Side 1/2

• Install the unit only in a location that can structurally

support the weight of the unit and the mounting bracket.

Doing otherwise may result in the unit falling down and

causing personal injury and/or property damage.

• Do not use other methods than specied to mount the

bracket. Extreme force is applied to the unit and the unit

could fall off, possibly resulting in personal injuries.

2. GENERAL DESCRIPTION

Integrated with a speaker unit and panel, the PC-1860 and PC-2360 Ceiling Mount Speakers are of all metallic construction

and ideal for use in a voice alarm system.

They feature spring clamp mechanism for easy speaker mounting to the ceiling.

The input impedance can be easily changed by changing the tap position of the transformer.

The push-in type input terminal block makes cable connections easy and allows bridge wiring.

INSTALLATION MANUAL

CEILING MOUNT SPEAKER

ThankyouforpurchasingTOA’sCeilingMountSpeaker.

Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.

PC-1860

PC-2360

1. SAFETY PRECAUTIONS

• Before installation or use, be sure to carefully read all the instructions in this section for correct and safe operation.

• Be sure to follow all the precautionary instructions in this section, which contain important warnings and/or

cautions regarding safety.

• After reading, keep this manual handy for future reference.

Indicates a potentially hazardous situation which,

if mishandled, could result in death or serious

personal injury.

WARNING

Indicates a potentially hazardous situation which,

if mishandled, could result in moderate or minor

personal injury, and/or property damage.

CAUTION

• Avoid touching the unit’s sharp metal edge to prevent

injury.

• To avoid electric shocks, be sure to switch off the

amplier’spowerwhenconnectingspeakers.

• Do not operate the unit for an extended period of time

with the sound distorting. This is an indication of a

malfunction, which in turn can cause heat to generate

andresultinare.

3. SPECIFICATIONS

Model No. PC-1860 PC-2360

Rated Input 6 W (100 V line), 3 W (70 V line)

Rated Impedance 100Vline: 1.7kΩ(6W),3.3kΩ(3W),6.7kΩ(1.5W),13kΩ(0.8W)

70Vline: 1.7kΩ(3W),3.3kΩ(1.5W),6.7kΩ(0.8W),13kΩ(0.4W)

Sensitivity 94dB(1W,1m)(500Hz–5kHz,pinknoise)

Frequency Response 80Hz–20kHz(peak–20dB) 60Hz–20kHz(peak–20dB)

Speaker Component 12cm(5")cone-type 16cm(6")cone-type

Operating Temperature –10to+50°C(14to122°F)

DimensionsforFixingHole Mountinghole: ø150±3mm(ø5.91"±0.12")

Ceilingthickness: 5–25mm(0.2"–0.98")

Mountinghole: ø200±3mm(ø7.87"±0.12")

Ceilingthickness: 5–25mm(0.2"–0.98")

Speaker Mounting Method Spring clamp

Applicable Cable Solidwire:0.5–3mm²(AWG20–12)

Connection Push wire connection (Bridging terminal-2 branch type)

Finish Frame: Steel plate, white (RAL 9016 equivalent), paint

Grille: Steelnet,white(RAL9016equivalent),paint

Dimensions ø180x70(d)mm(ø7.09"x2.76") ø230x76(d)mm(ø9.06"x2.99")

Weight 560g(1.23lb) 740g(1.63lb)

Accessory Paper pattern ................................... 1

Note: Thedesignandspecicationsaresubjecttochangewithoutnoticeforimprovement.

Produkspesifikasjoner

Merke:	Toa
Kategori:	Høyttaler
Modell:	PC-2360
Vekt:	740 g
Bredde:	230 mm
Dybde:	230 mm
Høyde:	76 mm
Bluetooth:	Nei
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Antall per pakke:	1 stykker
Anbefalt bruk:	Intercom-system
Høyttalerplassering:	Tak-Monterbart
Forsterker:	Nei
Produktfarge:	Black, White
Driftstemperatur (T-T):	-10 - 50 °C
Kroppsmateriale:	Stål
Lyd-utgang kanaler:	- kanaler
RMS-rangert strøm/utgangseffekt:	6 W
Frekvensrekkevidde:	60 - 20000 Hz
Sensitivitet/følsomhet:	94 dB
Driverdiameter:	160 mm
