EN-1

CONTENTS

Usage Notice .....................................................................................2

Safety Instructions ................................................................................................................. 2

Introduction .......................................................................................5

Projector Features ................................................................................................................. 5

Package Contents ................................................................................................................. 6

Projector Overview ................................................................................................................ 7

Using the Product .............................................................................9

Control Panel ......................................................................................................................... 9

Connection Ports ................................................................................................................. 10

Remote Control ................................................................................................................... 11

Remote Control ................................................................................................................... 13

Installing the Batteries ......................................................................................................... 15

Remote Control Operation ................................................................................................... 16

Connection ......................................................................................17

Connecting a computer or monitor ...................................................................................... 18

Connecting Video source devices ....................................................................................... 19

Operation .........................................................................................23

Powering On/Off the Projector ............................................................................................. 23

Adjusting the Projector Height ............................................................................................. 24

Adjusting the Projector Zoom and Focus ............................................................................ 24

Adjusting Projection Image Size .......................................................................................... 25

Menu Operation ................................................................................................................... 26

Use web browser to control your projector .......................................................................... 36

Crestron RoomView Control Tool ........................................................................................ 40

Appendix ..........................................................................................43

Replacing the Lamp .............................................................................................................43

Ceiling mount installation .....................................................................................................45

Compatibility Modes ............................................................................................................46

RS232 Commands and Protocol Function List .................................................................... 49

Troubleshooting ................................................................................................................... 53

Optoma Global Offices ........................................................................................................ 55

Regulation & Safety Notices ................................................................................................ 58

EN-2

Usage Notice

Safety Instructions

Read all of these instructions before you operate your projector and save for

future reference.

1. Read instructions

All the safety and operating instructions should be read before the

appliance is operated.

2. Notes and warnings

All notes and warnings in the operating instructions should be adhered

to.

3. Cleaning

Unplug the projector from the wall socket before cleaning. Use a damp

cloth for cleaning the projector housing. Do not use liquid or aerosol

cleaners.

4. Accessories

Do not place this product on an unstable cart, stand, or table. The product

may fall,

causing serious damage to the product.

Keep the plastic packing materials (from the projector, accessories and

optional parts) out of the reach of children as these bags may result in

death by suffocation. Be particularly careful around the small children.

5. Ventilation

The projector is equipped with ventilation holes (intake) and ventilation holes

(exhaust).

Do not block or place anything near these slots, or internal heat

build-up may occur,

causing picture degradation or damage to the

projector.

6. Power sources

Check that the operating voltage of your unit is identical with the voltage of

your local

power supply.

7. Servicing

Do not attempt to service this projector yourself. Refer all servicing to

qualified service personnel.

Produkspesifikasjoner

Merke:	Optoma
Kategori:	videoprosjektor
Modell:	FW5200
Produkttype:	Standard stråleprojektor
Innebygd skjerm:	Nei
Vekt:	2200 g
Bredde:	280 mm
Dybde:	230 mm
Høyde:	77 mm
Støynivå:	29 dB
Strømkilde:	AC
Bruksanvisning:	Ja
Bluetooth:	Nei
Plassering:	Desktop
Wi-Fi:	Nei
Garantikort:	Ja
Antall farger:	1.073 milliarder farger
Matrisestørrelse:	0.65 "
Antall USB 2.0-porter:	1
Antall HDMI-porter:	1
DVI-port:	Nei
Innebygde høyttalere:	Ja
Antall innebygde høyttalere:	2
Hodetelefonutganger:	1
Full HD:	Nei
HDCP:	Ja
3D:	Ja
Ensartethet:	85
Kontrastforhold:	8000:1
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Strømforbruk (standby):	0.5 W
Projektorens lysstyrke:	3300 ANSI lumen
Projektoroppløsning:	WXGA (1280x800)
Produktfarge:	Sort
Støttede grafikkoppløsninger:	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 800 (WXGA), 1600 x 1200 (UXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Analogt signalformatsystem:	NTSC, PAL, SECAM
Kabler inkludert:	AC, VGA
Visningsteknologi:	DLP
Skjermstørrelsekompabilitet:	30.78 - 315.83 "
Projeksjonsavstand:	1.2 - 1 m
Hjørnesteinsrettelse, vertikal:	-40 - 40 °
Horisontalt frekvensområde:	15.3 - 91.1 kHz
Zoomfunksjon:	Ja
Brennviddeområde:	21 - 25.6 mm
Zoom-type:	Manuell
RS-232-port:	1
Lyskildens tjenestetid:	3500 timer
Strømforbruk (vanlig bruk):	285 W
Støttede videofunksjoner:	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Antall VGA (D-Sub)-porter:	3
Mikrofon, linje-inn-støpsel:	Ja
Strøminngang/AC (strøm) inn:	Ja
Seriell grensesnittype:	RS-232
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Oppbevaringstemperaturomåde (Celsius):	5 - 40 °C
Bærekraftsertifikater:	RoHS
Innebygd kortleser:	Nei
Fjernkontroll medfølger:	Ja
Hurtigstartsguide:	Ja
Driftshøyde:	0 - 3000 m
forskyvning:	112.4
Antall S-Video-innganger:	1
Ethernet/bredbåndsforbindelse:	Ja
Relativ luftfuktighet under drift (H-H):	5 - 85
Komposittvideo inn/sammensatt video inn:	1
RMS-rangert strøm/utgangseffekt:	10 W
Batterier medfølger:	Ja
Lyskildens tjenestetid (økonomisk modus):	6000 timer
Blenderåpning rekkevidde:	2.57 - 2.84
Projeksjonsfaktor:	1.47 - 1.81:1
Type CardBus PCMCIA-port:	Nei
Bæretaske:	Ja
Størrelseforhold:	16:10
Innebygd TV-mottaker:	Nei
Kabellåsport:	Ja
Vertikal scanningsratio:	24 - 120 Hz
Kabellåstype:	Kensington
Zoom-forhold:	1.2:1
3D Ready:	Ja
Maksimal analog oppløsning:	1600 x 1200 piksler
HD-Ready:	Ja
