Optoma EH1060 Bruksanvisning

Optoma videoprosjektor EH1060

Les nedenfor 📖 manual på norsk for Optoma EH1060 (57 sider) i kategorien videoprosjektor. Denne guiden var nyttig for 4 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2.5 brukere

Last ned PDF

Side 1/57

English

Table of contents

Table of Contents ...................................................................................1

Usage Notice ..........................................................................................3

Safety Information .........................................................................................3

Precautions....................................................................................................4

Eye Safety Warnings .....................................................................................6

Introduction.............................................................................................7

Package Overview.........................................................................................7

Product Overview ..........................................................................................8

Main Unit ................................................................................................................8

Connection Ports ................................................................................................... 9

Remote Control ....................................................................................................10

Installation ............................................................................................11

Connecting the Projector .............................................................................11

Connect to Notebook ...........................................................................................11

Connect to Video Sources ...................................................................................12

Powering On/O󰘯 the Projector .....................................................................13

Powering On the Projector ...................................................................................13

Powering O󰘯 the Projector ................................................................................... 14

Warning Indicator .................................................................................................14

Adjusting the Projected Image.....................................................................15

Adjusting the Projector's Height ........................................................................... 15

Adjusting Projection Image Size .......................................................................... 16

User Controls .......................................................................................17

Remote Control ...........................................................................................17

On-screen Display Menus ...........................................................................19

How to operate .................................................................................................... 19

Menu Tree ...................................................................................................20

Image ...................................................................................................................21

Image | Advanced ................................................................................................23

Display .................................................................................................................24

System .................................................................................................................26

System | Lamp Settings .......................................................................................28

System | Startup Image .......................................................................................29

System | Network ................................................................................................. 30

Setup .................................................................................................................... 34

Appendicess .........................................................................................38

Troubleshooting ...........................................................................................38

Image ...................................................................................................................38

Other .................................................................................................................... 39

Table of contents

Projector LED Status Indicator ............................................................................. 40

Remote Control ....................................................................................................41

Replacing the Lamp.....................................................................................42

Compatibility Modes ....................................................................................45

RS232 Commands and Protocol Function List............................................46

RS232 Pin Assignments (projector side) ............................................................. 46

RS232 Protocol Function List .............................................................................. 47

Ceiling Mount Installation ............................................................................53

Optoma Global O󰘲ces ................................................................................54

Regulation & Safety Notices ........................................................................56

Produkspesifikasjoner

Merke:	Optoma
Kategori:	videoprosjektor
Modell:	EH1060
Vekt:	3500 g
Støynivå:	28 dB
Wi-Fi:	Nei
Antall farger:	1.073 milliarder farger
Antall USB 2.0-porter:	1
Antall HDMI-porter:	2
DVI-port:	Nei
Innebygde høyttalere:	Ja
Full HD:	Ja
Digital zoom:	1.2 x
3D:	Nei
Ensartethet:	85
Dimensjoner (B x D x H):	326 x 259 x 109 mm
Kontrastforhold:	2500:1
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Strømforbruk (standby):	1 W
Projektorens lysstyrke:	3500 ANSI lumen
Projektoroppløsning:	1080p (1920x1080)
Produktfarge:	Sølv
Støttede grafikkoppløsninger:	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1600 x 1200 (UXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Analogt signalformatsystem:	NTSC, NTSC 3.58, NTSC 4.43, PAL, PAL B, PAL D, PAL G, PAL H, PAL I, PAL M, PAL N, SECAM, SECAM B, SECAM D, SECAM G, SECAM K, SECAM K1, SECAM L
Visningsteknologi:	DLP
Skjermstørrelsekompabilitet:	28.41 - 341.28 "
Projeksjonsavstand:	1.2 - 12 m
Hjørnesteinsrettelse, vertikal:	15 °
Horisontalt frekvensområde:	15 - 91 kHz
Støynivå (økonomisk funksjon):	30 dB
Zoomfunksjon:	Ja
Brennviddeområde:	- mm
Zoom-type:	Manuell
RS-232-port:	1
Lyskildens tjenestetid:	2000 timer
Strømforbruk (vanlig bruk):	298 W
Støttede videofunksjoner:	1080i, 480i, 480p, 576i, 576p, 720p
Antall VGA (D-Sub)-porter:	1
Lydinngang (V/H) inn:	2
Komponentvideo (YPbPr/YCbCr) inn:	1
Mikrofon, linje-inn-støpsel:	Ja
Seriell grensesnittype:	RS-232
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	5 - 40 °C
Fjernkontroll medfølger:	Nei
Antall S-Video-innganger:	1
Ethernet/bredbåndsforbindelse:	Ja
Relativ luftfuktighet under drift (H-H):	0 - 85
Komposittvideo inn/sammensatt video inn:	1
Lydutgang (venstre/høyre):	1
RMS-rangert strøm/utgangseffekt:	3 W
Lyskildens tjenestetid (økonomisk modus):	3000 timer
Størrelseforhold:	16:10
Kabellåsport:	Ja
Vertikal scanningsratio:	25 - 85 Hz
Kabellåstype:	Kensington
Strømforbruk, strømsparing:	247 W
