Side 1/16
STARTING & CHARGING SYSTEM
SECTION
SC
CONTENTS
PRECAUTIONS ...............................................................2
Supplemental Restraint System (SRS) ″AIR
BAG″ and ″SEAT BELT PRE-TENSIONER″...............2
Wiring Diagrams and Trouble Diagnosis.....................2
BATTERY.........................................................................3
How to Handle Battery ................................................3
METHODS OF PREVENTING OVER-DISCHARGE
......3
CHECKING ELECTROLYTE LEVEL
............................3
SPECIFIC GRAVITY CHECK
......................................4
CHARGING THE BATTERY
........................................5
STARTING SYSTEM.......................................................6
System Description......................................................6
M/T MODELS
............................................................6
A/T MODELS
.............................................................6
Wiring Diagram - START -...........................................7
M/T MODELS
............................................................7
A/T MODELS
.............................................................8
Construction.................................................................9
Removal and Installation .............................................9
REMOVAL
.................................................................9
INSTALLATION
..........................................................9
Pinion/Clutch Check ..................................................10
CHARGING SYSTEM....................................................11
System Description....................................................11
Wiring Diagram - CHARGE -.....................................12
Trouble Diagnoses.....................................................13
WITH IC REGULATOR
.............................................13
MALFUNCTION INDICATOR
....................................13
Construction...............................................................14
Removal and Installation ...........................................14
REMOVAL
...............................................................14
INSTALLATION
........................................................14
SERVICE DATA AND SPECIFICATIONS (SDS).........15
Battery........................................................................15
Starter ........................................................................15
Alternator ...................................................................15
GI
MA
EM
LC
EC
FE
CL
MT
AT
AX
SU
BR
ST
RS
BT
HA
EL
IDX
EXIT
EXIT
Supplemental Restraint System (SRS) “AIR
BAG” and “SEAT BELT PRE-TENSIONER”
NFSC0001
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER” used along with
a seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of
collision. The SRS system composition which is available to NISSAN MODEL A33 is as follows (The compo-
sition varies according to optional equipment.):
I For a frontal collision
The Supplemental Restraint System consists of driver air bag module (located in the center of the steer-
ing wheel), front passenger air bag module (located on the instrument panel on passenger side), seat belt
pre-tensioners, a diagnosis sensor unit, warning lamp, wiring harness and spiral cable.
I For a side collision
The Supplemental Restraint System consists of front side air bag module (located in the outer side of front
seat), satellite sensor, diagnosis sensor unit (one of components of air bags for a frontal collision), wiring
harness, warning lamp (one of components of air bags for a frontal collision).
Information necessary to service the system safely is included in the RS section of this Service Manual.
WARNING:
I To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance should be per-
formed by an authorized NISSAN dealer.
I Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by intentional activation of the system. For removal of Spiral Cable and Air Bag
Module, see the RS section.
I Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. Spiral cable and wiring harnesses covered with yellow insulation or tape either just
before the harness connectors or for the complete harness are related to the SRS.
Wiring Diagrams and Trouble Diagnosis
NFSC0002
When you read wiring diagrams, refer to the following:
I GI-11, “HOW TO READ WIRING DIAGRAMS”.
I EL-9, “POWER SUPPLY ROUTING” for power distribution circuit.
When you perform trouble diagnosis, refer to the following:
I GI-36, “HOW TO FOLLOW TEST GROUP IN TROUBLE DIAGNOSIS”.
I GI-25, “HOW TO PERFORM EFFICIENT DIAGNOSIS FOR AN ELECTRICAL INCIDENT”.
PRECAUTIONS
Supplemental Restraint System (SRS) “AIR BAG” and “SEAT BELT PRE-TENSIONER”
SC-2
EXIT
EXIT
