Side 1/19

OWNER’S OPERATING MANUAL

PETROL CHAIN SAW

MODEL CS-4016/CS-4518/ES-4520

KEEP THIS MANUAL FOR FUTURE REFERENCE

Your new petrol chain saw has been engineered and manufactured to

Ryobi’s high standard of dependability, ease of operation and operator safety.

Properly cared for, it will give you years of rugged, trouble free performance. If

you use your petrol chain saw properly and only for what it is intended, you

will enjoy years of safe, reliable service.

SPECIFICATIONS

THANK YOU FOR BUYING A RYOBI

GASOLINE CHAIN SAW

CAUTION: Carefully read through this entire owner’s

manual, paying close attention to the general

safety rules and rules for safe operation,

before using.

Max cutting length

Model CS-4016

380mm

1.6kW 1.8kW 1.8kW

10000min

-1

25:1

580 ml

250 ml

air cooling single cylinder

455mm

6.8kg6.35kg 7kg

500mm

CS-4518 ES-4520

Engine type

Engine power

Rated output power

Maximum engine speed

Fuel mixing ratio

Fuel tank capacity

Oil tank capacity

Nett weight

2 stroke 40cc 2 stroke 45cc 2 stroke 45cc

GENERAL SAFETY RULES

The purpose of safety rules is to attract your

ttention to possible dangers. The safety symbols

and the explanations with them, require your

areful attention and understanding. The safety

arnings do not by themselves eliminate any

danger. The instruction or warnings they give are

not substitutes for proper accident prevention

measures.

SAFETY ALERT SYMBOL. Indicates

caution or warning. May be used in

conjunction with other symbols or

pictures.

Failure to obey a safety warning can result in

serious injury to yourself or to others. Always follow

the safety precautions to reduce the risk of fire,

electric shock and personal injury.

Do not attempt to operate this tool until you have

read thoroughly and completely understood the

safety rules, etc. contained in this manual. Failure

to comply can result in accidents involving fire,

electric shock or serious personal injury. Save this

Owners Operating Manual and review it frequently

for continual safe operation and for instructing

others who may use this tool.

GENERAL REQUIREMENTS

. The saw is specially designed for tree service,

i.e. for off-ground working in trees, and when

eing used as such should only be used by

rained operators.

2. One handed operation of the saw can be

dangerous.

3. Be alert for the phenomena “skating” and

“bouncing”, greater risk from kickback.

4. Be cautious not to lose balance of your body

due to “drop” at the end of a cut.

5. If working off the ground the operator must be

trained in safe climbing techniques and use all

recommended safety equipment such as

harness, loops, strops, ropes and karabiners

for themselves and for the saw.

6. When hoisting a chain saw using a rope tied to

a lifting hook for operation on a tree, ensure

that the lifting hook is not strained by excessive

force.

PHYSICAL CONDITION

1. Do not operate a chain saw when you are tired

or under the influence of alcohol or drugs.

2. You should be in good physical and mental

health in order to handle your chain saw safely.

Errors in judgment or execution can be serious

or fatal. If you have any physical condition

which strenuous work could worsen, check with

your physician before using a chain saw. Do

not operate when ill or tired, or under the

influence of any substance or medication which

could affect your vision, dexterity or judgement.

PERSONAL PROTECTIVE EQUIPMENT (PPE)

1. Always wear approved goggles to protect your

eyes. Wood chips, dust, snapping branches

and other debris can be tossed by the cutting

chain into the operator’s facial area. Goggles

may also offer limited protection in the event of

the cutting chain hitting the operator in the eye

area. If conditions warrant that a ventilated face

shield should be worn, goggles must be worn

underneath it.

2. We recommend wearing hearing protection at

all times. If not followed, hearing loss can

occur. You should reduce the risk of hearing

damage by wearing either “headset” type

protectors or ear plugs which are approved by

an authorised organisation.

3. All persons who make part of their living using

chain saws should be tested periodically for

hearing deterioration.

The operation of any tool

can result in foreign objects

being thrown into your

eyes, which can result in

severe eye damage.

Before beginning power

tool operation, always wear safety goggles or

safety glasses with side shields and a full face

shield when needed. We recommend Wide

Vision Safety Mask for use over eye glasses or

standard safety glasses with side shields.

Due to continued product

refinement policy, product features

and specifications can and will

change without notice. Check

current features and specifications

with your retailer.

GENERAL SAFETY RULES

CAUTION. Stuffing ears with cotton is

not recommended

4. Always wear a cap or hat when working with a

chain saw. A safety hard hat is highly

recommended when felling or working under

trees, or when objects can fall on you.

5. Wear heavy duty, non-slip gloves for improved

grip, and also for protection against cold and

vibration.

6. Safety tip shoes or boots with non-slip sole

should be worn.

7. Use eye protection and protective clothing,

including gloves and

foot protection suitable for

tree climbing.

8. Never wear loose clothing, unbuttoned jackets,

flared sleeves and cuffs, scarfs, tie-strings,

neckties, cords, chains, jewelry, etc. which

could snag the saw chain or underbrush.

9. Clothing should be sturdy, protective material. It

should be snug-fitting to resist snagging, but

roomy enough for freedom of movement.

10. Trouser legs should not be flared or cuffed, and

should be either tucked into the boot tops or

trimmed short.

11. Safety vests, leg chaps and logger’s pants of

heavy leather material are available.

12. It is the operator’s responsibility to wear such

additional protection if conditions warrant it.

13. Never operate a chain saw when you are

alone. Arrange to have someone remain within

calling distance in case you need help.

FUEL

WARNING. Petrol and fuel are extremely

flammable. If spilled or ignited by ignition

source, it can cause fire and serious

injury or property damage. E

xtra caution

is required, when handling petrol or fuel.

1. Use an appropriate typefuel container .

2. Do not smoke or bring flame or sparks near fuel

supplies.

3. The fuel tank may be under pressure. Always

loosen the fuel cap and wait for pressure to be

equalized before removing the cap.

4. When fuel tank cap or oil tank cap is difficult to

remove by hand, place the attached socket

wrench into the groove of cap and turn it

anticlockwise.

5. Fill the fuel tank outdoors over bare ground and

ins

tall the fuel cap securely. Do not pour fuel

indoors.

6. Wipe any spilled fuel off the unit.

7. Never refuel while the engine is still hot, or fuel

a running engine.

8. Do not store the unit with fuel in its tank,

because a fuel leak could start a fire.

9. Bring an extinguisher or shovel in case of fire.

Despite the precautions which can be taken,

operating a chain saw, or just working in the

forest, presents dangers.

10. After refueling, tighten fuel cap firmly and check

for leakage. I

n case of fuel leakage, repair

before starting operation since there is a

danger of fire.

NOTE. Do not press socket wrench

forcefully, since tank cap is plastic.

Pressing forcefully can damage tank

cap. If tank cap is damaged, do not start

engine.

RULES FOR SAFE OPERATION

STARTING ENGINE

1. Move the chain saw at least 3m from the

fuelling point before starting the engine.

2. Do not allow other persons to be near the chain

saw when you are starting or cutting with the

chain saw. Keep bystanders and animals out of

the work area. Do not let anyone hold wood for

you to cut.

3. Do not start cutting until you have a clear work

area, secure footing, and a planned retreat

path from the falling tree.

4. Before you start the engine, make sure that the

saw chain is not in contact with any object.

5. Keep the handles dry, clean, and free of oil or

fuel mixture.

Produkspesifikasjoner

Merke:	Ryobi
Kategori:	sag
Modell:	CS-4016
Vekt:	6350 g
Strømkilde:	Bensin
Tomgangshastighet:	10000 RPM
Bladlengde:	- mm
Produktfarge:	Sort
Strøm:	1500 W
Motor-volum:	40 cm³
Drivstoffstankkapasitet:	0.58 l
Klippelengde:	380 mm
Automatisk oljering:	Ja
Kjede, lengde:	460 mm
