LP
*Easy installation! No panel kit required. Consult your cabinet maker for overlay
panel and handle options.
Built in the USA
14
7
/
8
" W
33
3
/
4
" H
25
5
/
8”
D
including
handle
Framed Overlay
(Panel Ready)*
Solid Overlay
(Panel Ready)*
Black FrameStainless Steel
Finish Options
marvelrefrigeration.com | 800.223.3900
1
5
⁄32"
(2.9 cm)
1
5
⁄32"
(2.9 cm)
Clearance
for hinge
2 places
14
3
⁄4"
(37.5 cm)
Clearance for
screw head,
4 places
Figure 14
Left Hand Hinged Door
15" (38.1 cm) wide appliance
Hinge side of door
Clearance
for hinge
2 places
14
3
⁄4"
(37.5 cm)
1
⁄4" (6 mm)
Deep
1" (25.4 mm) diameter
counter bore
1
⁄4" (6.4mm)
deep 4 places.
1
3
⁄4"
(4.4 cm)
4
7
⁄
8
"
(12.4 cm)
3
27
⁄32"
(9.7 cm)
1
11
⁄16"
(4.3 cm)
5"
(12.7 cm)
3
1
⁄8"
(7.9 cm)
Minimum
2"
(5.1 cm)
4
1
⁄8"
(10.5 cm)
Minimum
30
11
⁄32"
(77.1 cm)
1
3
⁄16"
(3 cm)
3
1
⁄8"
(7.9 cm)
1
1
⁄2"
(3.8 cm)
typical
3
11
⁄16"
(9.4 cm)
3
1
⁄8"
(7.9 cm)
Minimum
This side
facing interior
This side
facing interior
1
⁄4" (6 mm)
radius is
permissible
Hinge side of door
Top of door
Clearance for
screw head,
4 places
Figure 16
Right Hand Hinged Door
15" (38.1 cm) wide appliance
3
27
⁄32"
(9.7 cm)
1
⁄4" (6 mm)
Deep
5"
(12.7 cm)
1" (25.4 mm) diameter
counter bore
1
⁄4" (6 mm)
deep 6 places.
1
⁄4" (6 mm)
radius is
permissible
30
11
⁄32"
(77.1 cm)
4
7
⁄
8
"
(12.4 cm)
3
1
⁄
8
"
(7.9 cm)
1
1
⁄2"
(3.8 cm)
typical
1
3
⁄4"
(4.4 cm)
3
1
⁄8"
(7.9 cm)
Minimum
2"
(5.1 cm)
3
11
⁄16"
(9.4 cm)
4
1
⁄8"
(10.5 cm)
Minimum
1
11
⁄16"
(4.3 cm)
3
1
⁄8"
(7.9 cm)
Minimum
1
3
⁄16"
(3 cm)
Panel Overlay Dimensions (Frame Door)
Rough-In Dimensions
A. Rough-In Width 15”
B. Rough-In Height
Solid Door 34” to 35”
Overlay Door
34” 1/4 to
35” 1/4
C. Rough-In Depth 24”
Product Dimensions
D. Width 14 7/8”
E. Height
Solid Door
33 3/4” to
34 3/4”
Overlay Door 34” to 35”
F. Depth 21 1/2”
G. Depth to Front of Door
Solid Door 23 23/32”
Overlay Door
22 7/8”
Without
Handle
H. Depth to Handle 25 21/32” (Stainless Steel)
I. Depth with door at 90˚
Solid Door 37 13/32”
Overlay Door 37 1/2”
Product Features
Interior Cabinet Finish Black
Capacity
Up to 3 wine bottles or
up to 75 12-oz cans
Shelving System Cantilever
Shelf Fronts Black Steel-Framed
Other Storage NA
Interior Lighting White LED
Toe Grill Finish Black
Hinge Classic Hinge
Handle
Slim Designer Handle
(Panel Overlay Does
Not Include Handle)
Control Type Intuit
™
Temperature Range 34° to 42° F
Lock No
Electrical Requirements 120V / 60Hz / 15A
Length of Power Cord 6’
Shipping Weight 125 lbs
Finishes Stainless Steel, Overlay, Black
Vacation Mode Yes
Agency Approvals CSA, ENERGY STAR
"A"
"B"
"C"
"D"
"E"
"A"
"B"
"C"
"D"
"E"
"G"
"H"
"I"
"G"
"H"
"I"
"A"
"B"
"C"
"D"
"E"
"A"
"B"
"C"
"D"
"E"
"G"
"H"
"I"
"G"
"H"
"I"
Product Dimensions
For comprehensive installation instructions, please visit
www.marvelrefrigeration.com to access the owner’s guide.
marvelrefrigeration.com | 800.223.3900
Clearance for
screw head,
4 places
Clearance
for hinge
2 places
Right Hand Hinged Door
15" (38.1 cm) wide appliance
Right Hand Hinged Door
15" (38.1 cm) wide appliance
Clearance for
screw head,
4 places
Clearance
for hinge
2 places
Left Hand Hinged Door
15" (38.1 cm) wide appliance
Left Hand Hinged Door
15" (38.1 cm) wide appliance
4
7
⁄8"
(12.4 cm)
1
3
⁄16"
(3 cm)
3
1
⁄8"
(7.9 cm)
1
1
⁄2"
(3.8 cm)
typical
Hinge side of door
Top of door
14
3
⁄4"
(37.5 cm)
1
⁄4" (6 mm)
Deep
5"
(12.7 cm)
1" (25.4 mm) diameter
counter bore
1
⁄4" (6 mm)
deep 4 places.
1
3
⁄4"
(4.4 cm)
2"
(5.1 cm)
3
11
⁄16"
(9.4 cm)
1
⁄4" (6 mm)
radius is
permissible
1
11
⁄16"
(4.3 cm)
4
7
⁄8"
(12.4 cm)
1
3
⁄16"
(3 cm)
3
1
⁄
8
"
(7.9 cm)
1
1
⁄2"
(3.8 cm)
typical
1
11
⁄16"
(4.3 cm)
Hinge side of door
14
3
⁄4"
(37.5 cm)
1
⁄4" (6 mm)
Deep
5"
(12.7 cm)
1" (25.4 mm) diameter
counter bore
1
⁄4" (6 mm)
deep 4 places.
1
3
⁄4"
(4.4 cm)
2"
(5.1 cm)
3
11
⁄16"
(9.4 cm)
This side
facing interior
This side
facing interior
1
⁄4" (6 mm)
radius is
permissible
1
5
⁄32"
(2.9 cm)
1
5
⁄32"
(2.9 cm)
30
11
⁄32"
(77.1 cm)
30
11
⁄32"
(77.1 cm)
Panel Overlay Dimensions (Solid Door)
For comprehensive installation instructions, please visit
www.marvelrefrigeration.com to access the owner’s guide.
