Side 1/2
marvelrefrigeration.com | 800.223.3900
Performance
• Dynamic Cooling Technology™ air fl ow system ensures even circulation
and optimal cooling environment for longer lasting food preservation
• Digital controls offer precise temperature stability within one degree
• Energy-effi cient variable speed compressor chills food quickly while
saving energy
• One of the quietest, technologically advanced compressors available
• Integrated ion air purifi er eliminates airborne bacteria and mold spores,
removes odors and enhances food preservation – and it never degrades
or needs replacing
• Moisture-control evaporator removes excess humidity
• Maintenance-free anti-clog condenser coil prevents dust and other
airborne particles from clogging the condenser
Storage Capabilities
• 25.32 total cubic feet storage capacity
REFRIGERATOR
• 15.76 cubic feet refrigerator capacity
• Seamless glass shelves feature spill-proof Nano technology that
contains spills and makes clean up easy
• 3/8” thick tempered glass shelves provide industry-leading durability
• 2 moisture-adjustable drawers feature soft-close slides and high/low
settings for the freshest leafy vegetables and fruits
• 4 deli drawers with soft-close slides store meats and cheeses
• 4 metal door bins provide enduring performance to securely store heavy
items
• 2 dairy compartments in the door with easy-view covers
• Also features additional space for extra-large 18” pizza box storage
FREEZER
• 9.56 cubic feet freezer capacity
• 3 adjustable wire shelves to confi gure storage to your needs
• 2 large-capacity wire baskets slide out for easy viewing
• 3 metal door bins easily adjust
• Adaptive defrost extends defrost periods to improve longevity of frozen
food storage
• Factory-installed ice automatic crescent ice maker with large-capacity
ice bin
Marvel Professional Built-in
42” Side-by-Side
Model # MP42SS2
Solid Overlay
(Panel Ready)*
Stainless Steel
Finish Options Optional
Professional Handle
Touchscreen Controls
• Fast Cool: cools the refrigerator at high speed for 2 hours
to rapidly chill contents
• Max Refrigerator Mode: adjusts refrigerator temp to the coldest setting
for 4 hours
• Max Freezer Mode: adjusts freezer temp to the coldest setting
for 6 hours to freeze contents faster
• Door Open Alarm: alerts when door is left open for more than 3 minutes
• Power Loss Alarm: POWER indicator light fl ashes, in the case of a
power loss
• High Temperature Alarm: alerts when freezer temp is too high
for 2 hours
• Temperature Sensor Alarm: alerts of temperature sensor problems
• Sabbath Mode: disables interior lights and alarms for observance
of the Sabbath
Aesthetics
• Graduated theater lighting with bright, energy-effi cient LED illumination
from top and sidewalls for better visibility
• Robust hinge allows optimal door rotation and maximum durability
• Adjustable door stops at 90, 110 and 120 degrees
Additional Convenience
• 2-year full product warranty, 6-year full sealed refrigeration system
warranty, 90-day full cosmetic parts and 12-year limited sealed
refrigeration system warranty
Ordering Options
Solid Stainless Steel Door, Slim Designer Handle MP42SS2NS
Panel-Ready Solid Overlay Door, (Handle Not Included)* MP42SS2NP
Optional Accessories
Professional Handle - Vertical Door Installation (qty 1) 42249470
Flush Mount Trim Kit PBIRFTKSS
*Consult your cabinet maker for overlay panel and handle options
Slim Designer
Handle Shown
(MP42SS2NS)
marvelrefrigeration.com | 800.223.3900
Width 42” (106.7 cm)
Overall Height
(from bottom)
82-3/4” (210.2 cm) min to
84-1/16” (213.5 cm) max
Depth to front edge
of side trim
23-3/4” (60.3 cm)
Depth to front of
top grille
26-1/4” (66.7 cm)
Depth to front of
handle endcap
29-3/16” (74.1 cm)
Cutout Width 41-5/8” (105.7 cm) min to
41-3/4” (106 cm) max
Cutout Height 82-7/8” (210.5 cm) min to
84-1/16” (213.5 cm) max
Cutout Depth 24” (61.0 cm) min
Electrical
Requirements
115 volt, 60 Hz, 15 amp
dedicated circuit; 3-wire
cord with grounded
3-prong plug attached to
product
Maximum Amp Usage 9.9 amps
Water Requirements 1/4” copper tubing inlet
waterline; minimum 20
psi; maximum 120 psi
Length of Power Cord 4 1/2 ft. (137 cm)
Total Capacity 25.32 cu. ft. (717 liters)
Refrigerator Capacity 15.76 cu. ft. (446 liters)
Freezer Capacity 9.56 cu. ft. (271 liters)
Approximate Shipping
Weight
525 lb. (238 kg)
Interior Finish Arctic White
Shelving System Spill-proof sealed 3/8”
thick glass shelves
Shelf Fronts Arctic White
Other Storage Bottom Storage for Extra-
Large Pizza Box
Interior Lighting White LED Lighting
(Top, Sidewalls)
Toe Grille Finish Stainless Steel
Hinge Zero Clearance
Handle Designer
(Handle not included on
Overlay Models)
Control Type Digital Controls
Temperature Range REFRIGERATOR:
33°F to 43°F
(0.6°C to 6°C)
FREEZER: -5°F to 5°F
(-20.6 °C to -15°C)
Lock No
Finishes Stainless Steel, Overlay
Agency Approvals UL
F60367
®
For detailed product information, model numbers, or to request a quote call 1-888-845-4641 or visit vikingrange.com
© 2015 Viking Range, LLC All rights reserved. Specifications subject to change without notice.
VIKING RANGE, LLC 111 FRONT STREET GREENWOOD, MISSISSIPPI 38930 USA
0416
QUIET COOL™ BUILT-IN 42”W. SIDE-BY-SIDE
Viking Professional 5 Series – VCSB
42”W. SIDE-BY-SIDE
DESCRIPTION VCSB5423 VCSB5423 FLUSH MOUNT
Overall Width 42” (106.7 cm)
Overall Height (from bottom) 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max.
Overall Depth from rear
To front edge of side trim:
To front of top grille:
To front of handle endcap:
23-3/4” (60.3 cm)
26-1/4” (66.7 cm)
29-3/16” (74.1 cm)
25-1/2” (64.8 cm)
26-1/4” (66.7 cm)
29-3/16” (74.1 cm)
Cutout Width 41-5/8” (105.7 cm) min. to 41-3/4” (106 cm) max. 42” (106.7 cm)
Cutout Height 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max.
Cutout Depth 24” (61.0 cm) min. 26-1/2” (67.3 cm) min.
Electrical Requirements 115 volt, 60 Hz, 15 amp dedicated circuit; 3-wire cord with grounded 3-prong plug attached to product
Maximum Amp Usage 9.9 amps
Inlet Water Requirements 1/4” copper tubing inlet waterline; min. 20 psi; max. 120 psi
Overall Interior Dimensions
Refrigerator
Freezer
Total Capacity
15.76 cu. ft. (446 liters)
9.56 cu. ft. (271 liters)
25.32 cu. ft. (717 liters)
15.76 cu. ft. (446 liters)
9.56 cu. ft. (271 liters)
25.32 cu. ft. (717 liters)
Approximate Shipping Weight 525 lb. (238 kg) 525 lb. (238 kg)
Please do not prepare installation from brochure data only. See installation instructions for important clearance/installation information.
26-1/4”
(66.7
cm)
41”
(10
4.1
cm
)
7
5
–
1
5
/1
6
”
(1
9
2
.9
cm
)
3–19/32”
(9.1 cm)
42”42”
(1
0
6
.7
c
m
)
9–5/32”
(23.3 cm)
8
2
–
3
/4
”
(210.2 cm
)
min.
to
84–1/16”
(213.5 cm
)
m
ax.
23–7/8”
(6
0
.6
c
m
)
24-5/8”
(62.6 cm
)
29-3/16”
(7
4
.1
c
m
)
1–1/2”
(3
.8
cm
)
9”
(22.9 cm)
73-3/8”
(186.4 cm)
82–7/8”
(210.5 cm) min.
anti-tip board &
opening height
84–1/16”
(213.5 cm) max.
anti-tip board &
opening height
41–5/8”
(105.7 cm) min.
to
41–3/4”
(106.0 cm) max.
42”
(106.7 cm)
Flush Mount only
Standar
d Mount
24”
(61.0 cm)
Flush Mount
26-1/2”
(67.3 cm)
Electric Outlet Location
Water Line Entry Area
6–3/4”
(17.1 cm)
7–5/8”
(19.4 cm)
3”
(7.6 cm)
5/8”
(1.6 cm)
5/8”
(1.6 cm)
10–1/2”
(26.7 cm)
5/8”
(1.6 cm)
10–3/4”
(27.3 cm)
1”
(2.5 cm)
3–5/8”
(9.2 cm)
Optional floor
water line entry
42”
(106.7 cm)
Flush Mount only
41–5/8”
(105.7 cm)
See Anti-Tip board installation
6”
(15.2 cm)
9”
(22.9 cm)
Marvel Professional Built-in
42” Side-by-Side
Model # MP42SS2
*Specifi cations subject to change without notice.
This spec sheet is intended only for quick reference.
For complete installation details, consult the owner’s
guide on marvelrefrigeration.com.
