Pure Evoke 1XT Marshall Bruksanvisning
Les nedenfor 📖 manual på norsk for Pure Evoke 1XT Marshall (8 sider) i kategorien radioer. Denne guiden var nyttig for 2 personer og ble vurdert med 4.3 stjerner i gjennomsnitt av 1.5 brukere
Side 1/8
Owner’s manual
2
Controls and Connectors
Autotune – press and release to scan UK only Band III. Press and hold for
around two seconds to scan the full range of digital frequencies in Band III.
Standby – press to switch between standby mode and power on
Timer – press and use Tune to set a countdown timer which will sound an
alarm after the period you set (range from 1 min to 23 hr 59 mins)
Info – press and repeat to change the text shown on the bottom of the
display between scrolling text, programme type, multiplex name, time and
date, channel and frequency, broadcast data rate/stereo mode and signal
quality (0-100 maximum).
Menu – press to access and exit setup menu options, turn the Tune knob to
scroll through and push to select an option.
Presets (1-6) – press and hold for around two seconds to store a station
under that number. Press and release to select and listen to a preset.
Preset 1 is permanently set to Planet Rock, where reception is available.
Tune – turn to scroll through and press to select stations and menu options.
Screen – 16 x 2 text display with active and standby brightness settings
USB – connect to a PC for software upgrades
Stereo Out – connect this analogue output to an external amplifier or
recorder
Headphone – connect to headphones (mutes speaker)
Aux Speaker – connect to an optional XT-1 speaker for full stereo output
9V DC – connect to mains adapter
Aerial – F-type connector for the supplied telescopic or other aerial
Stereo Out Aux SpeakerUSB
Designed in the UK Manufactured in China
9V DC
Produkspesifikasjoner
| Merke: | Pure |
| Kategori: | radioer |
| Modell: | Evoke 1XT Marshall |
