Side 1/14
Installation Instruction
NN-TK510FS/FW/FB
Trim kit
24”cabinet
(596mm)
NN-TK510FS
NN-TK510FW
NN-TK510FB
Contents
Attention P2 .............................................................................................................................................
Step1. Unpacking list P3 ..........................................................................................................................
Step2. Feature diagram P4 ......................................................................................................................
Step3. Cabinet Preparation P5-7 ............................................................................................................
Step4. Microwave Oven Installation P8 ...................................................................................................
Step5. Cabinet Installation............................................................................................................ P9-10
Step6. Finishing Installation........................................................................................................ P11-13
2
1. This trim kit can be installed into a cabinet.
The cabinet opening must have the following
internal dimensions as shown in , . g 1 p 5-7
A vent is required at the rear of the cabinet, it
should not be obstructed.
2. Electrical Connections The appliance is
supplied with a mains plug attached and
should only be connected into an earthed
socket that has been installed according to
the relevant safety regulations.
If the plug is no longer accessible after the
appliance has been built into the cabinet, a
dual pole isolator must be installed to conform
to the relevant safety standards.
3.Itisessentialthatthecabinetisxedtothe
wall for stability. The shelf must be able to
support a weight of 30 kg.
4. If the microwave oven is to be removed from
the kitchen cabinet and used free standing,
the built in parts must be removed, and the
oven returned to its original condition. Keep
these installation instructions for future
reference so the installation process can be
reversed.
TAKE CARE NOT TO KINK OR TRAP THE
MICROWAVE ELECTRICAL CABLE.
The diagram may vary from the actual unit
and is only for your reference.
3
Step1. Unpacking list
Tools Needed
• Measuring tape
• Pencil
• Driver
• Ø2 drill
Parts Supplied
PART QUANTITY
Trim Frame 1
Right Duct 1
Left Duct 1
Rail 2
Bracket 4
Catch 4
Tape 4
Screw 12
Strike 4
