Side 1/96

FRONT PAGE

R18PD3

R18PD32

Important! It is essential that you read the instructions in this manual before assembling, maintaining and

operating the product.

Attention! Il est essentiel que vous lisiez les instructions contenues dans ce manuel avant d’assembler,

d’entretenir et d’utiliser le produit.

Achtung! Es ist wichtig, dass Sie vor Zusammenbau, Wartung und Benutzung des Produktes die Anweisungen

in dieser Anleitung lesen.

¡Atención! Resulta fundamental que lea este manual de instrucciones antes de realizar el montaje, el

mantenimiento y de utilizar este producto

Attenzione! E’ importante leggere le istruzioni contenute nel presente manuale prima di montare il prodotto,

svolgere le operazioni di manutenzione sullo stesso e metterlo in funzione.

Let op! Het is van essentieel belang dat u de instructies in deze gebruiksaanwijzing leest voor u het product

monteert, onderhoudt en gebruikt.

Atenção! É fundamental que leia as instruções deste manual antes da montagem, manutenção e operação

do aparelho.

OBS! Det er vigtigt, at man læser instrukserne i denne brugsanvisning, inden man samler, vedligeholder

og betjener produktet.

Observera! Det är viktigt att du läser instruktionerna i manualen före montering, användning och underhåll av

produkten.

Huomio! On tärkeää, että luet tämän käsikirjan ohjeet ennen tuotteen kokoamista, huoltoa ja käyttöä.

Advarsel! Det er viktig at du leser instruksjonene i denne manualen før sammensetning, vedlikehold og bruk

av produktet

Внимание! Необходимо прочитать инструкции в данном руководстве перед сборкой, обслуживанием и

эксплуатацией этого изделия.

Uwaga! Koniecznie należy przeczytać instrukcje zawarte w tym podręczniku przed montażem, obsługą oraz

konserwacją produktu.

Důležité

upozornění!

Neinstalujte, neprovádějte údržbu ani nepoužívejte tento výrobek dříve, než si přečtete pokyny

uvedené v tomto návodu.

Figyelem! Fontos, hogy a termék összeszerelése, karbantartása és használata előtt elolvassa a kézikönyvben

található utasításokat.

Atenţie! Este esențial să citiți instrucțiunile din acest manual înainte de asamblare, efectuarea întreținerii și

operarea produsului.

Uzmanību! Ir svarīgi izlasīt šīs rokasgrāmatas instrukcijas pirms uzstādīšanas, apkopes un preces darbināšanas.

Dėmesio! Prieš surenkant, prižiūrint ir naudojant gaminį, būtina perskaityti šiame vadove pateiktus nurodymus.

Tähtis! Enne masina kokkupanekut, hooldamist ja kasutama hakkamist tuleb käesolevas juhendis esitatud

juhised kindlasti läbi lugeda.

Upozorenje!

Vrlo je važno da ste prije sklapanja, održavanja i rada s ovim proizvodom pročitali upute u ovom priručniku.

Pomembno!

Pomembno je da pred montažo vzdrževanjem in uporabo tega izdelka preberete navodila v tem priročniku.

Upzornenie! Je dôležité, aby ste si pred montážou, údržbou a obsluhou produktu prečítali pokyny v tomto návode.

Важно! Изключително важно е да прочетете инструкциите в настоящото ръководство, преди да

преминете към сглобяване, поддръжка или работа с продукта.

Важливо! Дуже важливо, щоб ви прочитали інструкції в цьому керівництві перед складанням,

обслуговуванням та експлуатацією цієї машини.

Dikkat! Ürünün montajını, bakımını yapmadan ve ürünü çalıştırmadan önce bu kılavuzda yer alan talimatları

okumanız önemlidir.

Προσοχή! Είναι πολύ σημαντικό να διαβάσετε τις οδηγίες στο παρόν εγχειρίδιο πριν συναρμολογήσετε,

συντηρήσετε ή λειτουργήσετε το προϊόν.

Subject to technical modication | Sous réserve de modications techniques | Technische Änderungen vorbehalten | Bajo

reserva de modicaciones técnicas | Con riserva di eventuali modiche tecniche | Technische wijzigingen voorbehouden

| Com reserva de modicações técnicas | Med forbehold for tekniske ændringer | Med förbehåll för tekniska ändringar |

Tekniset muutokset varataan | Med forbehold om tekniske endringer | могут быть внесены технические изменения |

Z zastrzeżeniem modykacji technicznych | Změny technických údajů vyhrazeny | A műszaki módosítás jogát fenntartjuk

| Sub rezerva modicaţiilor tehnice | Paturam tiesības mainīt tehniskos raksturlielumus | Pasiliekant teisę daryti techninius

pakeitimus | Tehnilised muudatused võimalikud | Podloæno tehniëkim promjenama | Tehnične spremembe dopuščene

| Právo na technické zmeny je vyhradené | Подлежи на технически модификации | Є об’єктом для технічних змін |

Teknik değişiklik hakkı saklıdır | Υπό την επιφύλαξη τεχνικών τροποποιήσεων

ENGLISH

Original Instructions

Safety, performance, and dependability have been given top

priority in the design of your percussion drill.

INTENDED USE

The percussion drill is intended to be used only by adults

who have read and understood the instructions and

warnings in this manual and can be considered responsible

for their actions.

The percussion drill can be used for drilling into various

material including wood, metal and plastics using a drill bit

which has a shank diameter of less that 13 mm. It can also

be used in hammer mode for drilling masonry and similar

materials.

Do not use the percussion drill for any other purpose not

described above.

WARNING! Read all safety warnings, instructions,

illustrations and specifications provided with this

power tool. Failure to follow all instructions listed below

may result in electric shock, ﬁ re and/or serious injury.

Save all warnings and instructions for future reference.

PERCUSSION DRILL SAFETY WARNINGS

SAFETY INSTRUCTIONS FOR ALL OPERATIONS

■ Wear ear protectors when impact drilling. Exposure

to noise can cause hearing loss.

■ Hold the power tool by insulated gripping surfaces,

when performing an operation where the cutting

accessory or fasteners may contact hidden wiring.

Cutting accessory or fasteners contacting a “live” wire

may make exposed metal parts of the power tool “live”

and could give the operator an electric shock.

SAFETY INSTRUCTIONS WHEN USING LONG DRILL

BITS

■ Never operate at higher speed than the maximum

speed rating of the drill bit. At higher speeds, the bit is

likely to bend if allowed to rotate freely without contacting

the workpiece, resulting in personal injury.

■ Always start drilling at low speed and with the bit

tip in contact with the workpiece. At higher speeds,

the bit is likely to bend if allowed to rotate freely without

contacting the workpiece, resulting in personal injury.

■ Apply pressure only in direct line with the bit and do

not apply excessive pressure. Bits can bend causing

breakage or loss of control, resulting in personal injury.

ADDITIONAL SAFETY WARNINGS

■ Clamp workpiece with a clamping device. Unclamped

workpieces can cause severe injury and damage.

■ Ambient temperature range for tool during operation is

between 0°C and 40°C.

■ Ambient temperature range for tool storage is between

0°C and 40°C.

■ The recommended ambient temperature range for the

charging system during charging is between 10°C and

38°C.

ADDITIONAL BATTERY SAFETY WARNINGS

■ To reduce the risk of fire, personal injury, and product

damage due to a short circuit, never immerse your

tool, battery pack, or charger in fluid or allow fluid to

flow inside them. Corrosive or conductive fluids, such

as seawater, certain industrial chemicals, and bleach

or bleach-containing products, etc., can cause a short

circuit.

■ Ambient temperature range for battery during use is

between 0°C and 40°C.

■ Ambient temperature range for battery storage is

between 0°C and 20°C.

TRANSPORTING LITHIUM BATTERIES

Transport the battery in accordance with local and national

provisions and regulations.

Follow all special requirements on packaging and labelling

when transporting batteries by a third party. Ensure that

no batteries can come in contact with other batteries

or conductive materials while in transport by protecting

exposed connectors with insulating, non-conductive caps or

tape. Do not transport batteries that are cracked or leaking.

Check with the forwarding company for further advice.

RESIDUAL RISKS

Even when the product is used as prescribed, it is still

impossible to completely eliminate certain residual risk

factors. The following hazards may arise and the operator

should pay special attention to avoid the following:

■ damage to hearing caused by noise

– Wear suitable hearing protection and limit exposure.

■ injury to the eyes

– Wear protective eye shields or goggles when using

the product.

■ injury caused by vibration

– Limit exposure. Follow the instructions in Risk

Reduction.

■ electric shock caused by contact with hidden wires

– Hold the product only by insulated surfaces.

■ injury caused by dust

– Dust created by operating the product can cause

respiratory injury. Wear appropriate dust control

mask with filters suitable for protecting against

particles from the material being worked on.

RISK REDUCTION

It has been reported that vibrations from handheld tools

may contribute to a condition called Raynaud’s Syndrome

in certain individuals. Symptoms may include tingling,

numbness and blanching of the ﬁ ngers, usually apparent

upon exposure to cold. Hereditary factors, exposure to

cold and dampness, diet, smoking and work practices

are all thought to contribute to the development of these

symptoms. There are measures that can be taken by the

operator to possibly reduce the eﬀ ects of vibration:

■ Keep your body warm in cold weather. When operating

the unit wear gloves to keep the hands and wrists

warm. It is reported that cold weather is a major factor

contributing to Raynaud’s Syndrome.

■ After each period of operation, exercise to increase

blood circulation.

■ Take frequent work breaks. Limit the amount of exposure

per day.

Produkspesifikasjoner

Merke:	Ryobi
Kategori:	drill
Modell:	One+ R18PD3
Produkttype:	Elektrisk skrutrekker
Vekt:	1300 g
Strømkilde:	Batteri
Batterikapasitet:	2.5 Ah
Tomgangshastighet (maks.):	23400 RPM
Lydeffektnivå:	96.6 dB
Lydtrykknivå:	85.6 dB
Justerbar hastighet:	Ja
Mykt håndtak:	Ja
Batterivekt:	400 g
Antall batterier inkludert:	2 stykker
Produktfarge:	Black, Green
Batterispenning:	18 V
Strømbeskyttelsesfunksjoner:	Overbelastning
Batteri inkludert:	Ja
Borediameter i stål (maks.):	13 mm
Boring:	Ja
Tilpassbart dreiemoment:	Ja
Tomgangshastighet (min.):	6500 RPM
Borediameter i treverk (maks.):	38 mm
Omveltning/motsetning/bakside:	Ja
Maksimalt dreiemoment (hardt bruk):	50 Nm
Usikkerhet i lydnivå:	3 dB
Batterilader:	Ja
Håndgrepsform:	Pistolhåndtak
Boltmodus:	Ja
