Optoma EH415 Bruksanvisning

Optoma videoprosjektor EH415

Les nedenfor 📖 manual på norsk for Optoma EH415 (87 sider) i kategorien videoprosjektor. Denne guiden var nyttig for 5 personer og ble vurdert med 3.9 stjerner i gjennomsnitt av 3 brukere

Last ned PDF

Side 1/87

English

Table of contents

Table of contents ....................................................................................1

Usage Notice ..........................................................................................3

Safety Information .........................................................................................3

Precautions....................................................................................................4

Eye Safety Warnings .....................................................................................6

Introduction.............................................................................................7

Package Overview.........................................................................................7

Product Overview ..........................................................................................8

Main Unit ................................................................................................................ 8

Connection Ports ................................................................................................... 9

Remote Control .................................................................................................... 10

Installation ............................................................................................11

Connecting the Projector .............................................................................11

Connect to Notebook ........................................................................................... 11

Connect to Video Sources ................................................................................... 12

Powering On/O󰘯 the Projector .....................................................................13

Powering On the Projector ................................................................................... 13

Powering O󰘯 the Projector ................................................................................... 14

Warning Indicator ................................................................................................. 14

Adjusting the Projected Image.....................................................................15

Adjusting the Projector’s Height ........................................................................... 15

Adjusting Projection Image Size (WXGA) ............................................................ 16

Adjusting Projection Image Size (1080p) ............................................................. 17

User Controls .......................................................................................18

Remote Control ...........................................................................................18

On-screen Display Menus ...........................................................................20

How to operate ..................................................................................................... 20

Menu Tree ...................................................................................................21

Image ................................................................................................................... 23

Image | Advanced ................................................................................................ 25

Image | Advanced | Color Matching ..................................................................... 27

Image | Advanced | Signal ................................................................................... 28

Display ................................................................................................................. 29

Display | 3D .......................................................................................................... 31

Setup .................................................................................................................... 32

Setup | Language ................................................................................................. 34

Setup | Security .................................................................................................... 35

Setup | Audio Settings ......................................................................................... 38

Setup | Advanced ................................................................................................. 39

Setup | Network ................................................................................................... 40

Setup | LAN Settings ............................................................................................ 41

Setup | Control Settings ....................................................................................... 42

Table of contents

Options ................................................................................................................. 43

Options | Input Source ......................................................................................... 46

Options | Remote Settings ................................................................................... 47

Options | Advanced .............................................................................................. 48

Options | Lamp Setting ........................................................................................ 50

LAN_RJ45 ...................................................................................................52

Appendices...........................................................................................62

Troubleshooting ........................................................................................... 62

Image ................................................................................................................... 62

Other .................................................................................................................... 63

Projector LED Status Indicator ............................................................................. 64

Remote Control .................................................................................................... 65

Replacing the Lamp.....................................................................................66

Compatibility Modes ....................................................................................69

Video Compatibility .............................................................................................. 69

Video Timing Detail Describe ............................................................................... 69

Computer Compatibility - VESA standards .......................................................... 70

Input Signal for HDMI/DVI-D ............................................................................... 71

True 3D Video Compatibility table ....................................................................... 72

RS232 Commands and Protocol Function List............................................73

RS232 Pin Assignments (projector side) ............................................................. 73

RS232 Protocol Function List .............................................................................. 74

Telnet Commands .......................................................................................78

AMX Device Discovery commands .............................................................78

PJLink™ supported commands...................................................................79

Trademarks .................................................................................................81

Ceiling Mount Installation ............................................................................83

Optoma Global O󰘲ces ................................................................................84

Regulation & Safety Notices ........................................................................ 86

Produkspesifikasjoner

Merke:	Optoma
Kategori:	videoprosjektor
Modell:	EH415
Produkttype:	Standard stråleprojektor
Vekt:	3400 g
Bredde:	286 mm
Dybde:	266 mm
Høyde:	124 mm
Støynivå:	- dB
Strømkilde:	AC
Plassering:	Desktop
Garantikort:	Ja
Antall farger:	1.073 milliarder farger
Matrisestørrelse:	0.65 "
Antall HDMI-porter:	1
Fokus:	Manuell
Innebygde høyttalere:	Ja
Antall innebygde høyttalere:	1
Full HD:	Ja
Digital zoom:	1.6 x
3D:	Ja
On Screen Display (OSD):	Ja
Ensartethet:	85
Kontrastforhold:	15000:1
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Strømforbruk (standby):	0.5 W
Projektorens lysstyrke:	4200 ANSI lumen
Projektoroppløsning:	1080p (1920x1080)
Produktfarge:	Hvit
Naturlig sideforhold:	16:9
Støttede grafikkoppløsninger:	1024 x 768 (XGA), 1280 x 768 (WXGA), 1280 x 800 (WXGA), 1360 x 768 (WXGA), 1400 x 1050 (SXGA+), 1600 x 1200 (UXGA), 800 x 600 (SVGA)
Analogt signalformatsystem:	NTSC, PAL, SECAM
Kabler inkludert:	VGA
Visningsteknologi:	DLP
Skjermstørrelsekompabilitet:	30 - 300 "
Projeksjonsavstand:	1.2 - 10 m
Hjørnesteinsrettelse, horisontal:	40 °
Hjørnesteinsrettelse, vertikal:	40 °
Horisontalt frekvensområde:	15 - 91 kHz
Støynivå (økonomisk funksjon):	32 dB
Zoomfunksjon:	Ja
Brennviddeområde:	20.77 - 31.05 mm
Zoom-type:	Manuell
RS-232-port:	1
Lyskildens tjenestetid:	3000 timer
Lyskildetype:	Lampe
Strømforbruk (vanlig bruk):	290 W
Støttede videofunksjoner:	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Antall VGA (D-Sub)-porter:	2
Lydinngang (V/H) inn:	2
Seriell grensesnittype:	RS-232
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Bærekraftsertifikater:	RoHS
Fjernkontroll medfølger:	Ja
Fjernkontrolltype:	IR
Hurtigstartsguide:	Ja
DC-inngangskontakt:	Ja
OSD-språk:	ARA, CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, NOR, POL, POR, RUM, RUS, SWE, TUR
Antall S-Video-innganger:	1
Ethernet/bredbåndsforbindelse:	Nei
Komposittvideo inn/sammensatt video inn:	1
Lydutgang (venstre/høyre):	1
RMS-rangert strøm/utgangseffekt:	10 W
Batterier medfølger:	Ja
Lampens effekt:	280 W
Lyskildens tjenestetid (økonomisk modus):	7000 timer
Blenderåpning rekkevidde:	2.42 - 2.97
Bæretaske:	Ja
Kabellåsport:	Ja
Vertikal scanningsratio:	24 - 120 Hz
Kabellåstype:	Kensington
Zoom-forhold:	1.6:1
AC-adapter bunt:	Ja
Støttede forhold:	4:3, 16:9, 16:10
Strømforbruk, strømsparing:	250 W
