Side 1/72

25.4cc Gas Power Head

Item No. 51948—319000001 & Up

English (EN), French (FR), and Spanish (ES)

WARNING:

To reduce the risk of injury, the user must read and understand the operator’s manual. Save this manual.

Form No. 3427-358 Rev. A

NOTICE

Do not use E15, E20 or E85 fuel in this

product. It is a violation of federal law

and will damage the unit and void your

warranty. Only use unleaded gasoline

containing up to 10% ethanol.

If you have questions concerning

your trimmer, please call us

at 866-574-9242 (US) or

866-574-9243 (Canada).

READ THIS INFORMATION

Before you use your new trimmer, read the following helpful hints to

get you started.

Fueling

WARNING:

Gasoline and its vapors are highly ammable and

explosive. To prevent serious personal injury and

property damage, handle it with care. Keep away

from ignition sources and open ames, handle

outdoors only, do not smoke and wipe up spills

immediately.

1. Obtain a clean container that is approved for use with gasoline.

2. Mix all of the 2-cycle lubricant provided with 1 US gallon of 87-octane, unleaded gasoline (50:1).

3. Fill the trimmer’s gas tank carefully.

Cold Starting vs. Warm Starting

When you restart the trimmer and you are not sure whether the engine is still warm, set the choke

lever to RUN and pull the starter cord. If the engine does not start within 5 pulls, refer to “To Start a

Cold Engine” later in this manual.

Flooded Engine

Will the engine start? If not, it may be ooded. Relax, this is easy to correct. Set the choke lever to

RUN. Squeeze the trigger and pull the starter cord quickly for 10 to 12 pulls.

If the engine does not start, refer to “Troubleshooting” later in this manual or call toll-free at

866-574-9242 (US) or 866-574-9243 (Canada).

CALL

866-574-9242 (US) or

866-574-9243 (Canada)

For questions concerning your trimmers,

call us toll free at 866-574-9242 (US) or

866-574-9243 (Canada).

STOP

Table of Contents

Introduction ................................................................................................................................................................................... 4

General Safety Rules ................................................................................................................................................................. 5-6

Specic Safety Rules ....................................................................................................................................................................6

Symbols.........................................................................................................................................................................................7

Product Labels ..............................................................................................................................................................................8

Features .........................................................................................................................................................................................9

Product Specications ...........................................................................................................................................................9

Assembly................................................................................................................................................................................10-11

Unpacking ............................................................................................................................................................................ 10

Packing List .........................................................................................................................................................................10

Connecting the Attachment to the Upper Shaft ...................................................................................................................10

Removing the Attachment from the Upper Shaft ................................................................................................................11

Attaching the Front Handle .................................................................................................................................................11

Operation ............................................................................................................................................................................... 12-14

Applications .........................................................................................................................................................................12

Fueling and Refueling the Power Head ...............................................................................................................................12

Oxygenated Fuels ...............................................................................................................................................................13

Starting the Product .............................................................................................................................................................13

Stopping the Product ............................................................................................................................................................13

Operating the Power Head ................................................................................................................................................... 14

Blade Thrust ........................................................................................................................................................................14

Maintenance .......................................................................................................................................................................... 15-19

General Maintenance ...........................................................................................................................................................15

Cleaning the Product ............................................................................................................................................................15

Servicing the Product ........................................................................................................................................................... 15

Checking the Fuel Cap, Tank, and Lines .............................................................................................................................15

Cleaning the Air Filter .........................................................................................................................................................15

Replacing the Spark Arrestor ...............................................................................................................................................16

Replacing the Spark Plug .....................................................................................................................................................17

Idle Speed Adjustment .........................................................................................................................................................17

Storing the Product ..............................................................................................................................................................18

Transporting the Product .....................................................................................................................................................18

High Altitude Engine Operation ..........................................................................................................................................18

Maintenance Schedule .........................................................................................................................................................19

Troubleshooting ..........................................................................................................................................................................20

Warranty ...................................................................................................................................................................................... 21

California Proposition 65 Warning Information .........................................................................................................................22

Table of Contents
