SPEKTRUM MICRO PRO RECEIVER • BINDING PROCEDURE

IMPORTANT!

To achieve the lightest possible weight and smallest size, Spektrum’s

Micro Receiver utilizes a removable bind plug during the binding process.

Binding is necessary to teach the receiver the code of the speciﬁc

transmitter so that the receiver will operate from that speciﬁc transmitter

only. During binding the servo’s fail safe positions are also programmed.

To Bind the Micro Receiver:

With the transmitter and receiver power off, insert the bind plug into the

battery/bind port on the receiver labeled B.

Power up the receiver by turning on the electronic speed control (electric

cars) or turn on the battery switch (gas car). Note that the LED will ﬂash

continuously indicating that the receiver is ready to bind.

With the throttle and the steering channels set to the desired failsafe

positions, (normally neutral steering and slight brakes) press and hold the

bind button on the back of the module while turning on the transmitter.

After several seconds the receiver’s LCD will change to a continuous glow

indicating that a successful bind has been achieved.

Remove the bind plug before using the system.

Spektrum

™

Micro Receiver Binding Instructions

Flashing LED

Solid LED

Off

Produkspesifikasjoner

Merke:	Spektrum
Kategori:	radiostyrt leke
Modell:	SR3500
Produkttype:	Mottaker
Innebygd skjerm:	Nei
Vekt:	6.5 g
Bredde:	26.9 mm
Dybde:	19.8 mm
Høyde:	12.2 mm
Antall per pakke:	1 stykker
Merkekompatibilitet:	Spektrum
Antall kanaler:	3 kanaler
Spenning:	3.9 - 9.6 V
Produktfarge:	Sort
Modell/Type:	Radio-Controlled (RC) Model Parts
Kroppsmateriale:	Plast
Korrekt bruk:	Car, Truck
Frekvensbånd og driftskanaler:	2.4 GHz
RF senderfrekvens:	2400 MHz
