Side 1/256
1
i
19
INSTRUMENTS and CONTROLS
PETROL - DIESEL MANUAL OR AUTOMATIC GEARBOX
INSTRUMENT PANELS
Panel grouping together the vehicle
operation indication dials and warning
lamps.
5. Screen .
6. Display management button.
Recalls the service information.
Resets the selected function to zero
(trip distance recorder or service
indicator).
7. Instrument panel lighting button.
Adjusts the brightness of the lighting
of the instruments and controls.
Dials
1. Rev counter.
Indicates the speed of rotation of the
engine (x 1000 rpm).
2. Coolant temperature.
Indicates the temperature of the
engine coolant (°Celsius).
3. Fuel level.
Indicates the quantity of fuel
remaining in the tank.
4. Vehicle speed.
Indicates the current speed of the
moving vehicle (mph or km/h).
A. Speed limiter
(mph or km/h) or
Cruise control.
B. Gear change indicator.
C. Automatic gearbox.
D. Trip distance recorder.
(miles or km)
E. Service indicator.
(miles or km) then,
engine oil level indicator
then
distance recorder.
(miles or km)
These three functions are displayed
in succession when the ignition is
switched on.
Display
For further information, refer to the
paragraph relating to the button or
function and its associated display.
1
i
20
INSTRUMENTS and CONTROLS
PETROL - DIESEL MANUAL OR AUTOMATIC GEARBOX
INSTRUMENT PANELS
Panel grouping together the vehicle
operation indication dials and warning
lamps.
5. Small screen .
6. Large central screen .
7. Display management button.
Starts a manual CHECK.
Recalls the service information.
Resets the function selected to zero
(trip distance recorder or service
indicator).
8. Instrument panel lighting button.
Adjusts the brightness of the lighting
of the instruments and controls.
Dials
1. Rev counter.
Indicates the speed of rotation of the
engine (x 1000 rpm).
2. Coolant temperature.
Indicates the temperature of the
engine coolant (°Celsius).
3. Fuel level.
Indicates the quantity of fuel
remaining in the tank.
4. Vehicle speed.
Indicates the current speed of the
moving vehicle (mph or km/h).
A. Trip distance recorder.
(miles or km)
B. Distance recorder.
(miles or km)
C. Engine oil level indicator,
service indicator.
(miles or km)
These two functions are displayed
when the ignition is switched on,
then disappear after a few seconds.
Displays
For further information, refer to the
paragraph which relates to the but-
ton or function and its associated
display.
The following functions are displayed in
accordance with the selection.
- Warning lamps/CHECK.
- Tyre under-infl ation detection.
- Speed limiter/Cruise control.
- Gear change indicator.
- Automatic gearbox.
-
Navigation - Guidance/Trip computer.
