Technical specifications and operating manual

5.1 Home Theatre Set with Active Subwoofer

·Motiv 6

About this document

The information in this document is subject to

change without warning. Lautsprecher Teufel

GmbH is in no way bound by the information pro-

vided herein.

No section of this document may be reproduced

or copied by any electronic or mechanical means,

including photocopying and recording, without

prior written consent from Lautsprecher Teufel

GmbH.

Version 1.3

March 2009

Trademarks

® All registered trademarks remain the

propertyof their respective owners.

Original packaging

We recommend that you hold on to the packag-

ing of all your new Teufel products, as we only

accept loudspeakers back within the initial eight-

week return period if they are shipped in their

ORIGINAL PACKAGING. We do not provide packag-

ing boxes separately.

Technical specifications

For technical specifications of the pro-

ducts described herein, please refer to

www.teufel.eu.

Contact

If you have any questions, suggestions or criti-

cisms, please contact our support team:

Lautsprecher Teufel GmbH

Gewerbehof Bülowbogen · Bülowstraße 66

10783 Berlin (Germany)

Ph.: +49(30) - 30 09 300

Fax:+49(30) - 30 09 30 30

www.teufel.eu

Terms of warranty

Lautsprecher Teufel GmbH provides a twelve-year

warranty for loudspeakers and a two-year war-

ranty for amplifiers and electrical components,

starting at the purchase date. The warranty cov-

ers all materials and time needed. The warranty

does not cover devices damaged as a result of im-

proper use or electrical/mechanical overloading.

The original Teufel invoice is your proof of war-

ranty. This warranty applies exclusively to loud-

speakers, amplifiers and electronic components

purchased by consumers from Teufel for private

usage. The warranty does not apply to loudspea-

kers, amplifiers and electronic components sold

to consumers through third-party dealers. For

third-party products supplied together with the

Teufel system, the terms of warranty of the man-

ufacturer in question apply. When Teufel products

are resold privately, the warranty may be trans-

ferred to the new owner. For this, the new owner

requires the original Teufel invoice.

Returns policy

Teufel provides an eight-week right of return with

a money-back guarantee.

You may only return individual components from

a set if Teufel offers these components for sale

separately. If you return one or more individual

components from a set, this voids the discount

that Teufel provides on the sale of components

as a set. This means that for individually returned

components from a set, you will be refunded the

difference between the set price and the sum

purchase price of the individual components you

decide to keep, i.e., we will deduct the discount

that applies to set purchases.

For further information on returns, please refer

to the returns form provided with your ship-

ment (or online at www.teufel.eu in the support

section).

If you decide to return any or all of the purchased

goods, please always contact us first.

Note that we can only process and accept

returned goods if you have telephoned us in

advance and discussed the required returns

procedure.

·Motiv 6

Contents

Contents .....................................................................Page 3

Safety guidelines..............................................................Page 4

Introduction .................................................................Page 5

Unpacking · Included components ...............................................Page 6

Accessories · Upgrading ........................................................Page 7

Speaker positions in the 5.1 configuration ........................................Page 8

Speaker positions in the 6.1 configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 10

Speaker positions in the 7.1 configuration ........................................Page 11

Connections ..................................................................Page 12

Settings......................................................................Page 13

Controls (subwoofer) ..........................................................Page 14

Problems and solutions · Cleaning ...............................................Page 15

Glossary .....................................................................Page 16

Manual Version 1.3

Produkspesifikasjoner

Merke:	Teufel
Kategori:	Høyttaler
Modell:	Motiv 6 Set M
Strømkilde:	AC
Anbefalt bruk:	Hjemmekino
Antall satellitter:	2
Produktfarge:	Sort
Satelitthøyttalerens dimensjoner (BxDxH):	170 x 60 x 520 mm
Senterhøyttalertype:	3-veis
Subwoofer-vekt:	22300 g
Lyd-utgang kanaler:	5.1 kanaler
RMS-rangert strøm/utgangseffekt:	- W
Satelitthøyttalere RMS-strøm:	- W
Frekvensomfang for satelitthøyttaler:	100 - 20000 Hz
Senterhøyttaler vekt:	2830 g
Subwooferens dimensjoner (BxDxH):	330 x 470 x 510 mm
Senterhøyttalerens dimensjoner (BxDxH):	520 x 60 x 170 mm
Frekvensomfang for senterhøyttaler:	100 - 20000 Hz
Subwoofer-type:	Aktiv subwoofer
Frekvensomgang subwoofer:	40 - 240 Hz
Satelitthøyttalertype:	3-veis
Satelitthøyttalervekt:	2600 g
Fronthøyttalertype:	3-veis
Fronthøyttalerens frekvensområde:	100 - 20000 Hz
Dimensjoner fremste høyttaler (WxDxH):	280 x 210 x 1124 mm
Vekt fremste høyttaler:	10500 g
