Side 1/18

Owner’s Manual

AVRX550U & AVRX750U

UPS Systems

Not suitable for mobile applications.

1111 W. 35th Street • Chicago, IL 60609 USA

www.tripplite.com/support

Important Saftey Instructions 2

Features 3

Installation 4

Optional Installation 5

Troubleshooting 5

Storage & Service 6

Español 7

Français 13

Important Safety Instructions

SAVE THESE INSTRUCTIONS—This manual contains instructions and warnings that should be followed during the installation, operation and

storage of Tripp Lite UPS Systems. Failure to heed these warnings may affect your warranty.

UPS Location Warnings

• Install UPS indoors, away from excess moisture or heat, conductive contaminants, dust or direct sunlight.

• Keep the indoor temperature between 32º F and 104º F (0º C and 40º C).

• Leave adequate space around all sides of UPS for proper ventilation.

UPS Connection Warnings

• Connect UPS directly to a properly grounded AC power outlet. Do not plug UPS into itself; this will damage the UPS.

• Do not modify the UPS’s plug, and do not use an adapter that would eliminate the UPS’s ground connection.

• Do not use extension cords to connect UPS to an AC outlet.

• If UPS receives power from a motor-powered AC generator, the generator must provide clean, ltered, computer-grade output.

• The mains socket outlet that supplies the UPS should be installed near the UPS and should be easily accessible.

Equipment Connection Warnings

• Use of this equipment in life support applications where failure of this equipment can reasonably be expected to cause the failure of the life support

equipment or to signicantly affect its safety or effectiveness is not recommended. Do not use this equipment in the presence of a ammable

anesthetic mixture with air, oxygen or nitrous oxide.

• Do not connect surge suppressors or extension cords to the output of UPS. This might damage the UPS and may affect the surge suppressor and

UPS warranties.

Battery Warnings

• Batteries can present a risk of electrical shock and burn from high short-circuit current. Observe proper precautions. Do not dispose of the batteries

in a re. Do not open the UPS or batteries. Do not short or bridge the battery terminals with any object. Unplug and turn off the UPS before

performing battery replacement. Use tools with insulated handles. There are no user-serviceable parts inside the UPS. Battery replacement should

be performed only by authorized service personnel using the same number and type of batteries (Sealed Lead-Acid). The batteries are recyclable.

Refer to your local codes for disposal requirements or visit www.tripplite.com/UPSbatteryrecycling for recycling information. Tripp Lite offers a

complete line of UPS System Replacement Battery Cartridges (R.B.C.).Visit Tripp Lite on the Web at

www.tripplite.com/support/battery/index.cfm to locate the specic replacement battery for your UPS.

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	uforstyrret strømtilførsel (UPS)
Modell:	AVRX550U
Vekt:	3860 g
Bredde:	279.4 mm
Dybde:	147.3 mm
Høyde:	88.9 mm
LED-indikatorer:	Ja
Opprinnelsesland:	China
Pakkevekt:	4630 g
Antall USB 2.0-porter:	1
Sertifisering:	CE, GOST, SASO, FCC, EN62040
Utgangseffekt:	300 W
Forhåndsinstallert programvare:	PowerAlert UPS
Vekt (imperial):	10.4 Ibs
Utgangsspenning (maks.):	240 V
Effektivitet:	95
UPS topologi:	Linje-Interactive
Antall inngangsfaser:	1
Bølgeform:	Sinus
Inngangsspenning (maks.):	282 V
Kabellengde:	0.2 m
Produktfarge:	Sort
Pakkedybde:	223.5 mm
Pakkehøyde:	116.8 mm
Pakkebredde:	340.4 mm
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-15 - 50 °C
Bærekraftsertifikater:	RoHS
Formfaktor:	Tower
Inngangsfrekvens:	50/60 Hz
Kroppsmateriale:	Akrylonitril-butadien-styren (ABS)
Overspenningsvern:	Ja
Strømbeskyttelsesfunksjoner:	Over voltage, Under voltage
Rack-kapasitet:	2U
Relativ luftfuktighet under drift (H-H):	0 - 95
Videoopptaksgrensesnitt:	USB
Oppdateringsresponstid:	4 ms
Antall AC outlets:	6 AC-utganger
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332123470
Masterkassens (ytterkassens) bruttovekt:	18730 g
Masterkassens (ytterkassens) lengde:	342.9 mm
Produkter per masterkasse (ytterkasse):	4 stykker
Masterkassens (ytterkassens) bredde:	457.2 mm
Masterkassens (ytterkassens) høyde:	266.7 mm
Kompatibel med Mac:	Ja
Hørbare alarmer:	Ja
Strøm (maks.):	10 A
AC-utgangstyper:	C13 kopling
Strømuttak:	C14 kopling
Nominell innputspenning:	230 V
Nominell outputspenning:	230 V
Strømstøt energivurdering:	320 J
EMI/RFI-lydfiltrering:	Ja
Output strømkapasitet (VA):	0.55 kVA
Inngangsspenning (min.):	159 V
Utgangsspenning (min.):	220 V
Modem (RJ-11)-porter:	1
Normal backuptid ved halv belastning:	5.1 min
Normal backuptid ved full belastning:	- min
Kald oppstart:	Ja
Hot-swap-batterier:	Ja
Automatic Voltage Regulation (AVR):	Ja
Output spenningsforskrift:	+8, -21
Luftfuktighet, uvirksom:	0 - 95
