Optoma W316ST Bruksanvisning

Optoma videoprosjektor W316ST

Les nedenfor 📖 manual på norsk for Optoma W316ST (74 sider) i kategorien videoprosjektor. Denne guiden var nyttig for 7 personer og ble vurdert med 3.7 stjerner i gjennomsnitt av 4 brukere

Last ned PDF

Side 1/74

English

Table of Contents ............................1

Usage Notice

...................................2

Safety Information ...............................2

Precautions

.........................................3

Eye Safety Warnings

..........................5

Product Features

................................5

Introduction ......................................6

Package Overview ..............................6

Product Overview

...............................7

Main Unit .............................................. 7

Control Panel

....................................... 8

Input/Output Connections

.................... 9

Remote Control

.................................. 10

Installation .....................................11

Connecting the Projector ..................11

Connect to Computer/Notebook ........ 11

Connect to Video Sources

................. 12

Powering the Projector On / Off ........13

Powering On the Projector ................. 13

Powering off the projector

.................. 14

Warning Indicator

............................... 14

Adjusting the Projected Image ..........15

Adjusting the Projector’s Height ........15

Adjusting the Projector’s Zoom /

Focus

................................................. 16

Adjusting Projection Image Size

........ 17

User Controls ................................20

Control Panel & Remote Control ......20

Control Panel ..................................... 20

Remote Control

.................................. 21

On-screen Display Menus ................28

How to operate .................................. 28

Menu Tree

.......................................... 29


............................................... 31

IMAGE | Advanced

............................ 33

IMAGE | Advanced | Signal (RGB)

... 35

DISPLAY

............................................ 36

DISPLAY | 3D

................................... 39

SETUP

............................................... 40

SETUP | Security

............................... 42

SETUP | Audio Settings

..................... 44

SETUP | LAN Settings

....................... 45

SETUP | Advanced

............................ 47

OPTIONS

........................................... 48

OPTIONS | Remote Settings

............. 50

OPTIONS | Advanced

........................ 51

OPTIONS | Lamp Settings

................. 52

OPTIONS | Optional Filter Settings

... 53

Appendices ....................................54

Troubleshooting ................................54

Replacing the Lamp

..........................60

Installing and Cleaning the Filter

......62

Compatibility Modes

.........................63

Computer/Video/HDMI/Mac

Compatibility ...................................... 63

3D Input Video Compatibility

.............64

RS232 Commands and Protocol

Function List

.....................................65

RS232 Pin Assignments .................... 65

RS232 Protocol Function List

............ 66

Ceiling Mount Installation ..................70

Optoma Global Ofces

.....................71

Regulation & Safety Notices

.............73

Table of Contents

English

Usage Notice

Safety Information

The lightning ash with arrow head within an equilateral triangle is

intended to alert the user to the presence of uninsulated “dangerous

voltage” within the product’s enclosure that may be of sufcient

magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert

the user to the presence of important operating and maintenance

(servicing) instructions in the literature accompanying the appliance.

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT

EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. DANGEROUS HIGH

VOLTAGES ARE PRESENT INSIDE THE ENCLOSURE. DO NOT OPEN THE

CABINET. REFER SERVICING TO QUALIFIED PERSONNEL ONLY.

Class B emissions limits

This Class B digital apparatus meets all requirements of the Canadian

Interference-Causing Equipment Regulations.

Important Safety Instruction

1. Do not block any ventilation openings. To ensure reliable operation of

the projector and to protect from over heating, it is recommended to

install the projector in a location that does not block ventilation. As an

example, do not place the projector on a crowded coffee table, sofa,

bed, etc. Do not put the projector in an enclosure such as a book case

or a cabinet that restricts air ow.

2. Do not use the projector near water or moisture. To reduce the risk

of re and/or electric shock, do not expose the projector to rain or

moisture.

3. Do not install near heat sources such as radiators, heaters, stoves or

any other apparatus such as ampliers that emits heat.

4. Clean only with dry cloth.

5. Only use attachments/accessories specied by the manufacturer.

6. Do not use the unit if it has been physically damaged or abused.

Physical damage/abuse would be (but not limited to):

 Unit has been dropped.



Power supply cord or plug has been damaged.



Liquid has been spilled on to the projector.

 Projector has been exposed to rain or moisture.



Something has fallen in the projector or something is loose inside.

Do not attempt to service the unit yourself. Opening or removing covers

may expose you to dangerous voltages or other hazards. Please call

Optoma before you send the unit for repair.

7. Do not let objects or liquids enter the projector. They may touch

dangerous voltage points and short out parts that could result in re or

electric shock.

8. See projector enclosure for safety related markings.

9. The unit should only be repaired by appropriate service personnel.

Produkspesifikasjoner

Merke:	Optoma
Kategori:	videoprosjektor
Modell:	W316ST
Produkttype:	Projektor med kort stråle
Vekt:	2770 g
Bredde:	314 mm
Dybde:	224 mm
Høyde:	101 mm
Støynivå:	- dB
Antall lamper:	1 lamper
Strømkilde:	AC
LED-indikatorer:	Ja
Bruksanvisning:	Ja
Plassering:	Desktop
USB-kontakttype:	Mini-USB B
Garantikort:	Ja
Antall farger:	1.073 milliarder farger
Matrisestørrelse:	0.65 "
Antall USB 2.0-porter:	1
Antall HDMI-porter:	1
DVI-port:	Nei
Innebygde høyttalere:	Ja
Antall innebygde høyttalere:	1
Hodetelefonutganger:	1
Full HD:	Nei
3D:	Ja
HDMI-versjon:	1.4a
On Screen Display (OSD):	Ja
Kompatible produkter:	80
Ensartethet:	80
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Støttede 3D-formater:	Frame packing, Side by side, Top and bottom
Strømforbruk (standby):	0.5 W
Projektorens lysstyrke:	3600 ANSI lumen
Projektoroppløsning:	WXGA (1280x800)
Produktfarge:	Hvit
Naturlig sideforhold:	16:10
Støttede grafikkoppløsninger:	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 800 (WXGA), 1400 x 1050 (SXGA+), 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 1920 x 1200 (WUXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Analogt signalformatsystem:	NTSC, PAL, SECAM
Visningsteknologi:	DLP
Skjermstørrelsekompabilitet:	- "
Projeksjonsavstand:	0.5 - 3.4 m
Hjørnesteinsrettelse, vertikal:	-40 - 40 °
Horisontalt frekvensområde:	15.375 - 91.1 kHz
Støynivå (økonomisk funksjon):	29 dB
Brennviddeområde:	- mm
RS-232-port:	1
Lyskildens tjenestetid:	4000 timer
Lyskildetype:	Lampe
Strømforbruk (vanlig bruk):	280 W
Støttede videofunksjoner:	1080i, 1080p, 480i, 480p, 720p
Antall VGA (D-Sub)-porter:	3
Strøminngang/AC (strøm) inn:	Ja
Seriell grensesnittype:	RS-232
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	5 - 40 °C
Bærekraftsertifikater:	RoHS
Innebygd kortleser:	Nei
Fjernkontroll medfølger:	Ja
Fjernkontrolltype:	IR
Hurtigstartsguide:	Ja
forskyvning:	112
Antall S-Video-innganger:	1
Ethernet/bredbåndsforbindelse:	Ja
Komposittvideo inn/sammensatt video inn:	1
RMS-rangert strøm/utgangseffekt:	10 W
Batterier medfølger:	Ja
Markedsplassering:	Short throw
Lampens effekt:	210 W
Lyskildens tjenestetid (økonomisk modus):	7000 timer
Forbruk (økonomimodus):	194 W
Projeksjonsfaktor:	0.52:1
Type CardBus PCMCIA-port:	Nei
Optisk diskettspillertype:	Ikke inkludert
Kabellåsport:	Ja
Vertikal scanningsratio:	24 - 120 Hz
Kabellåstype:	Kensington
Støttede forhold:	4:3, 16:9, 16:10
Matrisetype:	DMD
Kontrastspekter:	20000:1
