Side 1/36

UPS Systems

Models:

AVRT450U, BC600TU, AVRT65OU, SMART550USB2

(Series Numbers AG-0300, AG-0303, AG-888E, AG-0395)

Owner’s Manual

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

Español 12 • Français 23

WARRANTY REGISTRATION

automatically entered to win an ISOBAR

surge protector in our monthly drawing!

tripplite.com/warranty

20-08-197-933853.indb 120-08-197-933853.indb 1 9/4/2020 10:06:52 AM9/4/2020 10:06:52 AM

SAVE THESE INSTRUCTIONS

This manual contains instructions and warnings that should be followed during the

installation, operation and storage of this product. Failure to heed these warnings

may affect the warranty.

UPS Location Warnings

• Install your UPS indoors, away from excess moisture or heat, conductive contaminants,

dust or direct sunlight.

• For best performance, keep the indoor temperature between 32º F and 104º F

(0º C and 40º C).

• Leave adequate space around all sides of the UPS for proper ventilation.

• Only set the UPS upright on a sturdy ﬂat surface. Do not block fans or ventilation holes, as

this will seriously inhibit the unit's internal cooling and cause product damage not covered

under warranty.

UPS Connection Warnings

• Connect your UPS directly to a properly-grounded AC power outlet. Do not plug the UPS

into itself; this will damage the UPS.

• Do not modify the UPS plug, and do not use an adapter that would eliminate the UPS

ground connection.

• Do not use extension cords to connect the UPS to an AC outlet.

• If the UPS receives power from a motor-powered AC generator, the generator must provide

clean, ﬁltered, computer-grade output.

• The mains socket outlet that supplies the UPS should be easily accessible and located

near the UPS.

Equipment Connection Warnings

Install in accordance with National Electrical Code standards ANSI/NFPA

70 and Canadian Electrical Code, Part I, C22.1.

Short circuit backup protection and overcurrent protection is provided by

the building installation.

To reduce the risk of ﬁre, connect only to a circuit provided branch circuit

overcurrent protection in accordance with the National Electrical Code,

ANSI/NFPA 70 and the Canadian Electrical Code, Part I, C22.1. The plug

on the power supply cord is intended to serve as the disconnect device.

Be sure that the socket-outlet is installed near the equipment and is

made easily accessible.

Important Safety Instructions

20-08-197-933853.indb 220-08-197-933853.indb 2 9/4/2020 10:06:52 AM9/4/2020 10:06:52 AM

Important Safety Instructions

• Use of this equipment in life support applications where failure of this equipment can

reasonably be expected to cause the failure of the life support equipment or to signiﬁcantly

affect its safety or effectiveness is not recommended.

• Do not connect surge protectors or extension cords to the output of your UPS. This might

damage the UPS and may affect the surge protector and UPS warranties.

• Connect the UPS to an outlet that is adequately protected against excess currents, short

circuits and earth faults as part of the building installation.

Battery Warnings

• Batteries can present a risk of electrical shock and burn from high short-circuit current.

Observe proper precautions. There are no user-serviceable parts inside the UPS. Do not

open the UPS except to perform battery replacement. Do not open batteries. Do not

short or bridge the battery terminals with any object. Do not dispose of batteries in a ﬁre.

The batteries may explode. Released material is harmful to the skin and eyes. It may be

toxic. Unplug and turn off the UPS before performing battery replacement. Use tools with

insulated handles. Battery replacement should be performed only by authorized service

personnel using the same number and type of batteries (sealed lead-acid). Do not dispose

of the batteries in a ﬁre. Tripp Lite offers a complete line of UPS System Replacement

Battery Cartridges (R.B.C.).Visit Tripp Lite on the Web at tripplite.com/products/battery-

ﬁnder to locate the speciﬁc replacement battery for your UPS.

CAUTION: A battery can present a risk of electrical shock and high short-

circuit current. Contact with any part of a grounded battery can result in

electrical shock. The following precautions should be observed when working

on batteries:

• Remove watches, rings or other metal objects.

• Use tools with insulated handles.

• Wear rubber gloves.

• Do not lay tools or metal parts on top of batteries.

• Unplug the UPS from the AC mains receptacle. Disconnect all cables, including

the equipment plugged into the UPS.

UPS and Battery Recycling

Tripp Lite products use sealed lead-acid batteries, which are highly recyclable.

Call Tripp Lite at 1.773.869.1234 or visit tripplite.com/support/recycling-program

for more information on recycling the batteries or any other Tripp Lite product.

Please refer to local codes for disposal requirements.

20-08-197-933853.indb 320-08-197-933853.indb 3 9/4/2020 10:06:52 AM9/4/2020 10:06:52 AM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	uforstyrret strømtilførsel (UPS)
Modell:	AVRT450U
Vekt:	4810 g
Bredde:	121.9 mm
Dybde:	345.4 mm
Høyde:	160 mm
LED-indikatorer:	Ja
Bruksanvisning:	Ja
USB-port:	Ja
Opprinnelsesland:	Vietnam
Pakkevekt:	5310 g
Utgangseffekt:	360 W
Utgangsspenning (maks.):	120 V
UPS topologi:	Linje-Interactive
Antall inngangsfaser:	1
Hørbare alarmmoduser:	Fault, Low battery alarm, Overload alarm
Bølgeform:	Sinus
Overføringstid (linjemodus til batterimodus):	6 ms
Inngangsspenning (maks.):	120 V
Kabellengde:	1.5 m
Produktfarge:	Sort
Pakkedybde:	414 mm
Pakkehøyde:	248.9 mm
Pakkebredde:	182.9 mm
Kabler inkludert:	USB-kabel
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-15 - 45 °C
Bærekraftsertifikater:	RoHS
Formfaktor:	Tower
Inngangsfrekvens:	50/60 Hz
Kroppsmateriale:	Akrylonitril-butadien-styren (ABS)
Driftshøyde:	0 - 3000 m
Relativ luftfuktighet under drift (H-H):	0 - 95
Oppdateringsresponstid:	0 ms
Antall AC outlets:	6 AC-utganger
Masterkassens (ytterkassens) bruttovekt:	5310 g
Masterkassens (ytterkassens) lengde:	414 mm
Produkter per masterkasse (ytterkasse):	1 stykker
Masterkassens (ytterkassens) bredde:	182.9 mm
Masterkassens (ytterkassens) høyde:	248.9 mm
Hørbare alarmer:	Ja
Strøm (maks.):	5 A
AC-utgangstyper:	NEMA 5-15R
Strømuttak:	NEMA 5-15P
Strømfaktor:	0.8
Strømstøt energivurdering:	316 J
EMI/RFI-lydfiltrering:	Ja
Output strømkapasitet (VA):	0.45 kVA
Inngangsspenning (min.):	110 V
Utgangsspenning (min.):	110 V
Normal backuptid ved halv belastning:	5.7 min
Kald oppstart:	Ja
Automatic Voltage Regulation (AVR):	Ja
Batteriladetid (90 %):	8 timer
