Thule Kit 145355 Bruksanvisning
Les nedenfor 📖 manual på norsk for Thule Kit 145355 (68 sider) i kategorien Takstativ. Denne guiden var nyttig for 15 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere
Side 1/68
Safety
5560060001
Thule roof rack and roof accessories
EN 2
FR 3
ES 5
DE 7
NL 9
PT 11
IT 13
SV 15
DK 17
NO 19
FI 21
IS 22
ET 24
LV 26
LT 28
RU 29
UK 31
PL 34
CS 35
HU 37
RO 39
SK 41
SL 43
BG 44
HR 47
EL 48
TR 50
MT 52
HE 54
AR 55
ZH 57
ZH 58
JA 59
KO 61
TH 62
MS 64
25560060001
EN
A.0 Fitting
A.1 Check with the assembly instructions that all the necessary parts are
present.
A.2 Do not install Thule roof racks on any part of the vehicle that has been
wrapped or modified in any other way.
A.3 Clean the car roof and those parts of the product that come into contact
with the roof before and regularly during use.
A.4 Go through and carefully follow the assembly instructions and the
recommendation list, if one is included. Then fit the unit in the correct
sequence, that is to say 1, 2, 3 and so on.
A.5 If no special fitting positions are given in the assembly instructions, try to
maintain a minimum distance of 700 mm between the load carrier bars.
A.6 When carrying long loads, the distance between the load carrier bars
should not be less than 600 mm.
A.7 Every time the unit is fitted, check that the load carrier is sitting securely
on the roof. Try to push and pull the carrier out of its locked position. Try
also to pull out the tensioning tabs from the roof edge. If you manage to
move any part of the unit, the load carrier must be secured more firmly.
This test should be carried out regularly.
A.8 Some types of sunroof and radio antenna cannot be used when the
carrier is fitted.
A.9 The roof rack is permitted to be assembled on cars with glass roof,
unless otherwise is specified in mounting instruction.
A.10 The manufacturer can not be held responsible for personal damages of
property or loss of fortune caused by incorrect mounting or use of the
product.
A.11 No modifications to the product are permitted.
A.12 Consult with your dealer if you have any questions regarding the
operations and limits of the products. Review all instructions and
warranty information carefully.
A.13 Please consider laws and regulations in the country you intend to use
the product.
A.14 Always make sure that the roof racks or other roof mounted accessories
does not interfere with any kind of sun roof/panorama roof/glass roof on
the car that is openable.
B.0 Loading
B.1 The maximum load specified in the assembly instructions is not to be
exceeded. However, this limit is always subordinate to the maximum
load recommended by the manufacturer of the car itself. It is always the
lower maximum recommended load that applies. Max. roof load = load
carrier weight + any fitted carrier accessories + the weight of the load
itself.
B.2 The load may not significantly exceed the load carrier’s width, and it
should always be spread evenly across the load carrier and with the
3
5560060001
lowest possible centre of gravity.
B.3 When several surfboards are being carried, they should not be placed
beside each other but instead one on top of the other.
B.4 When carrying surfboards and other long items, these shall be secured
both at the front and the rear of the vehicle.
B.5 Skis must be carried with their pointed ends facing the rear of the
vehicle.
B.6 All loose or removable parts of the load such as bike child seats, tyre
pumps, fins and so on should be taken o prior to loading.
B.7 The load should be thoroughly secured. Elastic bungees are not to be
used.
B.8 The load’s security should be checked after a short distance, and
thereafter at suitable intervals. Tighten the load’s securing straps
whenever necessary.
NOTE! Always check that the load is securely attached.
C.0 Driving properties and regulations
C.1 The vehicle’s speed must always be adjusted to the load being carried
and the current driving conditions, such as the road type, road
quality, wind conditions, trac intensity and applicable speed limits,
but must under no circumstances exceed 130 km/h. Applicable speed
limits and other trac regulations must always be observed.
C.2 Drive slowly over speed bumps, maximum speed 10 km/h.
C.3 Note that the vehicle’s total height increases when upright loads are
carried.
C.4 The vehicle’s driving characteristics and braking behaviour change and
its vulnerability to side-winds increases when a load is carried on the
roof.
C.5 Products fitted with a lock should always be locked during transport.
C.6 Adapt your speed to the conditions of the road and load being carried,
check tension of load carrier frequently, especially when travelling on
rough roads.
D.0 Maintenance
D.1 Check and replace worn-out or defective parts.
D.2 The load carrier should always be cleaned and maintained, especially in
the winter.
D.3 When not in use, the product should be removed from the vehicle.
D.4 When the product is removed from the vehicle, all loose parts should be
stored safely.
FR
A.0 Installation
A.1 Vérifier avec les «Instructions de montage» que toutes les pièces sont
présentes dans l’emballage.
