Side 1/34

... English

Table of Contents

Table of Contents ....................................................................................... 1

Usage Notice .............................................................................................. 2

Precautions ......................................................................................................... 2

Introduction ................................................................................................ 4

Product Features ................................................................................................ 4

Package Overview ............................................................................................. 5

Product Overview ................................................................................................ 6

Main Unit ........................................................................................................................ 6

Control Panel ................................................................................................................ 7

Connection Ports .......................................................................................................... 8

Remote Control with Mouse Function & Laser Pointer ............................................... 9

Installation ............................................................................................... 10

Connecting the Projector .................................................................................. 10

Powering On/Off the Projector .......................................................................... 11

Powering On the Projector ......................................................................................... 11

Powering Off the projector .......................................................................................... 12

Warning Indicator ....................................................................................................... 12

Adjusting the Projected Image ......................................................................... 13

Adjusting the Projector Image Height ........................................................................ 13

Adjusting the Projector Zoom / Focus ....................................................................... 14

Adjusting Projected Image Size ................................................................................. 14

User Controls ............................................................................................ 15

Control Panel & Remote Control ..................................................................... 15

On-Screen Display Menus ............................................................................... 18

How to operate ............................................................................................................ 18

Language ..................................................................................................................... 19

Image-I (Computer Mode) .......................................................................................... 20

Image-I (Video Mode) ................................................................................................. 21

Image-II ........................................................................................................................ 22

Audio ............................................................................................................................ 24

Management ................................................................................................................ 25

PIP ............................................................................................................................... 27

Appendices .............................................................................................. 28

Troubleshooting ............................................................................................... 28

Replacing the lamp .......................................................................................... 32

Compatibility Modes ........................................................................................ 33

Ceiling Mount Installation ................................................................................. 34

English ...

Usage Notice

Precautions

Follow all warnings, precautions and maintenance as recom-

mended in this user’s guide to maximize the life of your

unit.

Warning- Do not look into the projector’s lens when the lamp is

on. The bright light may hurt your eyes.

Warning- To reduce the risk of fire or electric shock, do not

expose this product to rain or moisture.

Warning- Please do not open or disassemble the product as this

may cause electric shock.

Warning- When changing the lamp, please allow unit to cool

down, and follow all changing instructions.

Warning- This product will detect the life of the lamp itself.

Please be sure to change the lamp when it shows

warning messages.

Warning- Reset the “Lamp Reset” function from the On Screen

Display “Management-->Lamp” menu after replacing

the lamp module (refer to page 26).

Warning- When switching the projector off, please ensure the

projector completes its cooling cycle before

disconnecting power.

Warning- Turn on the projector first and then the signal sources.

Warning- Do not use lens cap when projector is in operation.

Warning- When the lamp reaches the end of its life, it will burn

out and may make a loud popping sound. If this

happens, the projector will not turn back on until the

lamp module has been replaced. To replace the lamp,

follow the procedures listed under “Replacing the

Lamp”.

Produkspesifikasjoner

Merke:	Optoma
Kategori:	videoprosjektor
Modell:	EP759
Produkttype:	Standard stråleprojektor
Vekt:	3400 g
Bredde:	340 mm
Dybde:	260 mm
Høyde:	127 mm
Støynivå:	33 dB
Antall lamper:	1 lamper
Strømkilde:	AC
LED-indikatorer:	Ja
Plassering:	Desktop
Antall farger:	16.78 million farger
Matrisestørrelse:	0.7 "
Antall USB 2.0-porter:	1
DVI-port:	Ja
Fokus:	Manuell
Innebygde høyttalere:	Ja
Antall innebygde høyttalere:	2
Strømforbruk (maks.):	360 W
Full HD:	Nei
HDCP:	Ja
Kontrastforhold:	2000:1
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Strømforbruk (standby):	20 W
Projektorens lysstyrke:	3500 ANSI lumen
Projektoroppløsning:	XGA (1024x768)
Produktfarge:	Black, Grey
Støttede grafikkoppløsninger:	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1600 x 1200 (UXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Analogt signalformatsystem:	NTSC, PAL, SECAM
Visningsteknologi:	DLP
Skjermstørrelsekompabilitet:	29.5 - 300 "
Projeksjonsavstand:	1.5 - 12.2 m
Horisontalt frekvensområde:	15 - 100 kHz
Støynivå (økonomisk funksjon):	28 dB
Zoomfunksjon:	Ja
Brennviddeområde:	28 - 33.6 mm
Zoom-type:	Manuell
RS-232-port:	1
Lyskildens tjenestetid:	2000 timer
Lyskildetype:	Lampe
Støttede videofunksjoner:	480i, 480p, 576i, 576p, 720p
Antall VGA (D-Sub)-porter:	1
Komponentvideo (YPbPr/YCbCr) inn:	1
Seriell grensesnittype:	RS-232
Driftstemperatur (T-T):	5 - 35 °C
Oppbevaringstemperaturomåde (Celsius):	-20 - 60 °C
Innebygd kortleser:	Nei
Fjernkontroll medfølger:	Ja
Lampetype:	SHP
Antall S-Video-innganger:	1
Ethernet/bredbåndsforbindelse:	Nei
Komposittvideo inn/sammensatt video inn:	1
RMS-rangert strøm/utgangseffekt:	2 W
Lampens effekt:	300 W
Lyskildens tjenestetid (økonomisk modus):	3000 timer
Blenderåpning rekkevidde:	2.4 - 2.6
Type CardBus PCMCIA-port:	Nei
Optisk diskettspillertype:	Ikke inkludert
Vertikal scanningsratio:	43 - 120 Hz
Zoom-forhold:	1.2:1
