1
OWNER’S MANUAL SUPPLEMENT
2001 325 Magnum 2x4, HDS
PN 9916829
IMPORTANT: This is a supplement to your owner’s manual. This information should remain with your owner’s manual at all
times.
Capacities
Body Style Gen IV
Gross Vehicle Weight 1060
Fuel Capacity 3.75 U.S. Gallons
Engine Oil Capacity 1.9 quarts
Front Rack (Maximum -
Capacity)
90 Lbs.
Rear Rack 180 Lbs.
Tongue Weight 30 Lbs.
Tow Hitch Standard
Tow Capacity 850 Lbs
T urn Radius 65²
Ground Clearance 7.25²
Height 46²
Length 81²
Seat Height 34²
Dry Weight 574 Lbs.
Wheel Base 49.75²
Width 46²
Drive System
Drive System Type PVT
Shift Type Side Lever
Rear Drive (ratio) 3.1 / 1
Front Tire 24 x 8 - 12
Rear Tire 24 x 11.5 - 10
Tire Pressure (front) 4
Tire Pressure (rear) 3
Suspension and Brakes
Front Susp. - Mac Strut 6.7²
Rear Susp. - Progresseive
Rate Swing Arm
7²
Shock Adjustment 2² Gas Charged Mono-
tube Cam
Front Brake Hydraulic Disc
Rear Brake Hydraulic Disc
Auxiliary Brake Hydraulic Disc
Park Brake Hydraulic Lock, All Wheel
Engine & Cooling
Engine Model Number ES32PFE06
Engine Type 4 Stroke, Single Cylinder
Lubrication Wet Sump
Bore x Stroke 78 x 68
Displacement 324
Compression Ratio 9.2 Full Stroke
Engine Cooling Air with Fan Assisted Oil
Cooler
Alternator Output (watts) 200
Carburetion 1 / BST 31 (CV T ype)
Main Jet 145
Pilot Jet 50
Needle Jet P-2 (829)
Pilot Screw 2 T urns
Jet Needle 5-F14-3
Ignition CDI
Timing 30° @ 5000 ± 2
Spark Plug Gap .036 inches
Spark Plug Type NGK BKR 6E
Exhaust USFS Approval Pending
Features
Headlight (watts) Grill - Hi/Lo 30 W
Taillight (watts) 12 V / 8.26 W
Brake Light (watts) 12 V / 26.9 W
Battery 12 V / 14 AH
DC Plug In - Rear Accessory
DC Socket - Forward Accessory
Electric Start Standard
High Beam Indicator Standard
High Temp Indicator Standard
Windshield Accessory
Low Oil Light Not Applicable
Neutral Indicator Standard
Reverse Indicator Standard
Speedometer, km/hr Standard
Tool Kit Standard
2
Carburetor Jetting Clutching Chart
Altitude AMBIENT
TEMPERATURE
Below +40° F
Below +5° C
+40° F&
Above
+5° C&
Above
Altitude Shift
Weight
Clutch
Spring
Driven
Helix
Driven
Helix
Meters
(Feet)
0-1800
(0-6000)
150
145 Meters
(Feet)
0-1800
(0-6000)
16
5630279
Blue/
Green
7041157
Black
7041782
44-36°
5132344
2-2
1800 & above
(6000 & above)
142.5 137.5 1800 & above
(6000 & above)
16 Mod
5630280
Blue/
Green
7041157
Black
7041782
44-36°
5132344
2-2
44 - 36° helix, black driven spring
PN 9916829 Rev 01 9/00
E 2000 Polaris Sales Inc.
Printed in U.S.A.
1
OWNER’S MANUAL SUPPLEMENT
2001 MAGNUM 325 4X4
PN 9916401
IMPORTANT: This is a supplement to your owner’s manual. This information should remain with your owner’s manual at all
times.
Capacities
Body Style Gen IV
Gross Vehicle Weight 1125
Fuel Capacity 3.75 U.S. Gal
Engine Oil Capacity 1.9 Quarts
Front Rack (Maximum -
Capacity)
90 Lbs.
Rear Rack 180 Lbs.
Tongue Weight 30 Lbs.
Tow Hitch Standard
Tow Capacity 850 lbs.
T urn Radius 65²
Ground Clearance 7.25²
Height 46²
Length 81²
Seat Height 34²
Dry Weight 620 lbs
Wheel Base 49.75²
Width 46²
Drive System
Drive System Type PVT
Shift Type Side Lever
Front Drive (ratio) 3.7 / 1
Final Drive (ratio) 3.1 / 1
Front Tire 24 x 8 - 12
Rear Tire 24 x 11.5 - 10
Tire Pressure (front) 4
Tire Pressure (rear) 3
Suspension and Brakes
Front Susp. - Mac Strut 6.7²
Rear Susp. - Progresseive
Rate Swing Arm
6.5²
Shock Adjustment 2² Gas Charged Mono-
tube Cam
Front Brake Hydraulic Disc
Rear Brake Hydraulic Disc
Auxiliary Brake Hydraulic Disc
Park Brake Hydraulic Lock, All
Wheel
Engine & Cooling
Engine Model Number ES32PFE06
Engine Type 4 Stroke, Single Cyn-
linder
Lubrication Wet Sump
Bore x Stroke 78 x 68
Displacement 324 cc
Compression Ratio 9:2 Full Stroke
Engine Cooling Air with Fan Assisted
Oil Cooler
Alternator Output (watts) 200
Carburetion 1/BST31 (CV Type)
Main Jet 145
Pilot Jet 50
Needle Jet P-2 (829)
Pilot Air Jet 175
Pilot Screw 2 T urns
Jet Needle 5F14-3
Ignition CDI
Timing 30° @ 5000
Spark Plug Gap .036 inches
Spark Plug Type NGK BKR6E
Exhaust USFS Approval Pend-
ing
