CURRENTLY UNAVAILABLE - 15" ICE MAKER WITH PUMP - PANEL READY

UC-15IP

FEATURES

Accepts custom panels for an integrated look within cabinetry or

stainless-steel accessory panels and handles to match other Sub-Zero,

Wolf, and Cove products*

Pump allows for more flexible install. Unit does not need to be

immediately next to drain, a hose can be run and the pump assists the

water removal in those situations

Produces up to 50 pounds of octagonal-shaped ice per day; stores 25

pounds at a time

Locks in cold air to ensure freshness with magnetic door seals

Set the two, four, and eight-hour delay to temporarily stop ice production,

or pause ice production at the same time every day with auto-delay

Holds built-in ice scoop neatly in the door so it is there when you need it

ACCESSORIES

15" Stainless Door Panel with Pro Handle

15" Stainless Door Panel with Tubular Handle

15" to 18" Filler

18" Stainless Door Panel with Pro Handle

18" Stainless Door Panel with Tubular Handle

Cleaner For Undercounter Ice Maker

Sanitizer For Undercounter Ice Maker

Stainless Steel Kickplate

Stainless Steel Pro Handles

Stainless Steel Tubular Handles

Accessories are available through an authorized dealer.

For local dealer information, visit subzero-wolf.com/locator.

HANDLE ACCESSORIES

PRODUCT DETAILS

FREEZER

• LED lighting

• Built-in ice scoop

Specifications are subject to change without notice. This information was generated on September 11, 2023. Verify specifications prior to finalizing your cabinetry/enclosures.

CURRENTLY UNAVAILABLE - 15" ICE MAKER WITH PUMP - PANEL READY

PRODUCT SPECIFICATIONS

Model UC-15IP

Dimensions 14 3/4"W x 33 5/8"H x 23"D

Weight 115 lbs

Electrical Supply 115 VAC, 60 Hz

Electrical Service 15 amp dedicated circuit

Plumbing Supply 1/4" OD copper, braided stainless steel or

PEX tubing

Plumbing Pressure 20–80 psi

ELECTRICAL PLUMBING

ICE MAKER DRAIN Ice maker models can be ordered with or without a drain pump.

Models without a pump will drain water by gravity. A drain must be provided for all

models.

NOTE: Dimensions in parenthesis are in millimeters unless otherwise specified

INTERIOR VIEW

This illustration is intended for interior reference only and may not represent the exterior

of the model being specified.

DIMENSIONS

STANDARD INSTALLATION

(387)

OPENING

WIDTH

(876)

OPENING

HEIGHT

TOP VIEW

SIDE VIEW

FRONT VIEW

NOTE:

(89)

finished returns will be visible and should be finished to match cabinetry

(

19)

TYPICAL

FRAMED

CABINETRY

(387)

FILLER

(89)

FINISHED

RETURN

FRAMELESS

CABINETRY

(387)

(

19)

TYPICAL

(89)

FINISHED

RETURN

24"

(610)

OPENING

DEPTH

Specifications are subject to change without notice. This information was generated on September 11, 2023. Verify specifications prior to finalizing your cabinetry/enclosures.
