SOFTWARE INSTRUCTIONS

MIXER AMPLIFIER A-5000 SERIES

Thank you for purchasing TOA’s Mixer Amplier.

Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.

(Ver. 1.5.0)

taBle of CoNteNtS

1. a-5000 pC Software oUtlINe

........................................................ 4

1.1. General Description ............................................................................................... 4

1.2. System Requirements ........................................................................................... 4

2. Software SetUp ........................................................................................ 6

2.1. Installing the A-5000 PC Software ........................................................................ 6

2.2. Uninstalling the A-5000 PC Software ................................................................... 8

3. SettINGS flow ............................................................................................. 8

4. StartING tHe Software .................................................................... 9

4.1. Starting from the “Start” Menu .............................................................................. 9

4.2. Starting from the Shortcut Icon ............................................................................. 9

5. MoVING froM tHe INItIal operatIoN SeleCtIoN

SCreeN to tHe MaIN SCreeN ....................................................... 10

6. MaIN SCreeN aND INDIVIDUal VIewS ..................................... 13

6.1. Menu View ........................................................................................................... 14

6.2. Status View ......................................................................................................... 15

6.3. Flow View ............................................................................................................ 17

7. UNIt aND CHaNNel NaMe SettINGS ........................................ 19

8. INpUt aND oUtpUt leVel MoNItorING

(Only possible in online mode.) ................................................................................... 20

9. SIGNal proCeSSING DetaIleD SettINGS .......................... 21

9.1. Basic Function Box Operation in Flow View ........................................................ 21

9.2. Compression Settings ......................................................................................... 22

9.3. FBS Function Setting .......................................................................................... 24

9.4. Mute Settings ...................................................................................................... 27

9.5. Master Volume Settings ...................................................................................... 31

9.6. EQ Settings (Input) .............................................................................................. 32

9.7. EQ Settings (Output) ........................................................................................... 34

9.8. SP EQ Settings (Output) ..................................................................................... 37

10. preSet MeMorY-relateD SettINGS

aND operatIoNS ..................................................................................... 40

10.1. What Is the Preset Memory? ............................................................................. 40

10.2. Preset Memory Name Settings ......................................................................... 40

10.3. Setting the Preset Memory Number To Be Called Up

When Power Is Switched On ............................................................................. 41

10.4. Changing the Preset Memory Number To Be Called Up .................................. 42

10.5. Storing Set Parameters in Preset Memory ....................................................... 43

11. CoMMUNICatIoN SettINGS ............................................................ 44

11.1. Connections between the PC and the Unit ........................................................ 44

11.2. Method to Enable Communications between the PC and the Unit ................... 44

11.3. Connection Settings .......................................................................................... 45

11.4. Communications ................................................................................................ 48

Produkspesifikasjoner

Merke:	Toa
Kategori:	Mottaker
Modell:	A-5006
Innebygd skjerm:	Ja
Vekt:	3600 g
Bredde:	210 mm
Dybde:	375 mm
Høyde:	52.5 mm
LED-indikatorer:	Ja
Wi-Fi:	Nei
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Materiale:	Polystyrene, Steel
Antall kanaler:	1 kanaler
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 / 60 Hz
Produktfarge:	Black, Steel
Kabler inkludert:	AC
Strømforbruk (vanlig bruk):	106 W
Mikrofon, linje-inn-støpsel:	Ja
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Signal-til-støy-forhold (SNR):	70 dB
Total Harmonic Distortion (THD):	1
Lyd-utgang kanaler:	- kanaler
RMS-rangert strøm/utgangseffekt:	60 W
Utjevner/frekvenskorrigerer:	Ja
Frekvensrekkevidde:	50 - 20000 Hz
Linje innganger (RCA):	1
Peak effekt per kanal:	- W
USB port type:	USB Type-B
