Teufel Consono 35 Connect plus Bruksanvisning

Teufel Høyttaler Consono 35 Connect plus

Les nedenfor 📖 manual på norsk for Teufel Consono 35 Connect plus (17 sider) i kategorien Høyttaler. Denne guiden var nyttig for 2 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/17

Technical description and operating instructions

Consono 35

Active subwoofer US 5110/1

Technical description and operating instructions

Consono 35

5.1 Home Cinema Speaker Set

2 • Consono 35

Contents

Product contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

General notes and information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Safety notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Connection and settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Care and cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Protecting the environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

햲

4 x satellite speakers CS 35 FCR

햳

1 x center speaker CS 35 C

햴

1 x holder for center speaker CS 35 C

You will ﬁ nd the corresponding active subwoofer for this

5.1 home cinema speaker set in a separate box.

Check that all items have been delivered and that noth-•

ing is damaged.

If the delivery is incomplete or you ﬁ nd damage sus-•

tained in transit, do not operate the product but contact

our service department (see page 3).

Product Contents

햳

햴

햲

Produkspesifikasjoner

Merke:	Teufel
Kategori:	Høyttaler
Modell:	Consono 35 Connect plus
Strømkilde:	AC
Strømforbruk (maks.):	285 W
Anbefalt bruk:	Hjemmekino
Bassrefleks:	Ja
Antall satellitter:	4
Strømforbruk (standby):	0.34 W
Produktfarge:	Sort
Satelitthøyttalerens dimensjoner (BxDxH):	90 x 98 x 200 mm
Subwoofer-vekt:	17000 g
Lyd-utgang kanaler:	5.1 kanaler
RMS-rangert strøm/utgangseffekt:	- W
Satelitthøyttalere RMS-strøm:	- W
Frekvensomfang for satelitthøyttaler:	150 - 20000 Hz
Senterhøyttaler vekt:	800 g
Subwooferens dimensjoner (BxDxH):	240 x 410 x 490 mm
Senterhøyttalerens dimensjoner (BxDxH):	200 x 98 x 90 mm
Frekvensomfang for senterhøyttaler:	150 - 20000 Hz
Subwoofer-type:	Aktiv subwoofer
Forsterkerenhet medfølger:	Nei
Satelitthøyttalertype:	3-veis
Satelitthøyttalervekt:	800 g
