INSTALLATION MANUAL
WALL MOUNT SPEAKER 6W (UL) BS-680U
Thank you for purchasing TOA’s Wall Mount Speaker 6W (UL).
Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.
1. SAFETY PRECAUTIONS
• Beforeinstallationoruse,besuretocarefullyread
all the instructions in this section for correct and
safe operation.
• Besuretofollowalltheprecautionaryinstructions
in this section, which contain important warnings
and/orcautionsregardingsafety.
• After reading, keep this manual handy for future
reference.
Safety Symbol and Message Conventions
Safety symbols and messages described below
areusedinthismanualtopreventbodilyinjuryand
propertydamagewhichcouldresultfrommishandling.
Beforeoperatingyourproduct,readthismanualrst
and understand the safety symbols and messages
so you are thoroughly aware of the potential safety
hazards.
Indicatesapotentiallyhazardoussituationwhich,
if mishandled, could result in death or serious
personalinjury.
WARNING
Indicatesapotentiallyhazardoussituationwhich,
ifmishandled,couldresultinmoderateorminor
personalinjury,and/orpropertydamage.
CAUTION
WARNING
When Installing the Unit
• Installtheunitonlyinalocationthatcanstructurally
support the weight of the unit and the mounting
bracket. Doing otherwise may result in the unit
falling down and causing personal injury and/or
propertydamage.
• Donotuseothermethodsthanspeciedtomount
thebracket.Extremeforceisappliedtotheunitand
theunitcouldfalloff,possiblyresultinginpersonal
injuries.
• Tightenallscrewssecurely.Ifanyislooselyxed,
thismaycausethespeakercabinetorbafetofall,
resultinginpersonalinjury.
CAUTION
When Installing the Unit
• Toavoidelectricshocks,besuretoswitchoffthe
amplier'spowerwhenconnectingspeakers.
• Avoid touching the unit’s sharp metal edge to
preventinjury.
When the Unit is in Use
• Donotoperatetheunitfor anextendedperiodof
timewiththesounddistorting.Thisisanindication
of a malfunction, which in turn can cause heat to
generateandresultinare.
• Donotstandorsiton,norhangdownfromtheunit
asthismaycauseittofalldownordrop,resultingin
personalinjuryand/orpropertydamage.
2. FEATURES
• Constructedwithmetalcabinet,thespeakerisideal
foruseinavoicealarmsystem.
• Canbesurface-orush-mountedtothewall.
• Either concealed in-wall wiring or exposed wiring
canbeusedforspeakercableconnection.
• Thespeakerstructureofdirectwall-mountingwith
screws prevents the speaker from falling easily
evenifanoutwardforceisappliedto.
• The input impedance can be easily changed by
changing the tap position of the transformer.
• The built-in 16 cm (6") double cone speaker unit
delivershighqualitysound.
• The push-in type input connector makes cable
connectionseasyandallowsbridgewiring.
• The BS-680U is certied to UL 1480 UUMW and
ULC-S541standards,andforindooruseonly.
For Indoor Use Only
3. INSTALLATION
Notethatthemountingholesexcepthangingholesinthecabinetarecoveredwithtapewhenshippedfromthe
factory.Neverremovethetapeonyourownbeforeinstallation.
Note: Localcodesmayrequireotherinstallationmethods.Checkwithauthorityhavingjurisdictiontodetermine
acceptabilityofthemountingmethodsshownhere.
Step 1. Loosenoneeachofthescrewsonbothsides
ofthespeaker,thenremovethebafe.
You can remove the bafe by loosening the
screw without taking it out.
Step 2. Install the cabinet on the wall.
Thecabinethasknockoutholes(ø20.5mmorø0.81")forcablerouting.
Removethedesiredknockoutholedependingonthewiringmethod,androutecables.
2-1. (Recommended basic Way of Installation)
When installing the cabinet on the wall using
the hanging holes:
(1) Fix 2 supplied screws to the wall leaving
about5mm(0.2")stickingout.
(2)
Removethecabinet'sknockout,thenrunthe
cablesroutedfromthewallthroughthishole.
Inthecaseofexposedwiring,tthesupplied
rubber grommet into the knockout hole.
N
ote: Cut a hole in the grommet's thin
membrane to match the cable size.
(3) Hook the cabinet onto the stick-out screws,
then tighten the screws.
Tip: Owing to its shape, the hanging hole
will prevent the cabinet from falling
easily even if an outward force is
appliedto.
2-2. When installing the cabinet on the wall using
other holes than hanging holes:
(1) Removethe cabinet's knockout, then run the
cablesroutedfromthewallthroughthishole.
Inthecaseofexposedwiring,tthesupplied
rubber grommet into the knockout hole.
Note: Cut a hole in the grommet's thin
membrane to match the cable size.
(2) I
nstall the cabinet on the wall using the mounting
holes [a], [b] or [c] shown at right.
Notes
• When the holes to use are covered with
tape, break through the tape with a ne-
tippedobjecttoexposetheholes.
Leavetheunusedholescoveredwithtape.
Inaddition,cover2hangingholeswiththe
supplied2piecesofspongetape.
•Since no mounting screws are supplied
with the speaker, separately prepare them
appropriatefortheconstructionofwalland
its thickness.
Loosen
Tighten
Baffle
Cabinet
Note: To remove, pull in the arrow
direction after
loosening screws.
Cabinet
83.5 mm (3.29")
About 5 mm (0.2")
Hanging hole
Wall
Tapping screw 4 x 16
(accessory)
Knockout hole (ø20.5mm or ø0.81")
Cabinet
Knockout hole: ø20.5 (0.81)
36 (1.42)
36
(1.42)
60 (2.36)
60 (2.36)
115 (4.53)
4-3.5 x 6.5 (0.14 x 0.26) [a]
2-5.5 x 10
(0.22 x 0.39) [c]
4-ø4.5 (0.18) [b]
Unit: mm (in)
(View at factory-preset) (View with tape removed)
Holes are covered with tape.
