Technical Description and Operating Instructions

Stereo Shelf Speakers

Ultima 20 Mk 2

• Ultima 20 Mk 2

Contents

General notes and information ......................................................................................................................................3

Notice .......................................................................................................................................................... 3

Original packaging ........................................................................................................................................ 3

Contact ........................................................................................................................................................ 3

Proper use ..................................................................................................................................................... 3

Safety notes ..................................................................................................................................................................4

Caution icons ................................................................................................................................................ 4

Safety notes .................................................................................................................................................. 4

Unpacking and setup .....................................................................................................................................................5

Check to be sure ............................................................................................................................................ 5

Location tips .................................................................................................................................................. 5

Removing the cover grill .................................................................................................................................. 5

Connecting ....................................................................................................................................................................6

Connection variations ..................................................................................................................................... 6

Connecting the cables .................................................................................................................................... 6

Care and cleaning .........................................................................................................................................................7

Protecting the environment ............................................................................................................................................7

Technical data ...............................................................................................................................................................8

• Ultima 20 Mk 2

Notice

The information in this document may change without

prior notice and in no way constitutes any liability on the

part of Lautsprecher Teufel GmbH.

No part of these instructions may be reproduced in any

form or be broadcasted in any way electronically, me-

chanically, by photocopy or recording without the written

permission of Lautsprecher Teufel GmbH.

Version 1.0

May 2012

Original packaging

If you wish to exercise your eight-week right of return, we

ask that you be absolutely sure to hold onto the packag-

ing. We can only accept the return of the speakers IN

THE ORIGINAL PACKAGING.

Empty boxes are not available!

Complaints

In case of complaint we will need the following informa-

tion to process your enquiry:

1. Invoice Number

Can be found on the sales slip (enclosed with the

product) or on the order conﬁ rmation received as a PDF

document, e.g. 4322543.

2. Serial number and batch number respectively

Located on the back of the unit,

e.g. serial number: UL 04007480121A

Many thanks for your support!

Contact

For questions, suggestions or criticism please contact our

customer service department:

Lautsprecher Teufel GmbH

Gewerbehof Buelowbogen

Buelowstrasse 66

10783 Berlin (Germany)

Phone: 00800 - 200 300 40 (free of charge)

Fax: +49 (0)30 - 300 930 930

E-mail: service@teufelaudio.com

www.teufelaudio.com

Proper use

The product is designed for playback of audio signals.

Only use it as described in these operating instructions.

Any other use will be deemed as not in accordance with

the instructions and may lead to damage to property or

even persons.

The manufacturer accepts no liability for damage caused

by use not in accordance with the instructions.

The unit is intended for private use.

Before operating the product please read the

safety notes and operating instructions carefully.

This is the only way to use all functions safely

and reliably.

Keep the operating instructions safe and pass them on to

anyone who may own the unit after you.

General notes and information

Produkspesifikasjoner

Merke:	Teufel
Kategori:	Høyttaler
Modell:	Ultima 20 Mk2
Vekt:	6000 g
Bredde:	215 mm
Dybde:	240 mm
Høyde:	335 mm
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Volumkontroll:	Nei
Anbefalt bruk:	Høyttalersett
Impedans:	4 Ω
Egnet for utendørs bruk:	Nei
Høyttalerplassering:	Bord bokhylle
Basshøyttaler:	Ja
Peak Music Power Output (PMPO):	80 W
Bassrefleks:	Ja
Høyttalerkabinett:	Refleks
Forsterker:	Nei
Diskanthøyttaler:	Ja
Høyttalerposisjon:	Front
Avtakbart beskyttelsesdeksel:	Ja
THX-sertifisert:	Nei
Produktfarge:	Sort
Strøminngang/AC (strøm) inn:	Nei
AUX-inngang:	Nei
Kroppsmateriale:	MDF
Av/på-bryter:	Nei
Ethernet/bredbåndsforbindelse:	Nei
Lyd-utgang kanaler:	2.0 kanaler
RMS-rangert strøm/utgangseffekt:	50 W
Utjevner/frekvenskorrigerer:	Nei
Fjerndrevet:	Nei
Antall drivere:	2
Høyttaler type:	2-veis
Frekvensrekkevidde:	70 - 20000 Hz
Basshøyttalerens diameter:	165 mm
Diskant diameter:	25 mm
Sensitivitet/følsomhet:	84 dB
Diskanthøyttalerens diameter:	1 "
Basshøyttalerens diameter (imperisk):	6.5 "
Driversylinder, materiale:	Fiberglass
Ledningskontakt:	Ja
Overgangsfrekvens:	2600 Hz
Transducermateriale:	Polyfabric
Anbefalt forsterkereffekt (maks.):	50 W
Anbefalt forsterkereffekt (min.):	30 W
