Optoma TH1060P Bruksanvisning

Optoma videoprosjektor TH1060P

Les nedenfor 📖 manual på norsk for Optoma TH1060P (57 sider) i kategorien videoprosjektor. Denne guiden var nyttig for 5 personer og ble vurdert med 4.4 stjerner i gjennomsnitt av 3 brukere

Last ned PDF

Side 1/57

English

Table of contents

Table of Contents ...................................................................................1

Usage Notice ..........................................................................................3

Safety Information .........................................................................................3

Precautions....................................................................................................4

Eye Safety Warnings .....................................................................................6

Introduction.............................................................................................7

Package Overview.........................................................................................7

Product Overview ..........................................................................................8

Main Unit ................................................................................................................8

Connection Ports ................................................................................................... 9

Remote Control ....................................................................................................10

Installation ............................................................................................11

Connecting the Projector .............................................................................11

Connect to Notebook ...........................................................................................11

Connect to Video Sources ...................................................................................12

Powering On/O󰘯 the Projector .....................................................................13

Powering On the Projector ...................................................................................13

Powering O󰘯 the Projector ................................................................................... 14

Warning Indicator .................................................................................................14

Adjusting the Projected Image.....................................................................15

Adjusting the Projector's Height ........................................................................... 15

Adjusting Projection Image Size .......................................................................... 16

User Controls .......................................................................................17

Remote Control ...........................................................................................17

On-screen Display Menus ...........................................................................19

How to operate .................................................................................................... 19

Menu Tree ...................................................................................................20

Image ...................................................................................................................21

Image | Advanced ................................................................................................23

Display .................................................................................................................24

System .................................................................................................................26

System | Lamp Settings .......................................................................................28

System | Startup Image .......................................................................................29

System | Network ................................................................................................. 30

Setup .................................................................................................................... 34

Appendicess .........................................................................................38

Troubleshooting ...........................................................................................38

Image ...................................................................................................................38

Other .................................................................................................................... 39

Table of contents

Projector LED Status Indicator ............................................................................. 40

Remote Control ....................................................................................................41

Replacing the Lamp.....................................................................................42

Compatibility Modes ....................................................................................45

RS232 Commands and Protocol Function List............................................46

RS232 Pin Assignments (projector side) ............................................................. 46

RS232 Protocol Function List .............................................................................. 47

Ceiling Mount Installation ............................................................................53

Optoma Global O󰘲ces ................................................................................54

Regulation & Safety Notices ........................................................................56

Produkspesifikasjoner

Merke:	Optoma
Kategori:	videoprosjektor
Modell:	TH1060P
Vekt:	3530 g
Bredde:	326 mm
Dybde:	259 mm
Høyde:	109 mm
Støynivå:	30 dB
Antall lamper:	1 lamper
Bluetooth:	Nei
Plassering:	Tak
Wi-Fi:	Nei
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Antall farger:	1.073 milliarder farger
Matrisestørrelse:	0.65 "
Antall USB 2.0-porter:	1
Antall HDMI-porter:	2
DVI-port:	Nei
Fokus:	Manuell
Innebygde høyttalere:	Ja
Full HD:	Ja
3D:	Nei
Lydutgang:	1
Antall DisplayPorts:	1
Ensartethet:	85
Dimensjoner (B x D x H):	326 x 259 x 109 mm
Kontrastforhold:	2500:1
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Strømforbruk (standby):	1 W
Projektorens lysstyrke:	4500 ANSI lumen
Projektoroppløsning:	1080p (1920x1080)
Produktfarge:	Grå
Støttede grafikkoppløsninger:	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 800 (WXGA), 1400 x 1050 (SXGA+), 1600 x 1200 (UXGA), 1920 x 1080 (HD 1080), 640 x 480 (VGA), 800 x 600 (SVGA)
Analogt signalformatsystem:	NTSC, PAL, SECAM
Kabler inkludert:	Composite, HDMI, RS-232, USB, VGA
Visningsteknologi:	DLP
Skjermstørrelsekompabilitet:	23.6 - 300 "
Projeksjonsavstand:	1 - 10 m
Hjørnesteinsrettelse, vertikal:	-15 - 15 °
Horisontalt frekvensområde:	31 - 90 kHz
Støynivå (økonomisk funksjon):	28 dB
Zoomfunksjon:	Ja
Brennviddeområde:	23.5 - 28.2 mm
Zoom-type:	Manuell
RS-232-port:	1
Lyskildens tjenestetid:	2000 timer
Lyskildetype:	Lampe
Strømforbruk (vanlig bruk):	380 W
Støttede videofunksjoner:	1080i, 1080p, 480i, 480p, 720p
Antall VGA (D-Sub)-porter:	2
Lydinngang (V/H) inn:	1
Komponentvideo (YPbPr/YCbCr) inn:	1
Seriell grensesnittype:	RS-232
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	5 - 40 °C
Innebygd kortleser:	Nei
Fjernkontroll medfølger:	Ja
forskyvning:	115
Lampetype:	P-VIP
Antall S-Video-innganger:	1
Ethernet/bredbåndsforbindelse:	Ja
Komposittvideo inn/sammensatt video inn:	1
RMS-rangert strøm/utgangseffekt:	3 W
Batterier medfølger:	Ja
Lampens effekt:	300 W
Lyskildens tjenestetid (økonomisk modus):	3000 timer
Type CardBus PCMCIA-port:	Nei
Optisk diskettspillertype:	Ikke inkludert
Bæretaske:	Ja
Kabellåsport:	Ja
Vertikal scanningsratio:	50 - 85 Hz
Kabellåstype:	Kensington
Lydkontakter:	1
Zoom-forhold:	1.2:1
3D Ready:	Nei
Optisk digital lydutgang:	1
HD-Ready:	Ja
