EN-1

CONTENTS

Usage Notice .....................................................................................2

Safety Instructions ................................................................................................................. 2

Introduction .......................................................................................5

Projector Features ................................................................................................................. 5

Package Contents ................................................................................................................. 6

Projector Overview ................................................................................................................ 7

Using the Product .............................................................................9

Control Panel ......................................................................................................................... 9

Connection Ports ................................................................................................................. 10

Remote Control ................................................................................................................... 12

Installing the Batteries ......................................................................................................... 15

Remote Control Operation ................................................................................................... 16

Connection ......................................................................................17

Connecting a computer or monitor ...................................................................................... 19

Connecting Video source devices ....................................................................................... 21

Operation .........................................................................................24

Powering On/Off the Projector ............................................................................................. 24

Adjusting the Projector Height ............................................................................................. 25

Adjusting the Projector Zoom and Focus ............................................................................ 25

Adjusting Projection Image Size .......................................................................................... 26

Menu Operation ................................................................................................................... 30

Controlling the projector through a LAN environment ......................................................... 50

Controlling the projector through a web browser ................................................................. 54

Displaying images through Optoma Presenter .................................................................... 61

Displaying pictures with a USB storage device ................................................................... 65

Appendix ..........................................................................................69

Replacing the Dust Filter ..................................................................................................... 69

Replacing the Lamp .............................................................................................................70

Ceiling mount installation .....................................................................................................72

Compatibility Modes ............................................................................................................73

IR Code ............................................................................................................................... 76

Telnet Commands ............................................................................................................... 78

PJLink commands ............................................................................................................... 79

AMX Device Discovery commands ..................................................................................... 80

RS232 Commands and Protocol Function List .................................................................... 81

Troubleshooting ................................................................................................................... 87

Optoma Global Offices ........................................................................................................ 89

Regulation & Safety Notices ................................................................................................ 92

EN-2

Usage Notice

Safety Instructions

Read all of these instructions before you operate your projector and save for future reference.

1. Read instructions

All the safety and operating instructions should be read before the

appliance is operated.

2. Notes and warnings

All notes and warnings in the operating instructions should be adhered

to.

3. Cleaning

Unplug the projector from the wall socket before cleaning. Use a damp

cloth for cleaning the projector housing. Do not use liquid or aerosol

cleaners.

4. Accessories

Do not place this product on an unstable cart, stand, or table. The product

may fall,

causing serious damage to the product.

Keep the plastic packing materials (from the projector, accessories and

optional parts) out of the reach of children as these bags may result in

death by suffocation. Be particularly careful around the small children.

5. Ventilation

The projector is equipped with ventilation holes (intake) and ventilation holes

(exhaust).

Do not block or place anything near these slots, or internal heat

build-up may occur,

causing picture degradation or damage to the

projector.

6. Power sources

Check that the operating voltage of your unit is identical with the voltage of

your local

power supply.

7. Servicing

Do not attempt to service this projector yourself. Refer all servicing to

qualified service personnel.

8. Replacement parts

When replacement parts are required, be sure that the replacement

parts are

specified by the manufacture. Unauthorized substitutions may

result in fire, electric

shock or other hazards.

EN-3

9. Moisture Condensation

Never operate this projector immediately after moving it from a cold

location to a warm one. When the projector is exposed to such a

change in temperature, moisture may condense on the lens and the

crucial internal parts. To prevent the unit from possible damage, do not

use the projector for at least 2 hours when there is an extreme or

sudden change in temperature.

Produkspesifikasjoner

Merke:	Optoma
Kategori:	videoprosjektor
Modell:	W501
Vekt:	2360 g
Bredde:	386 mm
Dybde:	279 mm
Høyde:	152 mm
Støynivå:	27 dB
Antall lamper:	1 lamper
Strømkilde:	AC
LED-indikatorer:	Ja
Bruksanvisning:	Ja
Bluetooth:	Nei
USB-kontakttype:	USB Type-A, USB Type-B
Garantikort:	Ja
Antall farger:	1.073 milliarder farger
Matrisestørrelse:	0.65 "
Antall USB 2.0-porter:	4
Antall HDMI-porter:	1
DVI-port:	Ja
Fokus:	Manuell
Innebygde høyttalere:	Ja
Antall innebygde høyttalere:	2
Hodetelefonutganger:	1
Full HD:	Nei
3D:	Ja
HDMI-versjon:	1.4
On Screen Display (OSD):	Ja
Ensartethet:	85
Kontrastforhold:	15000:1
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Strømforbruk (standby):	0.5 W
Projektorens lysstyrke:	5000 ANSI lumen
Projektoroppløsning:	UXGA (1600x1200)
Produktfarge:	Sort
Naturlig sideforhold:	16:10
Støttede grafikkoppløsninger:	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 768 (WXGA), 1280 x 800 (WXGA), 1360 x 768 (WXGA), 1400 x 1050 (SXGA+), 1600 x 1200 (UXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Analogt signalformatsystem:	NTSC, PAL, SECAM
Kabler inkludert:	VGA
Visningsteknologi:	DLP
Skjermstørrelsekompabilitet:	23.4 - 300 "
Projeksjonsavstand:	1 - 10 m
Hjørnesteinsrettelse, vertikal:	-40 - 40 °
Horisontalt frekvensområde:	15.3 - 91.1 kHz
Zoomfunksjon:	Ja
Brennviddeområde:	20.77 - 31.13 mm
Zoom-type:	Manuell
RS-232-port:	1
Lyskildens tjenestetid:	2500 timer
Lyskildetype:	Lampe
Strømforbruk (vanlig bruk):	355 W
Antall VGA (D-Sub)-porter:	3
Lydinngang (V/H) inn:	1
Mikrofon, linje-inn-støpsel:	Ja
Strøminngang/AC (strøm) inn:	Ja
Seriell grensesnittype:	RS-232
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	5 - 45 °C
Innebygd kortleser:	Nei
Fjernkontroll medfølger:	Ja
Fjernkontrolltype:	IR
Hurtigstartsguide:	Ja
forskyvning:	112
Antall S-Video-innganger:	1
Lampestrøm (økonomisk modus):	4000 W
Ethernet/bredbåndsforbindelse:	Ja
Komposittvideo inn/sammensatt video inn:	1
RMS-rangert strøm/utgangseffekt:	30 W
Batterier medfølger:	Ja
Lampens effekt:	280 W
Blenderåpning rekkevidde:	2.42 - 2.98
Projeksjonsfaktor:	1.45 - 2.17:1
Type CardBus PCMCIA-port:	Nei
Optisk diskettspillertype:	Ikke inkludert
Kabellåsport:	Ja
Vertikal scanningsratio:	24 - 85 Hz
Kabellåstype:	Kensington
Zoom-forhold:	1.5:1
Støttede forhold:	4:3, 16:9, 16:10
3D-briller medfølger:	Nei
Innebygget touchpad:	Nei
Progressiv skanningsoutput:	Ja
