Optoma TW766W Bruksanvisning

Optoma videoprosjektor TW766W

Les nedenfor 📖 manual på norsk for Optoma TW766W (99 sider) i kategorien videoprosjektor. Denne guiden var nyttig for 8 personer og ble vurdert med 4.4 stjerner i gjennomsnitt av 4.5 brukere

Last ned PDF

Side 1/99

English

Table of Contents ...................................................................................1

Usage Notice ..........................................................................................2

Safety Information .........................................................................................2

Precautions....................................................................................................3

Eye Safety Warnings .....................................................................................5

Product Features ...........................................................................................5

Introduction.............................................................................................6

Package Overview.........................................................................................6

Product Overview ..........................................................................................7

Main Unit ................................................................................................................ 7

Control Panel ......................................................................................................... 8

Input / Output Connections .................................................................................... 9

Remote Control .................................................................................................... 11

Installation ............................................................................................12

Connecting the Projector .............................................................................12

Connect to Computer/Notebook .......................................................................... 12

Connect to Video Sources ................................................................................... 13

Powering On/Off the Projector .....................................................................15

Powering On the Projector ................................................................................... 15

Powering Off the projector ................................................................................... 16

Warning Indicator ................................................................................................. 16

Adjusting the Projected Image.....................................................................17

Adjusting the Projector’s Height ........................................................................... 17

Adjusting the Projector’s Zoom / Focus ............................................................... 18

Adjusting Projected Image Size ........................................................................... 18

Adjusting Projected Image Position Using PureShift ........................................... 19

User Controls ....................................................................................... 21

Control Panel & Remote Control .................................................................21

Control Panel ....................................................................................................... 21

Remote Control .................................................................................................... 22

Using the USB Remote Mouse Control ............................................................... 24

Using the ENTER / HELP button ......................................................................... 24

On-screen Display Menus ...........................................................................27

How to operate .................................................................................................... 27

Menu Tree ............................................................................................................ 28

Image ................................................................................................................... 29

Display ................................................................................................................. 32

Setup .................................................................................................................... 37

Options ................................................................................................................. 49

Appendices...........................................................................................52

Troubleshooting ...........................................................................................52

Image Problems .................................................................................................. 52

Other Problems ................................................................................................... 55

Projector Status Indication .................................................................................. 55

Remote Control Problems ................................................................................... 56

Replacing the Lamp.....................................................................................57

Compatibility Modes ....................................................................................59

RS232 Commands ......................................................................................60

Ceiling Mount Installation ............................................................................63

Optoma Global Ofces ................................................................................64

Regulation & Safety notices ........................................................................66

Wireless .......................................................................................................... 68

Table of Contents

Produkspesifikasjoner

Merke:	Optoma
Kategori:	videoprosjektor
Modell:	TW766W
Produkttype:	Standard stråleprojektor
Vekt:	5400 g
Bredde:	364 mm
Dybde:	283 mm
Høyde:	127 mm
Støynivå:	30 dB
Antall lamper:	1 lamper
Strømkilde:	AC
Bruksanvisning:	Ja
Plassering:	Desktop, Ceiling
Garantikort:	Ja
Antall farger:	134 million farger
Matrisestørrelse:	0.65 "
Antall USB 2.0-porter:	1
Antall HDMI-porter:	1
DVI-port:	Ja
Fokus:	Manuell
Innebygde høyttalere:	Ja
Antall innebygde høyttalere:	2
Full HD:	Nei
HDCP:	Ja
Ensartethet:	85
Kontrastforhold:	2500:1
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Strømforbruk (standby):	1 W
Projektorens lysstyrke:	4000 ANSI lumen
Projektoroppløsning:	WXGA (1280x800)
Produktfarge:	Sort
Naturlig sideforhold:	16:10
Støttede grafikkoppløsninger:	1024 x 768 (XGA), 1400 x 1050 (SXGA+), 1600 x 1200 (UXGA), 1920 x 1200 (WUXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Analogt signalformatsystem:	NTSC, PAL, SECAM
Kabler inkludert:	RS-232, USB, VGA
Visningsteknologi:	DLP
Skjermstørrelsekompabilitet:	23.2 - 295.7 "
Projeksjonsavstand:	1.2 - 10 m
Hjørnesteinsrettelse, vertikal:	- 30 - 30 °
Horisontalt frekvensområde:	15 - 91 kHz
Støynivå (økonomisk funksjon):	23 dB
Zoomfunksjon:	Ja
Brennviddeområde:	22.18 - 33.2 mm
Horisontal linseforskyvning:	-30 - 20 °
Zoom-type:	Manuell
RS-232-port:	1
Lyskildens tjenestetid:	2000 timer
Lyskildetype:	Lampe
Strømforbruk (vanlig bruk):	350 W
Støttede videofunksjoner:	1080i, 1080p, 480i, 480p, 720p
Antall VGA (D-Sub)-porter:	3
Komponentvideo (YPbPr/YCbCr) inn:	1
Seriell grensesnittype:	RS-232
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	5 - 35 °C
Innebygd kortleser:	Nei
Fjernkontroll medfølger:	Ja
Hurtigstartsguide:	Ja
forskyvning:	105
Lampetype:	UHP
Antall S-Video-innganger:	1
Ethernet/bredbåndsforbindelse:	Ja
Komposittvideo inn/sammensatt video inn:	1
RMS-rangert strøm/utgangseffekt:	2 W
Lampens effekt:	280 W
Lyskildens tjenestetid (økonomisk modus):	3000 timer
Blenderåpning rekkevidde:	2.41 - 3.2
Projeksjonsfaktor:	1.57 - 2.39:1
Optisk diskettspillertype:	Ikke inkludert
Kabellåsport:	Ja
Vertikal scanningsratio:	50 - 85 Hz
Kabellåstype:	Kensington
Zoom-forhold:	1.5:1
Støttede forhold:	4:3, 16:9, 16:10
