Satellite speakers
LT5 Mk2 FCR
Proper use
Only use the speakers as described in these operating instruc-
tions. Any other use will be deemed as not in accordance with
the instructions and may lead to damage of property or even
persons. The manufacturer accepts no liability for damage
caused by use not in accordance with the
speakers are intended for private use.
Before operating the speakers please read the safety
notes and operating instructions carefully. This is the
only way to use all functions safely and reliably. Keep
the operating instructions safe and pass them on to anyone
who may own the unit after you.
Notice
The information in this document may change without prior
notice and in no way constitutes any liability on the part of
Lautsprecher Teufel GmbH. No part of these instructions may
be reproduced in any form or be broadcasted in any way elec-
tronically, mechanically, by photocopy or recording without the
written permission of Lautsprecher Teufel GmbH.
Original packaging
If you wish to exercise your eight-week right of return, we ask
that you be absolutely sure to hold onto the packaging. We can
only accept the return of a device WITH THE ORIGINAL PACK-
AGING. Empty boxes are not available!
Complaints
In case of a complaint we implicitly need your invoice number
and the serial or lot number for processing. The serial number
can be found on the back side of the device.
Many thanks for your support!
Contact
For questions, suggestions or criticism please contact our
customer service department:
Lautsprecher Teufel GmbH
Gewerbehof Buelowbogen
Buelowstrasse 66
10783 Berlin (Germany)
Phone 00800 - 200 300 40 (free of charge)
Fax: +49 (0)30 / 300 930 930
E-mail: servcie@teufelaudio.com
www.teufelaudio.com
Dimensions (WxHxD) 160 x 460 x 140 mm
Weight 8.3 kg
Nominal impedance 4–8 ohm
Technical changes reserved!
You can nd further technical data on our website.
Technical data
This product conforms with Council of the European
Union guidelines 2004/108/EC and 2006/95/EC
General notes and information
Technical Description and
Operating Instructions
Product contents
Check to be sure
Check that all items have been delivered and that
nothing is damaged.
If the delivery is incomplete or you nd damage sustained in
transit, do not operate the device; instead contact our service
department.
a 2 x satellite speaker LT5 Mk2 FCR
a
Caution icons
You will nd the following caution icons in these instructions:
High risk! Failure to observe the warning may result
in severe personal injury or death.
=
Danger
Moderate risk! Failure to observe the warning may
result in property damage.
=
Attention
Minor risk! Points which should be observed when
handling the unit.
=
Attention
Fire hazard!
Improper use may lead to damage or re.
• Do not place open ames such as burning candles or
similar on the unit.
• Ensure sufcient ventilation.
• Do not place the unit in direct sunlight.
• Only use the unit in indoor areas.
• Do not operate the unit in moist areas and protect it from
drops of water and splash water.
Also take care not to stand vases or other containers lled
with liquid on or near the unit in order to avoid liquid get-
ting into the housing.
Danger
Danger of injury/damage!
Incorrect location may result in damage.
• Never use the unit unmounted in vehicles, in unstable
locations, on wobbly stands or furniture, on under-
dimensioned brackets etc. The speakers could tip or fall
down and cause injury to persons or be damaged.
• Place the speakers in such a way that they cannot be
knocked over unseen and make sure that the cables do
not pose a trip hazard.
• Carefully follow the installation instructions.
• If mounting the speakers on the wall, make sure that the
job is carried out by a professional.
• Only use suitable wall holders to mount the speakers.
Verify the carrying capacity of the walls.
• Do not place the unit near sources of heat (e.g. heaters,
ovens, other heat generating equipment such as ampli-
ers etc.).
Danger
Danger to children!
Children can become trapped in the packing lm
when playing and suffocate.
• Do not allow children to play with the unit or the packing
lm. Danger of suffocation.
• Ensure that children do not remove small parts from the
unit or take them off of the unit (e.g. control knobs or plug
adapters). They could swallow the parts and choke.
Never allow children to operate electrical devices unsuper-
vised.
Danger to hearing
Loud noise may lead to hearing loss.
Particularly when the subwoofer has been set
to maximum volume and the unit is activated, very high
noise pressure may suddenly be produced. This may have
psychological consequences and also cause physical injury.
Children and pets are particularly at risk.
• Set your signal source unit volume control to a low setting.
• When the volume is set high, always keep a certain dis-
tance from the unit and never place your ear directly on
the speaker.
• To avoid damage to health, avoid extended listening at
high volume.
Safety notes
Setup and connection
Setup
Note
Our website contains comprehensive notes for correct setup.
• Select a stable, level base.
• Make sure that the environment is clean and free from dust.
• Avoid placing the unit close to sources of heat or in direct
sunlight.
• Arrange the connector cables so that they do not pose a trip
hazard.
• Do not place any heavy objects on the cables or the speak-
ers.
Wall mounting
Danger
Risk of damage!
Improper assembly may result in damage.
• If mounting the speakers on the wall, make sure that the
installation is carried out expertly.
• Before drilling the holes, make sure that no pipes are
located within the drilling area using a metal detector.
• Only use suitable screws and dowels to mount the speak-
ers. Verify the carrying capacity of the walls.
• Hang the satellite speakers up
on the wall using the keyhole
openings on the speaker back
side and the screws you previously
mounted.
• You can also use these open-
ings for mounting a wall holder
or speaker stand. You can nd
suitable products for this in our
web shop.
Connecting
Danger
Danger of injury/damage!
Arrange the cables so that they do not pose a
trip hazard.
• Pull the power plug of your AV receiver or multi-channel ac-
tive subwoofer out of the socket.
• Lay the speaker cables from your AV receiver or multi-
channel active subwoofer to each speaker. These cables
should be high-quality double-wire speaker cable with marked
strands. The cross section should amount to 1.5 to 4mm
2
.
• A connector comprising two terminals is located on the
back side of each speaker, to which you have to connect the
speaker cables.
• The terminal clips are each marked red (+) and black (-).
Make sure the polarity is correct!
Connect the like coloured terminals. Otherwise the
sound quality will suffer.
The speaker connections of your AV receiver or
multi-channel
active subwoofer
should be marked similarly. The strands
of the speaker cables are marked with different colours or
shapes.
1. Split the single wire down to approx. 30 mm on both ends
and strip approx. 10 mm of insulation off of each cord.
2. Twist the stripped single wire ends together so that no wire
protrudes. Tin coating is not necessary.
3. Turn the connector terminal counterclockwise until loose.
Run the stripped cable end into the now visible hole. Close
the terminal by turning it counterclockwise. The cable has
now been clamped in place.
4. Connect the cables to the other speaker in the same way.
5. Connect the speaker cables to your AV receiver
or
multi-
channel active subwoofer. The operating instructions of the
appliance should contain notes on this.
Crossover frequency
The ideal separation frequency on the AV amplier or multi-
channel active subwoofer for the satellite speaker LT5 Mk2 FCR
is 100 Hz.
