OPERATING INSTRUCTIONS

SPEAKER SYSTEM H-3

H-3WP

Please follow the instructions in this manual to obtain optimum results from this unit.

We also recommend that you keep this manual handy for future reference.

TABLE OF CONTENTS

1. SAFETY PRECAUTIONS .............................................................................. 2

2. GENERAL DESCRIPTION ............................................................................ 3

3. FEATURES ......................................................................................................... 3

4. NOMENCLATURE AND DIMENSIONS ..................................................... 4

5. INSTALLATION

5.1. Contents............................................................................................................ 5

5.2. Installation Example (Using Two-Gang Electrical Box) .................................... 5

5.3. Installation Procedures .................................................................................... 6

6. REMOVING THE FRONT GRILLE .............................................................. 9

7. OUTDOOR USE (H-3WP ONLY)

7.1. Installation Precautions ................................................................................... 10

7.2. Waterproofing the Base Frame ....................................................................... 10

8. REPAINTING THE FRONT GRILLE .......................................................... 10

9. PROTECTION CIRCUITRY INFORMATION ........................................... 11

10. EQUALIZATION ............................................................................................... 11

11. SPECIFICATIONS ........................................................................................... 12

Accessories ............................................................................................................ 12

1. SAFETY PRECAUTIONS

• Before installation or use, be sure to carefully read all the instructions in this section for correct and safe

operation.

• Be sure to follow all the precautionary instructions in this section, which contain important warnings and/or

cautions regarding safety.

• After reading, keep this manual handy for future reference.

Safety Symbol and Message Conventions

Safety symbols and messages described below are used in this manual to prevent bodily injury and property

damage which could result from mishandling. Before operating your product, read this manual first and

understand the safety symbols and messages so you are thoroughly aware of the potential safety hazards.

• Install the unit only in a location that can

structurally support the weight of the unit and the

mounting bracket. Doing otherwise may result in

the unit falling down and causing personal injury

and/or property damage.

• Use nuts and bolts that are appropriate for the

ceiling's or wall's material and structure. Tighten

each nut and bolt securely. Ensure that the bracket

has no loose joints after installation to prevent

accidents that could result in personal injury.

• (Applicable to H-3 only)

Since the unit is designed for in-door use, do not

install it outdoors. If installed outdoors, the aging of

parts causes the unit to fall off, resulting in

personal injury. Also, when it gets wet with rain,

there is a danger of electric shock.

• Do not apply lubricant and rust inhibitor. If it

contacts resin or rubber parts, they could

deteriorate and cause the unit to fall, possibly

resulting in personal injury.

• (Applicable to H-3WP only)

Avoid installing the unit in locations close to the

seashore, or in indoor swimming pools or

bathrooms. In such locations, the bracket may be

vulnerable to corrosion, eventually allowing the

unit to fall resulting in personal injury.

• Avoid touching the unit's sharp metal edge to

prevent injury.

• Do not operate the unit for an extended period of

time with the sound distorting. This is an indication

of a malfunction, which in turn can cause heat to

generate and result in fire.

WARNING

Indicates a potentially hazardous situation which, if mishandled, could

result in death or serious personal injury.

Indicates a potentially hazardous situation which, if mishandled, could

result in moderate or minor personal injury, and/or property damage.

WARNING

CAUTION

Produkspesifikasjoner

Merke:	Toa
Kategori:	Høyttaler
Modell:	H-3
Vekt:	3300 g
Bredde:	295 mm
Dybde:	129 mm
Høyde:	318 mm
Bluetooth:	Nei
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Antall per pakke:	1 stykker
Anbefalt bruk:	Universell
Høyttalerplassering:	Vegg.monterbar
Basshøyttaler:	Ja
Diskanthøyttaler:	Ja
Produktfarge:	Hvit
Kroppsmateriale:	Akrylonitril-butadien-styren (ABS)
Lyd-utgang kanaler:	- kanaler
RMS-rangert strøm/utgangseffekt:	30 W
Monteringsbeslag inkludert:	Ja
Antall drivere:	3
Høyttaler type:	2-veis
Frekvensrekkevidde:	100 - 20000 Hz
Basshøyttalerens diameter:	100 mm
Diskant diameter:	25 mm
Sensitivitet/følsomhet:	89 dB
Diskanthøyttalerens diameter:	1 "
Basshøyttalerens diameter (imperisk):	4 "
Overgangsfrekvens:	4000 Hz
Antall drivere til diskant:	1
Antall basshøyttalerdrivere:	2
Magnettype:	Neodym
