Side 1/12

MAX-Series

INSTRUCTION MANUAL

HANDLEIDING

MODE D’EMPLOI

BEDIENUNGSANLEITUNG

MANUAL DE INSTRUCCIONES

Basic connections / Basis aansluiting / Connexions de base

Wide Range

Cable Connector / Aansluitingen / Connecteur de câble

Regulatory Requirement:

EN 55013

EN 55020

EN 61000-3-2/-3-3

Congratulations to the purchase of our MAX speaker box.

Read the instructions thoroughly prior to using the unit.

SAFETY INSTRUCTIONS

• Hearing damage:

MAX loudspeakers are easily generating high

sound pressure levels (SPL) sufficient to cause

permanent hearing damage to performers,

production crew and audience members. Care

should be taken to avoid prolonged exposure to

SPL in excess of 85 dB.

• Make sure that the amplifier is switched off

when the speaker box is connected or

disconnected.

• The box must be installed by a qualified

technician who has knowledge of the

techniques.

• Do not overload the box to avoid damage to the

speakers.

• Connect the box only to a good quality

amplifier:

Direct voltage at the amplifier output will

damage the speakers

“Clipping” (overdrive) of the amplifier can

damage the woofer, tweeter and horn speaker

• Do not overload the speakers to avoid damage

to the components.

• Do not place an open fire (candle, etc.) on top

or next to the box - FIRE HAZARD

• For indoor use only. If the box is used outdoors,

you need to make sure that no humidity can

enter the box.

• Make sure that the box is placed on a stable,

solid surface.

• The boxes can be stacked but do not put more

than 60kg weight on the box.

• The boxes can be hung. Use only strong and

approved mounting material. The installation

should only be carried out by a qualified

technician who has knowledge of the

techniques and regulations regarding the

mounting/hanging of speaker boxes. During the

mounting, make sure that nobody is standing

below the mounting area.

• Use only stands which are designed to support

the weight of the speaker. Do not attempt to

place more than one speaker on a stand

designed for a single speaker.

• Do not place liquids on the box and protect it

against humidity. Humidity can shorten the life

time considerably.

• Only use suitable means of transportation if you

want to move the box – BEWARE OF YOUR

BACK!!

• If the unit is damaged to an extent that internal

parts are visible, DO NOT connect the unit and

DO NOT switch it on. Contact your dealer or

Tronios.

• Never try to repair the unit yourself. It does not

contain any user serviceable parts. All repairs

must be carried out by a qualified technician.

• Set the amplifier to the lowest volume prior to

switching it on.

• Keep the unit out of the reach of children.

Protect your environment. Recycle packing material

whenever possible.

Do not throw a faulty unit into normal

household waste but bring it to a special

collection point. A large part of it can be

recycled.

CONNECTIONS:

First of all, check the specifications of the amplifier if it is suitable for your speaker boxes. Pay particular

attention to the power rating and impedance.

Check if the amplifier is switched off. If yes, you can switch on the speakers. PLEASE NOTE! Watch the polarity

(+/-). Wires of the same colour must be connected to the same sign of every side i.e. the + of the amplifier must

be connected to the + of the speaker box. If the connections are inverted, the sound quality will diminish.

Only use high quality speaker cables that are suitable for the power and distance between the amplifier and the

speaker.

Connection of several speakers:

When a second speaker is connected in parallel (see fig.) the impedance will change from 8 Ohms to 4 Ohms.

Check if the amplifier can handle this. If more that two speakers are connected in parallel, the impedance will go

below 4 Ohms. Most of the amplifiers can’t handle this!

Do not attempt to make any repairs yourself. This would invalid your warranty. Do not make any changes to the unit. This would

also invalid your warranty. The warranty is not applicable in case of accidents or damages caused by inappropriate use or

disrespect of the warnings contained in this manual. Tronios cannot be held responsible for personal injuries caused by a

disrespect of the safety recommendations and warnings. This is also applicable to all damages in whatever form.

Produkspesifikasjoner

Merke:	Max
Kategori:	Høyttaler
Modell:	215
Vekt:	18450 g
Bredde:	330 mm
Dybde:	465 mm
Høyde:	1025 mm
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Strømkildetype:	AC
Antall per pakke:	1 stykker
Anbefalt bruk:	DJ
Impedans:	8 Ω
Høyttalerplassering:	Gulv
Basshøyttaler:	Ja
Høyttalerposisjon:	Front
Produktfarge:	Sort
Lyd-utgang kanaler:	- kanaler
RMS-rangert strøm/utgangseffekt:	2000 W
Antall drivere:	1
Høyttaler type:	3-veis
Frekvensrekkevidde:	30 - 18000 Hz
Sensitivitet/følsomhet:	100 dB
Basshøyttalerens diameter (imperisk):	15 "
Antall basshøyttalerdrivere:	2
