Operator’s Manual
Manuel de L’Utilisateur
Manual del Operador
FORM NO. 3319–896 REV A
Air Rake
Rake and Vac
Superblower/vac
Blowers and Blower/Vacuums
Model No. 51539, 51549, 51587 — 89000001 & Up
Air Rake
Rake and Vac
Souffleur-aspirateur
SuperBlower/vac
Souffleur et souffleur-aspirateurs
Modèle No. 51539, 51549, 51587 — 89000001 et suivants
Air Rake
Rake and Vac
Aspiradora Supersopladora
Sopladoras y sopladora-aspiradoras
Modelos N. 51539, 51549, 51587 — 89000001 y siguientes
English
1
EThe Toro Company – 1997, Rev. 1998
All Rights Reserved
Printed in USA
Safety
IMPORTANT SAFETY
INSTRUCTIONS
When using an electrical appliance, basic precautions should
always be followed, including the following:
Read All Instructions Before Using
This Appliance
WARNING—To reduce the risk of fire, electric shock
or injury, follow these safety instructions.
To assure maximum safety, best performance, and to gain
knowledge of the appliance, it is essential that you or any other
operator of the appliance read and understand the contents of
this manual before operating the appliance. Pay particular
attention to the safety alert symbol
which means
CAUTION, WARNING OR DANGER — “personal safety
instruction.” Read and understand the instruction because it
has to do with safety. FAILURE TO COMPLY WITH
INSTRUCTION MAY RESULT IN PERSONAL INJURY,
RISK OF FIRE OR ELECTRICAL SHOCK.
• Do not leave the appliance when plugged in. Unplug from
outlet when not in use and before servicing.
• Do not allow appliance to be used as a toy. Do not use near
children. Do not let children use the appliance.
• Use only as described in this manual. Use only manufacturer’s
recommended attachments.
• Do not use with damaged cord or plug. If appliance is not
working as it should, has been dropped, damaged, left
outdoors, or dropped into water, return it to a service dealer.
• Do not pull or carry by cord, use cord as a handle, close a door
on cord, or pull cord around sharp edges or corners. Do not run
appliance over cord. Keep cord away from heated surfaces.
• Do not unplug by pulling on cord. To unplug, grasp the plug,
not the cord.
• Do not handle plug or appliance with wet hands.
• Do not put any object into openings. Do not use with any
opening blocked; keep free of dust, lint, hair, and anything that
may reduce air flow.
• DRESS PROPERLY.
Do not wear loose clothing or jewelry.
Pin up long hair. Be aware of the position of the blower and the
air inlets during operation. Loose clothing, jewelry and hair
can be drawn into the inlets (Fig. 1) and may result in personal
injury. Always wear substantial footwear and long pants.
• Turn off all controls before unplugging.
• Use extra care when cleaning on stairs.
• Do not use to vacuum up flammable or combustible liquids,
such as gasoline, or use in areas where they may be present.
• This appliance is provided with double insulation. Use only
identical replacement parts. See instructions for Servicing of
Double-Insulated Appliances.”
• Do not vacuum anything that is burning or smoking, such as
cigarettes, matches, or hot ashes.
• Do not use without vac bag or proper attachments in place.
• To reduce the risk of electric shock, this appliance has a
polarized plug (one blade is wider than the other) (Fig. 13).
This plug will fit in a polarized outlet only one way. If the plug
does not fit fully in the outlet, reverse the plug. If it still does
not fit, consult a qualified electrician to install the proper outlet.
Do not change the plug in any way.
EXTENSION CORD CHART
If length of extension cord is less
than or equal to:
100 ft. 150 ft.
Assure wire size gage (A.W.G.) in
cord is:
16 14
Note: Use of an extension cord over 150 feet is not recommended.
SAVE THESE
INSTRUCTIONS
Safety and Instruction Decals
Safety and instruction decals are easily visible to the operator and are located near any area of potential
danger. Replace any decal that is damaged or lost.
ON BLOWER HOUSING
ON REAR OF BLOWER HOUSING
(Part No. 95-5106)
2
Assembly
Note: Refer to Figures section at the back of the manual.
Note: Always turn off unit and unplug from electrical outlet
before adding or switching attachments.
Blower
1. Slide tube onto blower outlet until tabs on tube snap into latch
(Fig. 2).
Note: Inlet cover must be securely locked into position,
activating interlock switch, before blower will operate. Pointer
on cover will be aligned with pointer on housing when cover is
correctly locked in position (Fig. 3).
Note: Blower is shipped with inlet cover installed.
Note: Blower tube must be attached to housing when operating in
the blower mode.
Vacuum
(Model 51541 Vacuum Bag Kit optional for Model 51539.)
1. Grasp inlet cover and rotate it counterclockwise to remove
(Fig. 4).
POTENTIAL HAZARD
• Motor impeller rotates for a few seconds after blower
is turned off.
WHAT CAN HAPPEN
• Rotating impeller can cut or injure fingers.
HOW TO AVOID THE HAZARD
• Never remove inlet cover when motor is operating or
when unit is plugged in.
2. Assemble vacuum tubes by pressing tubes together (Fig. 5).
Line up arrows on outside of tubes to ensure correct assembly.
3. Hold vacuum tubes vertically and place blower inlet over top
of tube (Fig. 6). Tubes will only fit one way in blower inlet.
4. Rotate unit clockwise until pointer on vacuum tube aligns with
pointer on housing (Fig. 7, 8 & 9).
Note: Vacuum tube and housing pointers must be aligned at locked
position before blower will operate.
5. Slide bag collar into bag opening until bag collar flange is past
the Velcro strap (Fig. 10). Line up bag seam with tab on
collar. Tighten Velcro strap to secure bag to collar (Fig. 10).
Close bag zipper. Bag should appear as shown in Figure 11
when correctly assembled.
Note: Attaching the bag to the collar is a onetime
assembly.
6. Slide bag collar onto blower housing outlet until tabs on bag
collar snap into latch (Fig. 12).
Before Starting
Securing Extension Cord
Use only a UL listed (CSA certified in Canada) extension cord
recommended for outdoor use. Refer to Extension Cord Chart on
page 1.
1. Secure extension cord in cord lock (Fig. 14 & 15).
2. Make sure the extension cord is fully seated on inlet plug.
POTENTIAL HAZARD
• The extension cord may not be fully seated on inlet
plug.
WHAT CAN HAPPEN
• A loosely connected extension cord could lead to
overheating and cause a fire.
HOW TO AVOID THE HAZARD
• Make sure the extension cord is fully seated on inlet
plug and ALWAYS USE THE CORD LOCK
FEATURE to ensure that cord remains secured during
operation (Fig. 14 & 15).
Note: Do not unplug extension cord by pulling on cord. To
unplug, grasp the plug, not the cord.
Operation
This appliance is intended for household use only.
POTENTIAL HAZARD
• Debris can be thrown by unit in operator’s or
bystander’s direction.
WHAT CAN HAPPEN
• Flying debris can cause serious personal injury to
operator or bystanders.
HOW TO AVOID THE HAZARD
• Never blow hard objects such as nails, bolts and rocks.
• Always wear safety goggles or other suitable eye
protection, long pants and shoes while operating unit.
• Never operate unit near bystanders or pets.
• Use extra care when cleaning debris from stairs or
tight areas.
Starting/Stopping (Fig. 16)
1. To turn unit on, move switch to the ‘|’ position.
2. To turn unit off, move switch to the ‘O’ position. An arrow and
the word “OFF” on the top of the switch indicate which
direction to move the switch.
