Side 1/12

Active 2.1 multimedia set with table remote control

Technical specifications and operating instructions

Concept C 100 Concept C 200

· Concept C 100 / 200

For your information

The information in this document may be chan-

ged without advance notification and does not

represent any obligation on the part of Lautspre-

cher Teufel GmbH.

No part of these operating instructions may be

copied in any way, whether electronically, mecha-

nically, using photocopies or recordings, or trans-

ferred without the prior written agreement of

Lautsprecher Teufel GmbH.

Version 1.0

December 2008

Trademark

® All trademarks are the property of their

respective owners.

Original packaging

We recommend keeping the packaging if you want

to take advantage of the eight-week right to re-

turn goods, because we can only accept the spea-

kers IN THEIR ORIGINAL PACKAGING. We are unable

to supply empty boxes!

Technical Data

Technical data can be found in the product de-

scription on our website at:

www.teufel.eu

Contact

Please contact our service department if you

have any questions, suggestions or if there is

anything you think we could do better.

Lautsprecher Teufel GmbH

Gewerbehof Bülowbogen · Bülowstraße 66

10783 Berlin (Germany)

Tel.: +49 (30) - 30 09 300

Fax: +49 (30) - 30 09 30 30

www.teufel.eu

Warranty terms

12-year warranty for speakers and 2-year war-

ranty for power amplifiers and electronics (from

purchase date) on materials and work time, with

the exception of damage caused by incorrect use

or electrical or mechanical overload. An original

copy of our invoice is required as the warranty

document. This warranty is exclusively valid for

speakers, power amplifiers and electronics that

have been purchased from Teufel for private use

by end customers. The warranty is not valid for

speakers, power amplifiers and electronics that

the end user has purchased from a different dis-

tributor. For third-party products, the warranty

conditions of the respective manufacturers shall

apply. If the Teufel product is sold on privately, the

warranty may be transferred to the purchaser,

providing that the original proof of purchase is

also transferred.

Returns

Teufel provides an eight-week right to exchange

or return the product with reimbursement of the

full purchase price paid.

The return of individual components from a set

is only possible if these components are also of-

fered for sale separately by Lautsprecher Teufel.

If one or more components are returned, any

price discount given by Lautsprecher Teufel on

all components in a set as part of the price for

the set is waived. When returning a component,

the customer will be reimbursed for the price dif-

ference between the set price and the purchase

price of the individual components retained by

him/her. The financial outcome for customers is

as if they had bought the remaining components

at the individual price from the outset.

You can find more information on the subject of

returns on the returns form that accompanies

the delivery or online in the support area of our

website www.teufel.eu.

If you need to return an item, do not act without

the prior agreement of Lautsprecher Teufel.

We can only process and accept returns if you

have informed us first by phone and discussed

the procedure with us!

· Concept C 100 / 200

Contents

Manual Version 1.0

Table of contents..............................................................Page 3

Introduction to Concept C 100 / 200 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 4

Unpacking · Contents ..........................................................Page 5

Accessories (optional) · Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 6

Set-up .......................................................................Page 7

Connecting the Concept C 100 ..................................................Page 8

Connecting the Concept C 200 ..................................................Page 9

Operating the Concept C 100 / 200 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 10

Operating elements on the subwoofer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 11

Troubleshooting...............................................................Page 12

Produkspesifikasjoner

Merke:	Teufel
Kategori:	Høyttaler
Modell:	Concept C 100
Strømkilde:	AC
Strømforbruk (maks.):	150 W
Anbefalt bruk:	PC
Antall satellitter:	2
AC-inngangsspenning:	220-240 V
Strømforbruk (standby):	2 W
Produktfarge:	Sort
Satelitthøyttalerens dimensjoner (BxDxH):	90 x 98 x 90 mm
Kroppsmateriale:	MDF
Subwoofer-vekt:	12500 g
Lyd-utgang kanaler:	2.1 kanaler
RMS-rangert strøm/utgangseffekt:	65 W
Satelitthøyttalere RMS-strøm:	15 W
Subwoofer RMS-styrke:	35 W
Frekvensomfang for satelitthøyttaler:	180 - 20000 Hz
Subwooferens dimensjoner (BxDxH):	247 x 380 x 435 mm
Forsterkerenhet medfølger:	Ja
Satelitthøyttalertype:	1-veis
Impedans for satellitthøyttaler:	4 Ω
Satelitthøyttalervekt:	430 g
Forsterkerenhetens formfaktor:	Innebygget
