Side 1/35
Contents
1
1.
Safety and operating instructions ___________________________2
2. Installation and hook-up___________________________________5
3. Description of the controls _________________________________9
4. Operating instructions ___________________________________17
5. Cleaning and maintenance _______________________________ 29
6. Troubleshooting________________________________________33
Thank you for choosing one of our products.
You are advised to read this manual carefully; it contains all the
information you need about the right conditions for the proper, safe use
of your dishwasher.
The individual sections are laid out to provide you with a step-by-step
guide to all your appliance's functions; the texts are easy to understand
and are complete with detailed illustrations.
Recommendations are given for the correct use of the baskets, spray
arms, containers, filters, washing programs, and for operating the
controls.
Following the cleaning instructions provided here will keep your
dishwasher's performance at peak levels in the long term.
This user-friendly manual will provide answers to all your questions
about use of the dishwasher.
INSTALLATION INSTRUCTIONS: these are intended for the qualified
technician who must carry out the installation, hook-up and testing of
the appliance.
USER INSTRUCTIONS: these consist of recommendations for using the
appliance, a description of its controls and of the correct cleaning and
maintenance procedures.
Safety instructions
2
1. Safety and operating instructions
THIS MANUAL FORMS AN INTEGRAL PART OF THE APPLIANCE: IT MUST
ALWAYS BE KEPT INTACT TOGETHER WITH THE DISHWASHER. BEFORE
USING THE APPLIANCE, CAREFULLY READ ALL THE INSTRUCTIONS
CONTAINED IN THIS MANUAL.
INSTALLATION MUST BE PERFORMED BY A QUALIFIED TECHNICIAN, IN
COMPLIANCE WITH THE REGULATIONS IN FORCE. THIS APPLIANCE IS
INTENDED FOR DOMESTIC USE, AND COMPLIES WITH THE EEC
DIRECTIVES 73/23, 89/336 (INCLUDING 92/31 AND 93/68) CURRENTLY IN
FORCE, INCLUDING THE PREVENTION AND ELIMINATION OF RADIO
FREQUENCY INTERFERENCE.
THE APPLIANCE IS DESIGNED FOR THE FOLLOWING PURPOSE: WASHING
AND DRYING OF DISHES; ANY OTHER USE SHALL BE CONSIDERED
IMPROPER. THE MANUFACTURER DECLINES ALL RESPONSIBILITY FOR
USES OTHER THAN THOSE DESCRIBED ABOVE.
THE NAME PLATE FEATURING THE TECHNICAL DATA, SERIAL NUMBER
AND MARKINGS IS VISIBLY POSITIONED ON THE INNER EDGE OF THE
DOOR. THE NAME PLATE ON THE INNER EDGE OF THE DOOR MUST
NEVER BE REMOVED.
DO NOT LEAVE THE DISCARDED PACKAGING MATERIALS UNSUPERVISED
WITHIN THE HOME. SEPARATE THE VARIOUS MATERIALS WHICH MAKE
UP THE PACKAGING AND TAKE THEM TO THE NEAREST SORTED WASTE
COLLECTION CENTRE.
THE APPLIANCE MUST BE PROVIDED WITH AN EARTH CONNECTION IN
ACCORDANCE WITH THE ELECTRICAL SAFETY REGULATIONS IN FORCE.
THE MANUFACTURER DECLINES ALL RESPONSIBILITY FOR DAMAGE TO
PERSONS OR PROPERTY RESULTING FROM THE FAILURE TO EARTH THE
APPLIANCE OR FROM A DEFECTIVE EARTH CONNECTION.
IF THE APPLIANCE IS INSTALLED ON A CARPETED OR COVERED FLOOR,
ENSURE THAT THE OPENINGS ON ITS UNDERSIDE ARE NOT
OBSTRUCTED.
ALWAYS SWITCH OFF THE DISHWASHER AFTER EACH USE TO AVOID
WASTING ELECTRICITY.
Safety instructions
3
OBSOLETE APPLIANCES MUST BE RENDERED UNUSABLE. CUT OFF THE
MAINS POWER CORD AFTER UNPLUGGING IT FROM THE WALL OUTLET,
AND MAKE SAFE ANY COMPONENTS WHICH MIGHT BE DANGEROUS FOR
CHILDREN (LOCKS, DOORS, ETC.).
THIS APPLIANCE IS MARKED ACCORDING TO THE EUROPEAN DIRECTIVE
2002/96/EC ON WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT
(WEEE).
BY ENSURING THIS PRODUCT IS DISPOSED OF CORRECTLY, YOU WILL
HELP PREVENT POTENTIAL NEGATIVE CONSEQUENCES FOR THE
ENVIRONMENT AND HUMAN HEALTH, WHICH COULD OTHERWISE BE
CAUSED BY INAPPROPRIATE WASTE HANDLING OF THIS PRODUCT.
THE SYMBOL ON THE PRODUCT, OR ON THE DOCUMENTS
ACCOMPANYING THE PRODUCT, INDICATES THAT THIS APPLIANCE MAY
NOT BE TREATED AS HOUSEHOLD WASTE. INSTEAD IT SHALL BE
HANDED OVER TO THE APPLICABLE COLLECTION POINT FOR THE
RECYCLING OF ELECTRICAL AND ELECTRONIC EQUIPMENT.
DISPOSAL MUST BE CARRIED OUT IN ACCORDANCE WITH LOCAL
ENVIRONMENTAL REGULATIONS FOR WASTE DISPOSAL. FOR MORE
DETAILED INFORMATION ABOUT TREATMENT, RECOVERY AND
RECYCLING OF THIS PRODUCT, PLEASE CONTACT YOUR LOCAL CITY
OFFICE, YOUR HOUSEHOLD WASTE DISPOSAL SERVICE OR THE SHOP
WHERE YOU PURCHASED THE PRODUCT.
IN THE EVENT OF A FAULT, DISCONNECT THE DISHWASHER FROM THE
ELECTRICAL POWER SUPPLY AND SHUT OFF THE WATER TAP.
DO NOT USE APPLIANCES WHICH HAVE BEEN DAMAGED DURING
TRANSIT! IF IN DOUBT, CONSULT YOUR DEALER.
THE APPLIANCE MUST BE INSTALLED AND CONNECTED IN ACCORDANCE
WITH THE INSTRUCTIONS PROVIDED BY THE MANUFACTURER OR BY A
QUALIFIED TECHNICIAN.
THIS DISHWASHER MUST BE USED BY ADULTS.
USE BY PERSONS WITH REDUCED MENTAL AND/OR PHYSICAL
CAPABILITIES IS ONLY PERMITTED UNDER THE SUPERVISION OF A
PERSON RESPONSIBLE FOR THEIR SAFETY.
KEEP CHILDREN AWAY FROM DETERGENTS AND PACKAGING MATERIALS
(PLASTIC BAGS, POLYSTYRENE, ETC.), AND NEVER ALLOW THEM TO
APPROACH OR PLAY WITH THE DISHWASHER, SINCE IT MIGHT CONTAIN
DETERGENT RESIDUES CAPABLE OF CAUSING PERMANENT DAMAGE TO
THE EYES, MOUTH AND THROAT, AND EVEN LEADING TO SUFFOCATION.
DO NOT INTRODUCE SOLVENTS SUCH AS ALCOHOL OR TURPENTINE
WHICH MAY CAUSE AN EXPLOSION.
DO NOT LOAD DISHES THAT ARE SOILED WITH ASH, WAX OR PAINTS.
Safety instructions
4
LEANING OR SITTING ON THE DISHWASHER DOOR WHEN OPEN MAY
CAUSE THE APPLIANCE TO OVERTURN, PUTING PEOPLE AT RISK.
NEVER LEAVE THE DISHWASHER DOOR OPEN; PEOPLE MIGHT TRIP
OVER IT.
DO NOT DRINK THE WATER RESIDUES WHICH MAY BE PRESENT INSIDE
THE DISHES OR DISHWASHER AT THE END OF THE WASHING PROGRAM
AND BEFORE THE DRYING CYCLE.
KNIVES OR OTHER SHARP-ENDED COOKING UTENSILS MUST BE PLACED
IN THE CUTLERY BASKET BLADE-DOWN, OR LAID HORIZONTAL IN THE
TOP BASKET. TAKE CARE NOT TO CUT YOURSELF AND ENSURE THAT
THEY DO NOT PROJECT FROM THE BASKET.
AQUASTOP MODELS
THE AQUASTOP DEVICE PREVENTS FLOODING IN THE EVENT OF A
WATER LEAK. WHEN THE AQUASTOP DEVICE IS TRIPPED, CALL IN A
QUALIFIED TECHNICIAN TO IDENTIFY AND REPAIR THE FAULT.
IN MODELS EQUIPPED WITH THE AQUSTOP DEVICE, THERE IS A
SOLENOID VALVE INSIDE THE WATER INTAKE HOSE. DO NOT CUT THE
HOSE AND DO NOT ALLOW THE SOLENOID VALVE TO DROP INTO
WATER. IN THE EVENT OF DAMAGE TO THE WATER INTAKE HOSE,
DISCONNECT THE APPLIANCE FROM THE ELECTRICAL POWER SUPPLY
AND FROM THE WATER SUPPLY.
IMMEDIATELY AFTER INSTALLING THE DISHWASHER, PERFORM A QUICK
TEST OF THE APPLIANCE FOLLOWING THE INSTRUCTIONS BELOW. IF
THE DISHWASHER FAILS TO OPERATE CORRECTLY, DISCONNECT IT
FROM THE ELECTRICAL POWER SUPPLY AND CALL THE NEAREST
TECHNICAL SERVICE CENTRE. DO NOT ATTEMPT TO REPAIR THE
APPLIANCE.
THE DISHWASHER MEETS ALL THE REQUIREMENTS SET OUT BY THE
REGULATIONS IN FORCE CONCERNING SAFETY AND ELECTRICAL
EQUIPMENT. ANY TECHNICAL CHECKS SHOULD BE CONDUCTED
EXCLUSIVELY BY A TRAINED AND AUTHORISED TECHNICIAN: REPAIRS
CARRIED OUT BY UNAUTHORISED PERSONS WILL INVALIDATE THE
WARRANTY, AS WELL AS POSING A POTENTIAL HAZARD TO THE USER.
The manufacturer declines all responsibility for damage to persons or property
resulting from failure to observe the above precautions, from tampering with
even a single component of the appliance, or from the use of non original
spare parts.
Installation instructions
5
2. Installation and hook-up
Remove the polystyrene basket retainers.
Position the appliance in the desired place of installation. The back or
sides of the dishwasher may be placed up against walls or other
furniture units. If the dishwasher is installed near a heat source, fit the
special insulating panel to prevent overheating and malfunction of the
appliance. To ensure stability, install integrated or built-under
dishwashers only under continuous worktops, and screw them to the
adjacent units. To facilitate the installation procedure, the intake and
drain hoses can be positioned in any direction; make sure that the hoses
are not kinked, crushed or pulled too tightly. Make sure to tighten the
locking ring-nut once the pipes have been placed in the direction
required. A hole at least 8 cm in diameter is required to allow the power
supply cable and pipes to pass.
Level the appliance on the floor using its adjustable feet. This operation
is essential for ensuring correct operation of the dishwasher.
Building-in a dishwasher underneath a ceramic hob is absolutely
forbidden.
A dishwasher can be built-in underneath a conventional hob provided
there is no break in the kitchen worktop, and the dishwasher and hob are
installed and secured correctly, so that no hazards are generated.
When installing the dishwasher in a compartment next to one or more
other appliances, it is essential to comply with all the recommendations
provided by the appliance’s manufacturer (minimum distances, installation
procedures, etc.).
Some models are equipped with only one adjustable foot at the rear,
which can be adjusted by turning the screw on the lower front part of the
appliance.
2.1 Water supply connection
Preventing the risk of clogging or damage: if the water pipe is new or
has not been used for a long time, before connecting to the water supply
check that the water is clear and free of impurities, to prevent damage to
the appliance.
The dishwasher must always be connected to the water system
with new hoses; old or used hoses must never be reused.
Installation instructions
7
2.2 Electrical connection and precautions
CHECK THAT THE VOLTAGE AND THE FREQUENCY OF THE MAINS MATCH
THE RATINGS ON THE NAME PLATE OF THE APPLIANCE POSITIONED ON
THE INNER EDGE OF THE DOOR.
THE PLUG ON THE SUPPLY CORD AND THE CORRESPONDING SOCKET
OUTLET MUST BE OF THE SAME TYPE AND MEET THE REGULATIONS IN
FORCE.
THE PLUG MUST BE ACCESSIBLE AFTER INSTALLATION.
NEVER DISCONNECT THE PLUG BY PULLING ON THE POWER SUPPLY
LEAD.
IN THE EVENT OF DAMAGE TO THE SUPPLY CORD, HAVE IT REPLACED
BY THE MANUFACTURER OR AN AUTHORIZED TECHNICAL SERVICE
CENTRE.
DO NOT USE ADAPTORS OR SHUNT CONNECTIONS IN ORDER TO AVOID
THE POSSIBILITY OF OVERHEATING OR BURNING.
IF THE APPLIANCE IS PROVIDED WITH A PLUGLESS SUPPLY CORD:
IT IS NECESSARY TO INSTALL IN THE FIXED WIRING AN ALL-POLE
DISCONNECTION DEVICE HAVING A GAP BETWEEN CONTACTS OF AT
LEAST 3.5MM. AFTER INSTALLATION THE DISCONNECTION DEVICE HAS
TO BE EASY TO REACH.
THE CONNECTION TO THE MAINS MUST BE CARRIED OUT BY A
QUALIFIED TECHNICIAN IN ACCORDANCE TO THE SCHEME SHOWN
BELOW AND THE REGULATIONS IN FORCE.
L = brown
N = blue
= yellow-green
In the event of damage to the supply cord, have it replaced by the
manufacturer or an Authorized Technical Service Centre in order to
avoid any risk.
Installation instructions
8
FOR GREAT BRITAIN ONLY:
THIS APPLIANCE MUST BE EARTHED.
Fuse replacement
If the mains lead of this appliance is fitted
with a BS 1363A 13amp fused plug, to
change a fuse in this type of plug use an
A.S.T.A. approved fuse to BS 1362 type
and proceed as follows:
1. Remove the fuse cover A and fuse B.
2. Fit replacement 13A fuse into fuse
cover.
3. Refit both into plug.
The fuse cover must be refitted when changing a fuse and if the fuse
cover is lost the plug must not be used until a correct replacement is
fitted.
Correct replacement are identified by the colour insert or the colour
embossed in words on the base of the plug.
Replacement fuse covers are available from your local electrical store.
User instructions
9
3. Description of the controls
3.1 Upper panel
All the dishwasher controls are grouped on the upper panel. Switch-on,
programming, switch-off etc. procedures are only possible when the door
is open.
1
ON/OFF BUTTON
Pressing this button energises the appliance.
2
SELECTED PROGRAM INDICATOR LIGHTS
Illumination of this light denotes the program selected and the
occurrence of a fault (troubleshooting).
3
PROGRAM SELECTION BUTTON
By pressing this button in sequence it is possible to select the
desired program.
4
WATER HARDNESS ADJUSTMENT ON INDICATOR LIGHT
The light flashes to indicate that the appliance is in “water hardness
adjustment” mode.
SALT WARNIN LIGHT (on some models only)
If the symbol is present, illumination of this light denotes a
regenerating salt warning level.
5
RINSE AID WARNING LIGHT (on some models only)
Illumination of this light signals that rinse aid dispenser is empty.
6
EXTRA PROGRAM + EXTRA OPTION BUTTON
(see “EXTRA OPTIONS” section)
The button controls selection of the extra programs. (see table).
7
EXTRA PROGRAM LIGHT
Illuminates to indicate that one of the five extra programs (see
table) is going to be executed.
User instructions
10
HYGIENE OPTION + EXTRA OPTION BUTTON
(see “EXTRA OPTIONS” section)
Press the button to enable/disable the option.
HYGIENE OPTION LIGHT
Illuminates to indicate that the function is activated.
10
HALF LOAD BUTTON
Press this button to activate the half load wash option.
11
HALF LOAD LIGHT
Illuminates to indicate that the function is activated.
12
"3/1" OPTION (EXTRA OPTION) LIGHT
Illuminates to indicate that the function is activated.
13
PROGRAM DELAY BUTTON
Press this button to delay the start of the program.
14 INFORMATION DISPLAY (1 or 3 digits depending on model)
N.B.: symbols and styling are guideline and may vary depending on
the model or version of the dishwasher purchased.
Information displayed
no Scheduled program
duration
yes
no Remaining program
time
yes
1 - 9 hours Delayed start 1 - 24 hours
E
Error message
Err
SETTING THE WASHING PROGRAM AND SWITCHING ON
To select the most suitable program for the dishes to be washed refer to
the table below, which indicates the most appropriate program according
to dish type and degree of soiling.
After using the table to identify the most appropriate washing program:
• press the ON/OFF button (1) and wait for the PROGRAM
INDICATOR LIGHT (2) to illuminate;
• keep pressing the PROGRAM SELECTION button (3) until the
indicator light corresponding to the desired program illuminates;
• close the door; after about 2" the program will start. While it is in
progress, the relative LIGHT will flash (indicating that the program is
being executed).
User instructions
11
DURATION
CONSUMPTION
PROGRAMME,
NUMBER & SYMBOL
LOAD CROCKERY
AND CUTLERY
PROGRAM
PROGRESS
MINUTES
(2)
WATER
LITRES
(1)
POWER
KWh (2)
1
RINSE
Pans and dishes for
rinsing and drying.
Cold rinse
Rinse at 70°C
Dry
45' ***
9 0,90
2
GLASS
Delicate dishes with
normal dirt.
Wash at 45°C
Cold rinse
Rinse at 70°C
Dry
70' ***
13 1,20
3
AUTO
60-70
IEC/DIN
Pans and dishes with
normal dirt, even with
dried-on residues.
When the "AUTO" program is selected, the dishwasher
recognises the type of dirt and automatically adjusts the
washing parameters as appropriate.
4
ECO (*)
EN 50242
Dishes with normal
dirt, even with dried-
on residues.
Cold prewash
Wash at 52°C
Cold rinse
Rinse at 66°C
Dry
180’ ***
** **
5
INTENSIVE
(****)
Very dirty pans and
dishes, even with
dried-on residues.
Hot prewash
Wash at 70°C
Cold rinse (3)
Rinse at 70°C
Dry
150' ***
21 1,90
(*)
Reference program as per EN 50242 standard.
(**) See energy label.
(***)
For 3 digit models, see display.
(****)
Reference program for laboratories: Detergent: 20g in the dispenser + 10g in the door
or tablet. Configuration: see photo in “Using the baskets”.
(1)
Average power consumption with the softener set on level 2.
(2) The cycle duration and power consumption may vary according to the water and
room temperatures, and the type and amount of dishes.
(3)
1 or 2 cold rinses depending on the model.
The washing cycle will not take place if the dishwasher door is left open
or not properly closed.
User instructions
12
EXTRA PROGRAMS
(see relevant section for explanation of functioning modes)
DURATION
CONSUMPTION
PROGRAMME
NUMBER E SYMBOL
LOAD
CROCKERY
AND CUTLERY
PROGRAM
PROGRESS
MINUTI
(2)
WATER
LITRES (1)
POWER
KWh (2)
6
+
SOAK
Pans and dishes
awaiting
completion of the
load.
Cold prewash
15’ ***
5,5 0,02
7
+
FAST
Delicate dishes,
with light dirt,
washed
immediately after
use.
Wash at 38°C
Cold rinse
Rinse at 58°C
38’ ***
13 0,85
8
+
AUTO
40-50
Dishes with
normal dirt,
washed
immediately after
use
When the "AUTO" program is selected, the dishwasher
recognises the type of dirt and automatically adjusts the
washing parameters as appropriate.
9
+
SOFT
Dishes with
normal dirt,
washed
immediately after
use.
Wash at 55°C
Cold rinse
Rinse at 70°C
Dy
110’ ***
15 1,50
10
+
INTENSIVE
EXPRESS
Mixed dishes with
normal dirt without
dried-on residues.
Wash at 65°C
Cold rinse
Rinse at 70°C
50’ ***
10 1,20
Only run the soak program with half loads.
Options cannot be used with the soak program.
(***)
For 3 digit models, see display.
(1)
Average power consumption with the softener set on level 2..
(2)
The cycle duration and power consumption may vary according to the water and
room temperatures, and the type and amount of dishes.
The washing cycle will not take place if the dishwasher door is left open
or not properly closed.
User instructions
14
SPREAD HALF LOAD
(available in all programs except the soak program)
When there are not many dishes to be watched, the “spread half load”
option, controlled by button (10) is useful; it saves water and electricity
and reduces the program’s duration. Place dishes in both baskets then
load the detergent dispenser than less than the normal amount for a full
load..
EXTRA OPTIONS - “3/1” BUTTON
(available in all programs except the soak program)
Press buttons 6 + 8 (EXTRA PROGRAMS button + HYGIENE option
button) simultaneously to activate the "3/1" option; the respective light
(12) comes on to confirm the selection. The option is optimised for use of
detergents which are complete with salt and rinse aid, known on the
market as "3 in 1", "triple action", etc. With this option activated, any salt
and rinse aid If you wish to use detergents which already contain salt
and rinse aid already in the dishwasher will not be used.
N.B.: even with the "3/1" option selected, the regenerating salt/rinse aid
lights will still stay on if their containers are empty.
IMPORTANT: the option continues to be active until it is deactivated by
pressing buttons 6 + 8 simultaneously; the light (12) will then go out.
• 3/1 products are not suitable for use with excessively hard water.
Therefore, if the water hardness is set higher than H3, the 3/1
OPTION light (12) flashes to indicate a setting error. This does not
prevent the use of the option, but the washing results might not be of
the best.
User instructions
15
DELAYED START
(available in all programs except the soak program)
The start of the washing program can be delayed to program the
dishwasher to operate at the preferred time of day (e.g. overnight). Press
the PROGRAM DELAY button (13) to activate the option and display (14)
a 1 hour delay. Keep pressing to select the delay required, which may be
up to 9, 12 or 24 hours depending on the model.
When the door is closed, the appliance will prewash the dishes, after
which the "program delay" set will come into effect.
CANCELLING THE CURRENT PROGRAM
• To cancel the currently selected program, open the door and hold
down the PROGRAM SELECTION (3) button for a few seconds
until the indicator lights for programs 4 and 5 illuminate
simultaneously (the word "end" is displayed on the window).
• Close the door.
• After approximately 1 minute the dishwasher will advance to the end
of cycle.
CHANGING THE PROGRAM
To change the program in progress, simply open the door and select a
new program. When the door is closed the dishwasher will automatically
select the new program.
User instructions
17
4. Operating instructions
Once the dishwasher has been correctly installed, prepare for use as
follows:
• Adjust the water softening system;
• Add the regenerating salt;
• Add the rinse aid and detergent.
4.1 Using the water softening system
The amount of scale contained in the
water (water hardness index) can cause
whitish staining on the dry dishes, which
tend to become dull over time. The
dishwasher is equipped with an automatic
softening system which uses a special
regenerating salt to reduce the hardness
of the water.
The dishwasher is factory set for water
hardness level 3 (average hardness
41-60°dF – 24-31°dH).
When using water of medium hardness, the regenerating salt container
should be refilled after approximately 20 washing cycles. The salt
container can hold approximately 1.7 Kg of salt in grains. The container
is situated at the bottom of the dishwasher. After removing the lower
basket, unscrew the salt container cap by turning it anticlockwise and
pour in the salt using the funnel supplied with the dishwasher. Before
replacing the cap, remove any salt residues from around the opening.
• When using the dishwasher for the first time, in addition to the salt it
is also necessary to add one litre of water to the container.
• Each time the salt container is refilled, make sure that the cap is
securely closed. The mixture of water and detergent must never
penetrate the salt container, as this would compromise the operation
of the regeneration system. In the event of this occurring, the
warranty will be invalidated.
• Only use regenerating salt specially formulated for domestic
dishwashers. If using salt tablets, do not fill the container
completely.
SALT
User instructions
18
• Do not use table salt as it contains insoluble substances which,
over time, may damage the water softening system.
• When necessary, refill the regenerating salt container before
starting the washing program. In this way, the excess saline
solution will be immediately removed by the water; the prolonged
presence of salt water inside the tank may lead to corrosion.
Be careful not to confuse the salt and detergent packages; adding
detergent to the salt container will damage the water softening system.
ADJUSTING THE WATER SOFTENING SYSTEM
The dishwasher is equipped with a device which allows the softener
setting to be varied to suit the hardness of the mains water. The
hardness is set using the PROGRAM SELECTION BUTTON (3).
To access the setting function, hold the button down for more than 15
seconds. The WATER HARDNESS ADJUSTMENT INDICATOR LIGHT
(4) flashes, while the SELECTED PROGRAM INDICATOR LIGHTS (2)
show the current setting. Each pressure on the button changes the
setting following the sequence in the table below:
>
User instructions
20
ADDING THE RINSE AID
The rinse aid helps the dishes dry faster and
prevents the formation of scale deposits and
staining; it is automatically added to the water
during the final rinse cycle, from the container
situated on the inner side of the door.
To add rinse aid:
• Open the door.
• Rotate the container cap anticlockwise by ¼ of a turn and remove it.
• Add the rinse aid until the container is full (approximately 140 cc).
The optical level indicator on the side of the cap should be
completely obscured. Refill the rinse aid when the optical level
indicator becomes clear again, or when the rinse aid warning light
illuminates.
• Replace the cover and turn it in a clockwise direction.
• Use a cloth to remove any spillage of rinse aid which might lead to
the formation of excess foam.
ADJUSTING THE RINSE AID DISPENSER SETTING
The dishwasher is factory set for medium water hardness. However it
possible to change the setting by turning the dispenser’s selector to the
desired position: the amount of rinse aid dispensed is proportional to the
selector position.
• To adjust the rinse aid setting, rotate the dispenser cap through a
quarter turn in an anticlockwise direction and remove it.
• Then use a screwdriver to rotate the rinse aid selector to the desired
position.
• Replace the cap, turning it clockwise.
• The amount of rinse aid must be increased if the washed dishes
appear dull or feature circular stains.
• If, on the other hand, the dishes are sticky or have white streaks, it
is necessary to reduce the rinse aid setting.
User instructions
21
ADDING THE DETERGENT
To open the detergent dispenser cap, lightly press
the button P. Add the detergent and close the cap
carefully.
During the washing cycle, the dispenser will be
opened automatically.
• When a program with hot prewash is selected (see program table),
extra detergent must be placed in the cavity G/H (depending on
models).
• Use only detergents specially formulated for dishwashers. For
optimal washing results it is important to use a good quality detergent.
• The detergent packs must be sealed and stored in a dry place to
prevent the formation of lumps which may negatively affect washing
results. Once opened the detergent packs should not be kept for too
long, otherwise the detergent loses its effectiveness.
• Do not use detergents formulated for washing dishes by hand,
because they produce a great deal of foam and may negatively affect
the operation of the dishwasher.
• Add the correct amount of detergent. An insufficient amount of
detergent will result in a partial removal of dirt from the dishes,
whereas an excessive amount is wasteful and does not improve the
washing results.
• The market offers liquid and powder detergents with differing chemical
compositions, which may contain phosphates, or be phosphate-free
but contain natural enzymes.
- Detergents containing phosphates are more effective against
grease and starch at temperatures above 60°C.
- Enzyme detergents, on the other hand, are also effective at lower
temperatures (from 40 to 55°C) and are more easily
biodegradable. With enzyme detergents it is possible to obtain at
low temperatures comparable results to those which can only be
achieved at 65°C using traditional detergents.
For the safeguarding of the environment we recommend the use of
phosphate- and chlorine free detergents.
User instructions
22
• "3/1" Products
If you wish to use detergents which already contain salt and rinse
aid, check whether your dishwasher is fitted with the "3/1 option
button" on the "Controls description" page and then refer to the
section which explains how to use this function.
If the button is not provided, we recommend the use of conventional
products (separate detergent, salt and rinse aid), because with
conventional washing cycles "3/1" products might create problems
such as a white deposit, poor drying results and residues left on
dishes.
The introduction of detergent into the rinse aid dispenser, even in
liquid form, will damage the dishwasher.
4.3 General warnings and recommendations
Before using the dishwasher for the first time, it is advisable to read the
following recommendations concerning dish types to be washed and
their loading.
There are generally no constraints on the washing of domestic dishes,
but in certain cases it is necessary to take their characteristics into
account.
Before loading the dishes into the baskets it is necessary to:
• remove coarse food remains: e.g. bones, fish-bones, etc. which
may clog the filter or damage the wash pump.
• soak any pots or pans with burnt-on food remains on the bottom to
facilitate removal, then load them into the LOWER BASKET.
There is no need to pre-wash the dishes under running water before
loading them into the baskets since this only wastes water.
Correct loading of the dishes helps ensure optimal washing
results.
User instructions
23
WARNING!
• Make sure that the dishes are securely in place so that they cannot
tip over or obstruct the rotation of the spray arms during the
washing cycle.
• Do not place very small objects in the baskets as these could fall
and obstruct the spray arms or the wash pump.
• Containers such as cups, bowls, glasses and pots should always
be loaded with the opening facing downwards and with any cavities
at an angle, to allow the water to drain out.
• Do not stack dishes or place them in such a way that they cover
one other.
• Do not place glasses too close together because they may knock
against each other and break, or there might be staining at the
point where they touch.
MAKE SURE that the items being washed are dishwasher-safe.
Items which are not dishwasher-safe:
• Wooden dishes, pots or pans: these may be damaged by the
high washing temperatures.
• Handcrafted items: these are rarely suitable for washing in a
dishwasher. The relatively high water temperatures and the
detergents used may damage them.
• Plastic dishes: heat resistant plastic dishes must be washed in the
upper basket.
• Dishes and objects in copper, tin, zinc or brass: these tend to
stain.
• Aluminium dishes: items made from anodised aluminium may
lose their colour.
• Silverware: silver items may stain.
• Glass and crystal: in general, glass and crystal objects can be
washed in the dishwasher. However, certain types of glass and
crystal may become dull and lose their clearness after many
washings. Therefore, for these items we recommend using the
least aggressive program available.
• Decorated items: the decorated objects available on the market
are generally able to withstand washing in the dishwasher,
although the colours may fade after a great many washes. If in
doubt as to the fastness of the colours, it is advisable to wash just a
few items at a time for approximately one month.
User instructions
24
4.4 Using the baskets
The dishwasher has a capacity of 12 place-settings, including serving
dishes.
LOWER BASKET
The lower basket receives the full force of the lower spray arm, and
should therefore be used for the “toughest” items with a heavier degree
of soiling.
All types and combinations of loads are
permitted, provided that the dishes, pots and
pans are arranged with all the soiled surfaces
exposed to the water jets coming from the
bottom.
With fixed supports
To make the most of the space inside the
basket when loading large items, certain
models are equipped with tip-up supports for
plates in 2 or 4 sections.
With tip-up supports
BOTTOM BASKET INSERTS
Some models are equipped with bottom basket inserts which improve
the drying of dishes. The inserts are supplied in the accessories bag; to
use them, simply fit them into place as shown.
User instructions
25
LOADING THE LOWER BASKET
Carefully load flat plates, soup plates, dessert and serving dishes,
positioning them vertically. Pots, pans and their covers must be loaded
upside down. When loading soup plates and dessert bowls, be sure to
leave a gap between them.
Loading examples:
CUTLERY BASKET
The basket has removable top grids into which items of cutlery can be
inserted to keep them properly spaced and allow water to pass between
them effectively.
The cutlery supports and central lid are in the bag of accessories. The
central lid is intended to act only as a cover: do not place the cutlery in it.
Depending on model the grids may vary in shape.
The cutlery should be arranged in an orderly manner inside the basket,
with the handles pointing downwards. Take care during loading to avoid
injury from the knife blades. The basket is suitable for all types of cutlery,
except those long enough to interfere with the upper spray arm. Ladles,
wooden spoons and cooking knives can be placed in the upper basket,
making sure that the knife blades do not protrude from the basket.
User instructions
26
UPPER BASKET
It is recommended to load the upper basket with small- or medium-sized
items such as glasses, small plates, tea or coffee cups, shallow bowls
and light objects made from heat resistant plastic. If the upper basket is
used in the lowermost position, it can also be loaded with serving dishes,
provided they are only slightly soiled.
LOADING THE UPPER BASKET
Load plates facing forward; cups, bowls etc. must always be facing
downwards. The left side of the basket can be loaded with cups and
glasses on two levels. In the centre section, plates and saucers can be
loaded vertically into the supports provided.
Loading examples:
Examples of loading for intensive dirt:
User instructions
27
Depending on the models, the basket may be equipped with some or all
of the following accessories:
- Supports for cups or long objects (ladles, spoons…), on the left;
can be tipped to the vertical position when not in use.
- Long-stemmed glass holder, on the left; to use, simply lift and
fix onto the hooks provided.
- Cutlery racks, on the right, designed for knives and teaspoons;
for teaspoons, pull out the sliding support. The racks can be
tipped to the vertical position when not in use.
- Fixed or movable racks in the middle. The movable supports
can be fixed vertical, resting on the bottom of the basket when
not in use, or set in the intermediate position, as required.
Produkspesifikasjoner
| Merke: | Teka |
| Kategori: | Oppvaskmaskin |
| Modell: | DW8 80 FI |
Trenger du hjelp?
Hvis du trenger hjelp med Teka DW8 80 FI still et spørsmål nedenfor, og andre brukere vil svare deg
Oppvaskmaskin Teka Manualer
11 August 2025
11 August 2025
11 August 2025
20 Februar 2025
7 Februar 2025
6 Januar 2025
6 Januar 2025
6 Januar 2025
4 Januar 2025
4 Januar 2025
Oppvaskmaskin Manualer
- Oppvaskmaskin Maytag
- Oppvaskmaskin Miele
- Oppvaskmaskin Whirlpool
- Oppvaskmaskin Etna
- Oppvaskmaskin Haier
- Oppvaskmaskin KitchenAid
- Oppvaskmaskin Pelgrim
- Oppvaskmaskin Royal Catering
- Oppvaskmaskin LG
- Oppvaskmaskin Bosch
- Oppvaskmaskin Jocel
- Oppvaskmaskin BEKO
- Oppvaskmaskin Exquisit
- Oppvaskmaskin Grundig
- Oppvaskmaskin Hisense
- Oppvaskmaskin Sharp
- Oppvaskmaskin Electrolux
- Oppvaskmaskin Café
- Oppvaskmaskin Balay
- Oppvaskmaskin Siemens
- Oppvaskmaskin Koldfront
- Oppvaskmaskin Arcelik
- Oppvaskmaskin Danby
- Oppvaskmaskin Bartscher
- Oppvaskmaskin Smeg
- Oppvaskmaskin Hoover
- Oppvaskmaskin Saba
- Oppvaskmaskin Hotpoint
- Oppvaskmaskin Nabo
- Oppvaskmaskin Amica
- Oppvaskmaskin IKEA
- Oppvaskmaskin Ignis
- Oppvaskmaskin AEG
- Oppvaskmaskin Rosieres
- Oppvaskmaskin Artusi
- Oppvaskmaskin Cecotec
- Oppvaskmaskin Samsung
- Oppvaskmaskin Neff
- Oppvaskmaskin Delonghi
- Oppvaskmaskin Comfee
- Oppvaskmaskin Imarflex
- Oppvaskmaskin Bomann
- Oppvaskmaskin Edgestar
- Oppvaskmaskin Kogan
- Oppvaskmaskin Caple
- Oppvaskmaskin PKM
- Oppvaskmaskin Midea
- Oppvaskmaskin Franke
- Oppvaskmaskin Sauber
- Oppvaskmaskin Candy
- Oppvaskmaskin CDA
- Oppvaskmaskin Kuppersbusch
- Oppvaskmaskin Gorenje
- Oppvaskmaskin Summit
- Oppvaskmaskin Brandt
- Oppvaskmaskin Gram
- Oppvaskmaskin Master Kitchen
- Oppvaskmaskin Monogram
- Oppvaskmaskin Vox
- Oppvaskmaskin Westinghouse
- Oppvaskmaskin Medion
- Oppvaskmaskin Kluge
- Oppvaskmaskin Privileg
- Oppvaskmaskin MPM
- Oppvaskmaskin Cosmo
- Oppvaskmaskin Euro Appliances
- Oppvaskmaskin Bauknecht
- Oppvaskmaskin Frigidaire
- Oppvaskmaskin Defy
- Oppvaskmaskin Euromaid
- Oppvaskmaskin GE
- Oppvaskmaskin Omega
- Oppvaskmaskin Fisher Paykel
- Oppvaskmaskin Fulgor Milano
- Oppvaskmaskin Hyundai
- Oppvaskmaskin Infiniton
- Oppvaskmaskin Indesit
- Oppvaskmaskin Asko
- Oppvaskmaskin Blaupunkt
- Oppvaskmaskin Dacor
- Oppvaskmaskin Cylinda
- Oppvaskmaskin AYA
- Oppvaskmaskin Fisher And Paykel
- Oppvaskmaskin Elba
- Oppvaskmaskin Philco
- Oppvaskmaskin Jenn-Air
- Oppvaskmaskin Wisberg
- Oppvaskmaskin ECG
- Oppvaskmaskin Klarstein
- Oppvaskmaskin ATAG
- Oppvaskmaskin Freggia
- Oppvaskmaskin V-Zug
- Oppvaskmaskin Black And Decker
- Oppvaskmaskin Sauter
- Oppvaskmaskin Element
- Oppvaskmaskin Avanti
- Oppvaskmaskin Kucht
- Oppvaskmaskin Nodor
- Oppvaskmaskin Technika
- Oppvaskmaskin Hansa
- Oppvaskmaskin Thor
- Oppvaskmaskin Kenmore
- Oppvaskmaskin Meireles
- Oppvaskmaskin Fagor
- Oppvaskmaskin Edesa
- Oppvaskmaskin IFB
- Oppvaskmaskin Profilo
- Oppvaskmaskin Gaggenau
- Oppvaskmaskin Constructa
- Oppvaskmaskin KKT Kolbe
- Oppvaskmaskin Tisira
- Oppvaskmaskin Porter & Charles
- Oppvaskmaskin Zerowatt
- Oppvaskmaskin Baumatic
- Oppvaskmaskin Iberna
- Oppvaskmaskin Silvercrest
- Oppvaskmaskin Otsein
- Oppvaskmaskin Signature
- Oppvaskmaskin Corberó
- Oppvaskmaskin Rangemaster
- Oppvaskmaskin Daewoo
- Oppvaskmaskin Emerio
- Oppvaskmaskin Eurom
- Oppvaskmaskin Barazza
- Oppvaskmaskin Thermador
- Oppvaskmaskin Continental Edison
- Oppvaskmaskin Crosley
- Oppvaskmaskin Pitsos
- Oppvaskmaskin La Germania
- Oppvaskmaskin Emilia
- Oppvaskmaskin Esatto
- Oppvaskmaskin JennAir
- Oppvaskmaskin Kaiser
- Oppvaskmaskin Blomberg
- Oppvaskmaskin Robinhood
- Oppvaskmaskin De Dietrich
- Oppvaskmaskin Orima
- Oppvaskmaskin Zanussi
- Oppvaskmaskin Qilive
- Oppvaskmaskin Junker
- Oppvaskmaskin Benavent
- Oppvaskmaskin Black Decker
- Oppvaskmaskin Bellini
- Oppvaskmaskin Cookology
- Oppvaskmaskin Hanseatic
- Oppvaskmaskin Proline
- Oppvaskmaskin Hobart
- Oppvaskmaskin Pando
- Oppvaskmaskin Equator
- Oppvaskmaskin SEIKI
- Oppvaskmaskin Oranier
- Oppvaskmaskin Upo
- Oppvaskmaskin Sammic
- Oppvaskmaskin Ariston Thermo
- Oppvaskmaskin Hoonved
- Oppvaskmaskin Helkama
- Oppvaskmaskin Rex
- Oppvaskmaskin Classique
- Oppvaskmaskin Castor
- Oppvaskmaskin New World
- Oppvaskmaskin Essentiel B
- Oppvaskmaskin InAlto
- Oppvaskmaskin Veripart
- Oppvaskmaskin Bompani
- Oppvaskmaskin Prima
- Oppvaskmaskin Cove
- Oppvaskmaskin Champion
- Oppvaskmaskin Noble
- Oppvaskmaskin Jackson
- Oppvaskmaskin AIRMSEN
Nyeste Oppvaskmaskin Manualer
2 September 2025
2 September 2025
2 September 2025
2 September 2025
1 September 2025
1 September 2025
1 September 2025
1 September 2025
1 September 2025
31 August 2025
