Side 1/108

English

Table of Contents ............................1

Usage Notice ...................................2

Safety Information ...............................2

Precautions .........................................3

Eye Safety Warnings ...........................5

Product Features ................................5

Introduction ......................................6

Package Overview ..............................6

Product Overview ................................7

Main Unit .............................................. 7

Control Panel .......................................8

Input/Output Connections .................... 9

Remote Control .................................. 10

Installation .....................................11

Connecting to the Projector ..............11

Connecting a Computer/Notebook .... 11

Connecting a Video source ................ 12

Connect to 3D Video Devices ...........13

Using the 3D glasses ........................15

Powering On/Off the Projector ..........16

Powering On the Projector ................. 16

Powering Off the Projector ................. 17

Warning Indicator ............................... 18

Adjusting the Projected Image ..........19

Adjusting the Projector’s Height ........ 19

Adjusting the Projector’s Focus..........20

Adjusting Projection Image Size ........ 20

User Controls.................................23

Control Panel & Remote Control .......23

Control Panel .....................................23

Remote Control .................................. 24

On-screen Display Menus .................27

How to operate .................................. 27

Menu Tree .......................................... 28

IMAGE ...............................................35

IMAGE | Advanced ............................38

DISPLAY ............................................43

DISPLAY | 3D ................................... 48

SETUP ............................................... 50

SETUP | Audio Settings .....................53

SETUP | Security ...............................55

SETUP | Network ...............................57

SETUP | Network|LAN Settings ......... 58

SETUP | Network|Control Settings .... 60

SETUP | Signal (RGB) .......................70

SETUP | Signal (Video) ..................... 72

SETUP | Advanced ............................73

OPTIONS ........................................... 75

OPTIONS | Lamp Settings .................79

OPTIONS | Advanced ........................81

OPTIONS | Remote Settings ............. 83

OPTIONS | Filter Settings ..................84

Appendices ....................................85

Troubleshooting .................................85

Image Problems ................................. 85

Other Problems .................................. 87

Remote Control Problems ................. 87

LED Lighting Messages ..................... 88

On Screen Messages ........................89

Replacing the Lamp ..........................90

Installing and Cleaning the

Dust Filter .........................................92

Compatibility Modes .........................93

RS232 Commands and

Protocol Function List .......................95

RS232 Pin Assignments .................... 95

RS232 Protocol Function List ............96

Ceiling Mount Installation ................104

Optoma Global Offices ...................105

Regulation & Safety Notices ...........107

FCC Notice ......................................107

Declaration of Conformity for

EU countries ....................................108

Table of Contents

English

Usage Notice

The lightning flash with arrow head within an equilateral triangle is

intended to alert the user to the presence of uninsulated “dangerous volt-

age” within the product’s enclosure that may be of sufficient magnitude to

constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert

the user to the presence of important operating and maintenance (servic-

ing) instructions in the literature accompanying the appliance.

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT

EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. DANGEROUS HIGH

VOLTAGES ARE PRESENT INSIDE THE ENCLOSURE. DO NOT OPEN THE

CABINET. REFER SERVICING TO QUALIFIED PERSONNEL ONLY.

Class B emissions limits

This Class B digital apparatus meets all requirements of the Canadian Inter-

ference-Causing Equipment Regulations.

Important Safety Instruction

1. Do not block any ventilation openings. To ensure reliable operation of the

projector and to protect from over heating, it is recommended to install the

projector in a location that does not block ventilation. As an example, do

not place the projector on a crowded coffee table, sofa, bed, etc. Do not

put the projector in an enclosure such as a book case or a cabinet that

restricts air flow.

2. Do not use the projector near water or moisture. To reduce the risk of fire

and/or electric shock, do not expose the projector to rain or moisture.

3. Do not install near heat sources such as radiators, heaters, stoves or any

other apparatus such as amplifiers that emits heat.

4. Clean only with dry cloth.

5. Only use attachments/accessories specified by the manufacturer.

6. Do not use the unit if it has been physically damaged or abused. Physical

damage/abuse would be (but not limited to):

Unit has been dropped. -

Power supply cord or plug has been damaged. -

Liquid has been spilled on to the projector. -

Projector has been exposed to rain or moisture. -

Something has fallen in the projector or something is loose inside. -

Do not attempt to service the unit yourself. Opening or removing covers

may expose you to dangerous voltages or other hazards. Please call

Optoma before you send the unit for repair.

7. Do not let objects or liquids enter the projector. They may touch danger-

ous voltage points and short out parts that could result in fire or electric

shock.

8. See projector enclosure for safety related markings.

9. The unit should only be repaired by appropriate service personnel.

Safety Information

Produkspesifikasjoner

Merke:	Optoma
Kategori:	videoprosjektor
Modell:	X319USTir
Produkttype:	Ultrakort stråleprojektor
Innebygd skjerm:	Nei
Vekt:	4570 g
Bredde:	385 mm
Dybde:	310 mm
Høyde:	99 mm
Støynivå:	26 dB
Antall lamper:	1 lamper
Strømkilde:	AC
Bruksanvisning:	Ja
Plassering:	Desktop
Wi-Fi:	Nei
USB-kontakttype:	USB Type-A
Antall farger:	1.073 milliarder farger
Matrisestørrelse:	0.55 "
Antall USB 2.0-porter:	1
Antall HDMI-porter:	2
DVI-port:	Nei
Innebygde høyttalere:	Ja
Antall innebygde høyttalere:	1
Hodetelefonutganger:	1
Full HD:	Nei
3D:	Ja
On Screen Display (OSD):	Ja
Ensartethet:	85
Kontrastforhold:	18000:1
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Støttede 3D-formater:	Frame packing, Side by side
Strømforbruk (standby):	0.5 W
Projektorens lysstyrke:	3200 ANSI lumen
Projektoroppløsning:	XGA (1024x768)
Produktfarge:	Grå
Naturlig sideforhold:	4:3
Støttede grafikkoppløsninger:	640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1360 x 768 (WXGA), 1600 x 1200 (UXGA)
Analogt signalformatsystem:	NTSC, NTSC 3.58, NTSC 4.43, NTSC M, PAL, PAL B, PAL D, PAL G, PAL H, PAL I, PAL M, PAL N, SECAM, SECAM B, SECAM D, SECAM G, SECAM K, SECAM K1, SECAM L
Kabler inkludert:	AC, VGA
Visningsteknologi:	DLP
Skjermstørrelsekompabilitet:	70 - 100 "
Projeksjonsavstand:	0.47 - 0.68 m
Hjørnesteinsrettelse, vertikal:	-20 - 20 °
Horisontalt frekvensområde:	15.3 - 91.1 kHz
Brennviddeområde:	- mm
RS-232-port:	1
Lyskildens tjenestetid:	4500 timer
Lyskildetype:	Lampe
Strømforbruk (vanlig bruk):	235 W
Støttede videofunksjoner:	480i, 480p, 720p, 1080i, 1080p
Antall VGA (D-Sub)-porter:	3
HDMI-kontakttype:	Full-size
Mikrofon, linje-inn-støpsel:	Ja
Strøminngang/AC (strøm) inn:	Ja
Seriell grensesnittype:	RS-232
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	5 - 40 °C
Bærekraftsertifikater:	RoHS
Innebygd kortleser:	Nei
Fjernkontroll medfølger:	Ja
Hurtigstartsguide:	Ja
Driftshøyde:	0 - 3000 m
forskyvning:	117
Ethernet/bredbåndsforbindelse:	Ja
Relativ luftfuktighet under drift (H-H):	0 - 85
Komposittvideo inn/sammensatt video inn:	1
RMS-rangert strøm/utgangseffekt:	16 W
Batterier medfølger:	Ja
Lampens effekt:	190 W
Lyskildens tjenestetid (økonomisk modus):	7000 timer
Forbruk (økonomimodus):	200 W
Projeksjonsfaktor:	0.33:1
Kabellåsport:	Ja
Vertikal scanningsratio:	24 - 85 Hz
Kabellåstype:	Kensington
Zoom-forhold:	Fiksert
Støttede forhold:	16:9
Støttede Mac operativsystemer:	Ja
