Side 1/2
marvelrefrigeration.com | 800.223.3900
Performance
• Dynamic Cooling Technology
™
delivers rapid cool down, frost- free
operation and the industry’s best temperature stability
• Independent temperature control for each compartment
• Thermal-efcient cabinet ensures optimum preservation
and energy efciency while maximizing capacity
• Now even quieter operation thanks to exclusive design
enhancements to buffer and minimize sound
Storage Capabilities
• 4.9 cu. ft. capacity, refrigerator stores (72) 12-oz cans
• MaxStore
™
smooth-glide clear bin organizes loose, bulky items;
capable of storing 15 lbs of produce, 4 wine bottles or 22 cans
• Self-closing freezer can store 12 pints of ice cream
• Crescent ice maker produces up to 7 lbs of ice in 24 hours
and ice bucket stores 13 lbs of ice (select models)
• Also includes (2) half-width cantilevered, fully adjustable
steel-framed glass shelves and (1) full width xed position
steel-framed glass shelf
Touchpad Controls
• Multifunction Marvel Intuit
™
Integrated Controls ensure precise
refrigeration temperature management from 34° F to 42° F and a
freezer temperature between -6° F and 6° F to keep contents evenly
frozen throughout
• Vacation mode conserves energy during times when unit
is not in use
Aesthetics
• Pristine white interior easily wipes clean
• Efcient arctic white LED lighting illuminates interior
for better viewing
• Easy-to-install panel overlay option features soft-close integrated
hinge for a truly ush t with cabinetry
• Finish options: stainless steel, black or overlay (panel ready)
Additional Convenience
• Close Door Assist System
™
gently and automatically draws door to a
close, ensuring door is never accidentally left ajar
• Black toe kick adjustable to 4” with leveling legs
• 1-year parts and labor warranty, 5-year sealed system parts warranty
24” Marvel Refrigerator and
Freezer and MaxStore
™
Bin
Model # ML24RF & ML24RI
23
7
/
8
" W
33
3
/
4
" H
25
5
/
8
" D
including
handle
Made in the USA
Stainless Steel
Solid Overlay
(Panel Ready)*
Finish Options
Ordering Options:
Refrigerator + Freezer + Ice Maker
Solid Stainless Steel Door, Right Hinge,
Stainless Designer Handle
†
ML24RIS4RS
Solid Stainless Steel Door, Left Hinge,
Stainless Designer Handle
†
ML24RIS4LS
Panel-Ready Solid Overlay Door,
Integrated Right Hinge (Handle Not Included)*
ML24RIP5RP
Panel-Ready Solid Overlay Door,
Integrated Left Hinge (Handle Not Included)*
ML24RIP5LP
Refrigerator + Freezer (No Ice Maker)
Solid Stainless Steel Door, Right Hinge,
Stainless Designer Handle
†
ML24RFS3RS
Solid Stainless Steel Door, Left Hinge,
Stainless Designer Handle
†
ML24RFS3LS
Panel-Ready Solid Overlay Door,
Integrated Right Hinge (Handle Not Included)*
ML24RFP4RP
Panel-Ready Solid Overlay Door,
Integrated Left Hinge (Handle Not Included)*
ML24RFP4LP
*Easy installation! No panel kit required. Consult your cabinet maker for overlay
panel and handle options.
† ENERGY STAR
®
Certied
marvelrefrigeration.com | 800.223.3900
Left Hand Hinged Door
24" (61 cm) wide appliance
Right Hand Hinged Door
24" (61 cm) wide appliance
23
3
⁄4"
(60.3 cm)
1" (2.5 cm) diameter
x
1
⁄4" (6 mm) deep
4 places
4
7
⁄8"
(12.4 cm)
1
3
⁄16"
(3 cm)
14"
(35.6 cm)
1
⁄4" (6 mm)
radius is
permissible
3
1
⁄
8
"
(7.9 cm)
1
3
⁄4"
(4.4 cm)
2"
(5.1 cm)
3
11
⁄16"
(9.4 cm)
1
1
⁄2"
(3.8 cm)
typical
1
⁄4"
(6 mm)
Deep
1
11
⁄16"
(4.3 cm)
Hinge side of door
Top of door
Clearance for hinge
at top and bottom
Clearance for hinge
at top and bottom
Clearance for
screw head,
4 places
Left Hand Hinged Door
24" (61 cm) wide appliance
23
3
⁄4"
(60.3 cm)
1" (2.5 cm) diameter
x
1
⁄4" (6 mm) deep
4 places
4
7
⁄8"
(12.4 cm)
1
3
⁄
16
"
(3 cm)
14"
(35.6 cm)
1
⁄4" (6 mm)
radius is
permissible
3
1
⁄8"
(7.9 cm)
1
3
⁄4"
(4.4 cm)
2"
(5.1 cm)
3
11
⁄16"
(9.4 cm)
1
1
⁄2"
(3.8 cm)
typical
1
⁄4"
(6 mm)
Deep
1
11
⁄16"
(4.3 cm)
Hinge side of door
Top of door
Clearance for
screw head,
4 places
Right Hand Hinged Door
24" (61 cm) wide appliance
This side
facing interior
This side
facing interior
1
5
⁄32"
(2.9 cm)
1
5
⁄32"
(2.9 cm)
30
11
⁄32"
(77.1 cm)
30
11
⁄32"
(77.1 cm)
Panel Overlay Dimensions
Rough-In Dimensions
A. Rough-In Width 24”
B. Rough-In Height
Solid Door 34” to 35”
Overlay Door
34 1/4” to
35 1/4”
C. Rough-In Depth 24”
Product Dimensions
D. Width 23 7/8”
E. Height
Solid Door
33 3/4” to
34 3/4”
Overlay Door 34” to 35”
F. Depth 21 1/2
G. Depth to Front of Door
Solid Door 23 23/32”
Overlay Door
22 7/8”
Without
Handle
H. Depth to Handle 25 21/32” (Stainless Steel)
I. Depth with door at 90˚
Solid Door 46 13/32”
Overlay Door 46 1/2”
Product Features
Interior Cabinet Finish White
Capacity
Up to 72 12-oz cans
12 Pints of Ice Cream
Ice Bucket Capacity: 13 lbs
Shelving System Cantilever
Shelf Fronts White Steel-Framed
Other Storage
MaxStore
™
Bin
Freezer Storage, Ice Bucket
Interior Lighting White LED
Toe Grill Finish Black
Hinge Classic Hinge
Handle
Slim Designer Handle
(Panel Overlay Does
Not Include Handle)
Control Type Intuit
™
Temperature Range
Refrigerator: 34° to 42° F
Freezer: -6° to 6° F
Lock No
Electrical Requirements 120V / 60Hz / 15A
Length of Power Cord 6”
Shipping Weight 160 lbs
Finishes Stainless Steel, Overlay
Vacation Mode Yes
Agency Approvals CSA, Energy Star
"A"
"B"
"C"
"D"
"E"
"A"
"B"
"C"
"D"
"E"
"I"
"G"
"H"
"I"
"G"
"H"
"F"
"F"
"A"
"B"
"C"
"D"
"E"
"A"
"B"
"C"
"D"
"E"
"I"
"G"
"H"
"I"
"G"
"H"
"F"
"F"
Product Dimensions
For comprehensive installation instructions, please visit
www.marvelrefrigeration.com to access the owner’s guide.
