FEATURES & BENEFITS
High-Powered BTU Burners - From a high-powered 18,000 BTU burner
to a burner with a steady 650 BTU simmer function, this range gives you
the power you need for large family meals and the consistent low heat
desired for cooking delicate sauces or melting chocolate
LuxGlide™ Telescopic Racks - Telescopic racks use ball bearing rack
guides for an effortless glide in and out of the oven. This luxury feature
allows the rack to extend fully without tipping over for smooth, easy
handling of even the heaviest dishes, and adjusts to fit different rack
support levels
Gas Flame Broiler - Reflective gas flame broiler radiates heat evenly to
sear your food and seal in the juices
Commercial Convection Fan - Convection fan provides controlled heat
distribution for fast and efficient cooking
LED Control Panel Lights - When in operation, the LED control panel
lights illuminate a striking blue for an added pop of color
Large Oven Capacity - 4.2 cu. ft. oven capacity can accomodate multiple
dishes for enhanced cooking
Continuous Cast-Iron Cooking Grates - Heavy-duty continuous
cast-iron cooking grates that can handle any size cookware
Brilliant Blue Porcelain Interior - The brilliant blue porcelain interior
adds a bold, stylish touch to your professional range
Heavy Duty Control Knobs - Heavy duty, die-cast metal burner control
knobs add style and durability
Black Porcelain Spill Tray - Black porcelain spill tray on cooktop
catches the mess and makes cleanup easy
Automatic Reignition Feature - Automatic reignition feature relights an
extinguished flame for safer cooking
30 INCH PROFESSIONAL GAS RANGE
ACCESSORIES (NOT INCLUDED)
Liquid Propane Gas Conversion Kit LPKHRG3080U
30-inch Telescopic Rack TR30SS
30-inch Island Trim ITHRG3080U
Cast Iron Reversible Griddle RG1022
Wok Ring WK01
Cast Iron Range Griddle RG1032
Product: 30 Inch Professional Gas Range in Stainless Steel
Model Number: HRG3080U / HRG3080ULP
HRG3080U / HRG3080ULP
LIMITED WARRANTY: 24 MONTHS ON
PARTS AND LABOR
TECHNICAL DETAILS
Fuel Type Natural Gas / LP Convertible
Electrical Requirements 120V
Circuit Breaker (A) 15 or 20 A
Frequency (Hz) 60 Hz
BURNER PERFORMANCE
Total Burners 4
(1) Front Left (Single) 18,000 BTU
(2) Front Right (Dual Burner
with simmer function)
15,000 BTU (650 BTU for Simmer)
(3) Rear Left (Single) 12,000 BTU
(4) Rear Right (Single) 12,000 BTU
Tube Broil burner 13,000 BTU
U-shape Bake burner 22,000 BTU
3
21
4
30 INCH PROFESSIONAL GAS RANGE
- HRG3080U / HRG3080ULP
PRODUCT DIMENSIONS
Product Width 30”
Product height (from bottom to top of back splash) 38 3/8”-39 3/8”
Product height (from bottom to top of side panel)
35 9/16” -
36 9/16”
Product depth (from back panel to bullnose) 27 15/16”
Product depth (from back panel to control board) 26 9/16”
Product depth (from back panel to side panel front) 24 13/16”
Depth of control panel (minimum) 1 11/16”
Depth of control panel (bullnose) 3 1/8”
Cast iron cooking grate (W x L) 10 3/4” x 23”
REQUIRED CUTOUT SIZE
30 1/8” x 24 13/16” x 35 9/16” (+1”)
OVEN DIMENSIONS
Oven Cavity Dimension 24”W x 15 1/4”H x 18”D
Oven Rack Dimension 22 3/4” x 15 1/2”
Distance Between Oven
Rack
2 1/8”
