EN-1

CONTENTS

Usage Notice ....................................................................... 2

Safety Instructions .......................................................................................... 2

Introduction ......................................................................... 5

Projector Features .......................................................................................... 5

Package Contents .......................................................................................... 6

Projector Overview ......................................................................................... 7

Using the Product ............................................................... 9

Control Panel .................................................................................................. 9

Connection Ports .......................................................................................... 10

Remote Control ............................................................................................ 12

Installing the Batteries .................................................................................. 15

Remote Control Operation ............................................................................ 16

Connection ........................................................................ 17

Connecting a computer ................................................................................ 19

Connecting Video source devices ................................................................ 20

Operation ........................................................................... 23

Powering On/Off the Projector ...................................................................... 23

Adjusting the Projector Height ...................................................................... 24

Adjusting the Projector Zoom and Focus ..................................................... 24

Adjusting Projection Image Size ................................................................... 25

Menu Operation ............................................................................................ 27

Appendix ............................................................................ 50

Installing the Dust Filter (Optional accessory) .............................................. 50

Replacing the Lamp ...................................................................................... 51

Ceiling mount installation .............................................................................. 53

Compatibility Modes ..................................................................................... 54

RS232 Commands and Protocol Function List ............................................. 59

Troubleshooting ............................................................................................ 64

Optoma Global Offices ................................................................................. 66

Regulation & Safety Notices ......................................................................... 69

EN-2

Usage Notice

Safety Instructions

Read all of these instructions before you operate your projector and save for

future reference.

1. Read instructions

All the safety and operating instructions should be read before the

appliance is operated.

2. Notes and warnings

All notes and warnings in the operating instructions should be adhered

to.

3. Cleaning

Unplug the projector from the wall socket before cleaning. Use a damp

cloth for cleaning the projector housing. Do not use liquid or aerosol

cleaners.

4. Accessories

Do not place this product on an unstable cart, stand, or table. The product

may fall,

causing serious damage to the product.

Keep the plastic packing materials (from the projector, accessories and

optional parts) out of the reach of children as these bags may result in

death by suffocation. Be particularly careful around the small children.

5. Ventilation

The projector is equipped with ventilation holes (intake) and ventilation holes

(exhaust).

Do not block or place anything near these slots, or internal heat

build-up may occur,

causing picture degradation or damage to the

projector.

6. Power sources

Check that the operating voltage of your unit is identical with the voltage of

your local

power supply.

7. Servicing

Do not attempt to service this projector yourself. Refer all servicing to

qualified service personnel.

Produkspesifikasjoner

Merke:	Optoma
Kategori:	videoprosjektor
Modell:	S311
Produkttype:	Bærbar projektor
Vekt:	2000 g
Bredde:	287 mm
Dybde:	193 mm
Høyde:	113 mm
Støynivå:	- dB
Antall lamper:	1 lamper
Strømkilde:	AC
LED-indikatorer:	Ja
Bruksanvisning:	Ja
Wi-Fi:	Nei
Antall farger:	1.073 milliarder farger
Matrisestørrelse:	0.55 "
Antall USB 2.0-porter:	2
Antall HDMI-porter:	2
DVI-port:	Nei
Innebygde høyttalere:	Ja
Antall innebygde høyttalere:	1
Passordbeskyttelse:	Ja
Hodetelefonutganger:	1
Full HD:	Nei
3D:	Ja
HDMI-versjon:	1.4a
On Screen Display (OSD):	Ja
Ensartethet:	85
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Støttede 3D-formater:	Frame packing, Side by side, Top and bottom
Strømforbruk (standby):	0.5 W
Projektorens lysstyrke:	3200 ANSI lumen
Projektoroppløsning:	SVGA (800x600)
Produktfarge:	Sort
Naturlig sideforhold:	4:3
Støttede grafikkoppløsninger:	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1600 x 1200 (UXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Analogt signalformatsystem:	NTSC, NTSC 3.58, NTSC 4.43, PAL, PAL B, PAL D, PAL G, PAL H, PAL I, PAL M, PAL N, SECAM, SECAM B, SECAM D, SECAM G, SECAM K, SECAM K1, SECAM L
Kabler inkludert:	HDMI
Visningsteknologi:	DLP
Skjermstørrelsekompabilitet:	27.24 - 300.04 "
Projeksjonsavstand:	1.2 - 12 m
Hjørnesteinsrettelse, vertikal:	-40 - 40 °
Horisontalt frekvensområde:	15.3 - 91.1 kHz
Støynivå (økonomisk funksjon):	28 dB
Zoomfunksjon:	Ja
Brennviddeområde:	21.95 - 24.18 mm
Zoom-type:	Manuell
RS-232-port:	1
Lyskildens tjenestetid:	5000 timer
Lyskildetype:	Lampe
Strømforbruk (vanlig bruk):	236 W
Støttede videofunksjoner:	1080i, 480i, 480p, 540p, 576i, 720p
Strøminngang/AC (strøm) inn:	Ja
Seriell grensesnittype:	RS-232
Driftstemperatur (T-T):	5 - 40 °C
Bærekraftsertifikater:	RoHS
Innebygd kortleser:	Nei
Fjernkontroll medfølger:	Ja
Fjernkontrolltype:	IR
Hurtigstartsguide:	Ja
Driftshøyde:	0 - 3000 m
forskyvning:	115
OSD-språk:	ARA, CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, NOR, POL, POR, RUM, RUS, SWE, TUR
Ethernet/bredbåndsforbindelse:	Nei
RMS-rangert strøm/utgangseffekt:	2 W
Batterier medfølger:	Ja
Markedsplassering:	Bærbar
Lampens effekt:	190 W
Lyskildens tjenestetid (økonomisk modus):	7000 timer
Forbruk (økonomimodus):	202 W
Blenderåpning rekkevidde:	2.51 - 2.69
Projeksjonsfaktor:	1.97 - 2.17:1
Type CardBus PCMCIA-port:	Nei
Optisk diskettspillertype:	Ikke inkludert
Bæretaske:	Ja
Kabellåsport:	Ja
Vertikal scanningsratio:	24 - 85 Hz
Kabellåstype:	Kensington
Zoom-forhold:	1.1:1
Støttede forhold:	4:3, 16:9
Matrisetype:	DMD
Kontrastspekter:	20000:1
