OPERATING INSTRUCTIONS

H-2

H-2WP

SPEAKER SYSTEM

Please follow the instructions in this manual to obtain the optimum results from this unit.

We also recommend that you keep this manual handy for future reference.

TOA Corporation

TABLE OF CONTENTS

1. SAFETY PRECAUTIONS

2. GENERAL DESCRIPTION

3. FEATURES

4. HANDLING PRECAUTIONS

5. NOMENCLATURE

6. INSTALLATION

6.1. Direct Wall/Ceiling Mounting

6.2. Mounting the Speaker using an Electrical Box

6.3. Mounting the Speaker using Supporting Rails

6.4. Removing the Front Grille

7. OUTDOOR USE (H-2WP ONLY)

7.1. Waterproofing

7.2. Speaker Mounting Angle

8. REPAINTING THE GRILLE AND TRIM PIECE

9. PROTECTION CIRCUITRY INFORMATION

10. EQUALIZATION

11. SPECIFICATIONS

Accessories

1. SAFETY PRECAUTIONS

• Be sure to read the instructions in this section carefully before use.

• Make sure to observe the instructions in this manual as the conventions of safety symbols and messages

regarded as very important precautions are included.

• We also recommend you keep this instruction manual handy for future reference.

Safety Symbol and Message Conventions

Safety symbols and messages described below are used in this manual to prevent bodily injury and property

damage which could result from mishandling. Before operating your product, read this manual first so you are

thoroughly aware of the potential safety hazards as well as understand the safety symbols and messages.

Indicates a potentially hazardous situation which, if mishandled,

could result in death or serious personal injury.

Indicates a potentially hazardous situation which, if mishandled,

could result in moderate or minor personal injury, and/or property

damage.

WARNING

CAUTION

WARNING

CAUTION

When Installing the Unit

• Install the unit only in a location that can

structurally support the weight of the unit and the

mounting bracket. Doing otherwise may result in

the speaker falling down and causing personal

injury and/or property damage.

When the Unit is in Use

• Do not operate the speaker for an extended period

of time with the sound distorting. This is an

indication of a malfunction, which in turn can cause

heat to generate and result in a fire.

When the Unit is in Use

• Should the following irregularity be found during

use, immediately stop operating the unit and

contact your nearest TOA dealer. Make no further

attempt to operate the unit in this condition as this

may cause fire or electric shock.

• If you detect smoke or a strange smell coming

from the unit.

• If water or any metallic object gets into the unit

• If it is malfunctioning (no tone sounds.)

2. GENERAL DESCRIPTION

TOA's H-2 and H-2WP are small, dome-shaped 2-way speakers featuring high sound quality. The H-2 is

designed for indoor use, and the H-2WP is designed for outdoor use.

Note: Protect the H-2WP from rain when installing. (Refer to P. 10 "7.1. Waterproofing".)

3. FEATURES

• The speaker's smooth curved surface allows it to blend in with the interiors of most modern buildings.

• The speaker's small (10 cm) woofer features a magnetic circuit (employing a neodymium magnet) that

ensures powerful low-frequency sound reproduction.

• The one-inch balanced dome tweeter features ferro-fluid to ensure superb transient response characteristics

for clear, high frequency sound output and high power-handling capabilities.

• The speaker's built-in, crossover network circuitry features sharp cut-off characteristics that realize uniform

energy radiation while suppressing unwanted input signals to the woofer or tweeter.

• The speaker is designed with an emphasis on installation ease and safety, as well as easier conduit wiring

when an electrical box is installed.

• The speaker's round mounting base frame allows the speaker to be installed at any mounting angle.

Note: When mounting the H-2WP speaker to a wall, to ensure its watertightness it must not be tilted any

more than 45 degrees up from its downward-facing position.

• A built-in matching transformer permits the speaker to be used for both high- and low-impedance

applications. For low-impedance applications, either the 4 or 16 terminal can be selected. Impedance

can be easily changed from outside the unit.

• Detachable screw terminals facilitate connection. Dual positive and negative terminals also facilitate bridge

connections.

• The H-2's enclosure and front grille are made of fire-resistant ABS (UL Standard 94: V-0 Grade).

• The structure of the speaker's front grille is specially designed for ease of refinishing and repainting.

4. HANDLING PRECAUTIONS

• Avoid using the speaker on the beach because the speaker's life can be greatly shortened by sea breezes.

• The speakers are not magnetically shielded. Install them as far away as possible from television sets or

computer's CRTs to avoid degradation in picture quality.

Produkspesifikasjoner

Merke:	Toa
Kategori:	Høyttaler
Modell:	H-2
Vekt:	2100 g
Bredde:	268 mm
Dybde:	268 mm
Høyde:	111 mm
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Anbefalt bruk:	Universell
Impedans:	16 Ω
Høyttalerplassering:	Tak-Monterbart
Peak Music Power Output (PMPO):	120 W
Produktfarge:	Hvit
Kroppsmateriale:	Resin, Steel
Lyd-utgang kanaler:	- kanaler
RMS-rangert strøm/utgangseffekt:	40 W
Antall drivere:	1
Høyttaler type:	2-veis
Frekvensrekkevidde:	100 - 20000 Hz
Sensitivitet/følsomhet:	88 dB
Ledningskontakt:	Ja
Driverdiameter:	100 mm
