Side 1/4
100.615UK User Manual
Effect: Portable Bluetooth Party Speaker
Item ref: 100.615UK
User Manual
Take the party with you wherever you go, with a portable Bluetooth speaker with colourful LED light show.
Perfect for karaoke kings and queens, simply connect the microphone to showcase your talents and record
sing-alongs with the voice record function. Play your tunes via Bluetooth from your smart device, use the
inbuilt media ports or even FM radio. This speaker is light enough to be carried by shoulder strap and features
an internal rechargeable battery with up to 3 hours power from a single charge.
• Stylish and rugged design
• Connect to your smart device via Bluetooth
• Wired microphone included for karaoke and voice record functions
• LED colour light effect in grille
• Media player with inbuilt FM/USB/AUX and Microphone ports
• Internal rechargeable battery with up to 3 hours playback
• Ideal for karaoke, house parties, kids' rooms and more
Technical Specifications and Features
Speaker
6.5" Driver 10W RMS
Frequency range
70Hz-18KHz
Impedance
4.0 Ohms
Bluetooth version
5.0+EDR
Bluetooth range
Up to 10m (in clear line of sight)
FM Frequency range
87.5MHz-108MHz
Battery type
3.7V 2200mA internal rechargeable Lithium Ion
Battery life
Up to 3 hours (max volume)
Charge time
3 Hours from flat
Input connections
Bluetooth, USB, AUX (3.5mm), micro USB (DC 5V/1A - charge only)
Dimensions
300 x 250 x 180 mm (W x H x D)
Weight
1.65kg
Controls Diagram:
100.615UK User Manual
Unit Controls and Features:
1. Volume control: Rotate to increase or lower the master volume.
2. Power/mode button ( ): Long press to power the unit on or off. Short press to switch between
modes (Bluetooth/AUX/FM/Record).
3. Play/pause button ( ): Long press to turn the LED Light show on or off. Short press in BT/USB
mode to play or pause the current track, in FM mode to perform a channel scan and in record mode to
playback a recording.
4. Next track/station button ( ): Short press to move to the next track in BT/USB mode, or next
station in FM mode. Long press with the microphone inserted to increase the echo/reverb effect. Short
press in record mode to begin the recording session.
5. Previous track/station button ( ): Short press to move to the previous track in BT/USB mode, or
previous station in FM mode. Long press with the microphone inserted to decrease the echo/reverb effect.
Short press in record mode to end the recording session.
6. DC in 5V micro USB port: Use the charging cable supplied and connect to a compatible USB power
source for charging or constant power.
7. USB port: Multimedia playback via a USB flash drive or other compatible USB device.
8. AUX in jack: Use to connect to audio output devices with a compatible 3.5mm lead (not supplied).
9. Microphone jack: Connect the wired microphone supplied for voice playback or recording.
10. LED charging indicator: Glows red when the unit is connected to a compatible USB power source and in
charging mode. Goes out when fully charged.
11. Reset aperture: Press using a pin or sharp object to reset the unit when required.
Charging the battery:
• Fully charge the Effect’s internal battery before first use. Use the USB cable provided and only connect to a
suitable 5V USB power supply.
• During charging, the LED indicator will glow red and go out when the unit is fully charged.
Note: If the Effect is used while connected to a USB power source, the indicator will always glow, even
when the unit is fully charged.
Bluetooth Mode:
• Select Bluetooth mode by short pressing the Power/mode button repeatedly until you hear the relevant
voice prompt.
• The Effect will automatically enter Bluetooth pairing mode and become discoverable from your smart
device.
• Enter the Bluetooth device list on your smart device and search for “QTX-Effect” and select to pair.
• Your device may ask you for a pairing confirmation or code, enter “0000” if prompted. When successful, a
pairing tone can be heard.
• Once paired, the Effect will automatically reconnect to your device when both are in Bluetooth mode and
within 10m of each other.
• You can now also use the unit’s Play/pause, Previous track/station or Next track/station buttons
to control the music on your connected smart device.
USB mode:
• The Effect is fitted with a media player which can play compatible music files from the USB port on the
back of the unit.
• Simply insert your USB media and the unit will automatically enter USB mode and a voice prompt can be
heard. Alternatively, you can select the USB mode by short pressing the Power/mode button repeatedly
until you hear the relevant voice prompt.
• You can now play or scroll through the tracks using the Play/pause, Previous track/station or Next
track/station buttons on the front of the unit.
• The Effect also has a memory function which means it will continue from the last played track on the last
album played, on the last occasion it was inserted.
