English

Safety, performance, and dependability have been given

top priority in the design of your rotary hammer.

INTENDED USE

This rotary hammer drill is intended to be used only by

adults who have read and understood the instructions and

warnings in this manual and can be considered responsible

for their actions. It is to be used by a single operator by

grasping both trigger and side handles.

The rotary hammer drill is designed to operate without

hammer function into wood and metal. For chiselling and

masonry drilling, the hammer mode may be used.

The rotary hammer drill is designed to operate with drill

bits up to the maximum diameter defined in the product

specification table.

Do not use the product in any way other than those stated

for intended use.

WARNING

Read all safety warnings and all instructions. Failure

to follow the warnings and instructions may result in

electric shock, fire and/or serious injury.

Save all warnings and instructions for future reference.

HAMMER SAFETY WARNINGS

Ŷ Wear ear protectors. Exposure to noise can cause

hearing loss.

Ŷ Use auxiliary handle(s), if supplied with the tool.

Loss of control can cause personal injury.

Ŷ Hold power tool by insulated gripping surfaces

when performing an operation where the cutting

accessory may contact hidden wiring. Cutting

accessory contacting a “live” wire may make exposed

metal parts of the power tool “live” and could give the

operator an electric shock.

Ŷ Hold power tool by insulated gripping surfaces,

when performing an operation where the fastener

may contact hidden wiring. Fasteners contacting a

“live” wire may make exposed metal parts of the power

tool “live” and could give the operator an electric shock.

Ŷ Wear safety goggles to protect your eyes from flying

particles and splinters.

ADDITIONAL SAFETY WARNINGS

Ŷ Always ensure you hold the product securely. Twisting

of the product if it becomes jammed may result in injury

or loss of control of the product.

Ŷ Do not operate the forward /reverse or mode selector

switches when the product is running. Wait for it to

completely stop before changing direction or mode.

Ŷ Drill bits or chisels will become hot during use. They

may also be sharp. Wear suitable gloves and take care

when changing or adjusting these acceseries to avoid

personal injury.

Ŷ When working in walls, floors or ceilings, take care to

avoid cables, gas and water pipes.

Ŷ Clamp your workpiece with a clamping device to prevent

unexpected movement. Unclamped workpieces can

cause severe injury and damage.

Ŷ The dust produced when using the product may be

harmful to your health, inflammable or explosive. Do not

inhale the dust. Use a dust extraction system and wear

a suitable dust protection mask. Remove deposited

dust thoroughly, e.g., with a brush and vacuum cleaner.

If the drill bit or chisel becomes jammed in the workpiece

during use:

Ŷ Immediately release the trigger.

Ŷ Remove the battery pack from the product.

Ŷ Release the bit or chisel from the SDS adaptor. Do not

try to extract the jammed bit with the product attached

to it.

Ŷ Extract the jammed bit or chisel by other means.

Example: large pliers or wrench. Note: If you are

uncertain about how to extract a jammed bit or chisel,

seek professional advice from a reputable builder or

similar tradesman.

ADDITIONAL BATTERY SAFETY WARNINGS

WARNING

To reduce the risk of fire, personal injury, and product

damage due to a short circuit, never immerse your

tool, battery pack or charger in fluid or allow a fluid to

flow inside them. Corrosive or conductive fluids, such

as seawater, certain industrial chemicals, and bleach

or bleach-containing products, etc., can cause a short

circuit.

TRANSPORTING LITHIUM BATTERIES

Transport the battery in accordance with local and national

provisions and regulations.

Follow all special requirements on packaging and labelling

when transporting batteries by a third party. Ensure that

no batteries can come in contact with other batteries

or conductive materials while in transport by protecting

exposed connectors with insulating, non-conductive caps

or tape. Do not transport batteries that are cracked or

leaking. Check with the forwarding company for further

advice.

KNOW YOUR PRODUCT

See page 81.

1. LED light

2. Mode selector

3. Forward / reverse button

Produkspesifikasjoner

Merke:	Ryobi
Kategori:	drill
Modell:	One+ R18SDS
Vekt:	2080 g
Støynivå:	96.2 dB
Strømkilde:	Batteri
Innebygd lys:	Ja
Vibrasjonsutslipp:	11.7 m/s²
Mykt håndtak:	Ja
SDS-system:	Ja
Produktfarge:	Black, Green
Batterispenning:	18 V
Borediameter i stål (maks.):	13 mm
Borediameter i treverk (maks.):	16 mm
Borediameter i betong (maks.):	16 mm
Slagenergi:	1.3 J
Slaghastighet:	5000 bpm
